Introduction
FR1000Z is a router that provides high-speed Internet access, a built-in
switch, a firewall and high-speed wireless networking capability. It allows
you to enjoy high-bandwidth applications, such as video streaming, on-
line gaming and peer-to-peer (P2P). You can also set up a secure
wireless network connection using the WPS button.
Before You Begin
Make sure you have the following things before you set up your
FR1000Z.
• Internet access - account information provided by your ISP, such as
user name, password, and so on.
• Internet Explorer 6.0, Firefox 3.6, Safari: 4.0.5, Opera: 10.51 or
Chrome 4.1.249.1064 as well as later versions of all these
browsers, with JavaScript enabled.
3

Advertisement

loading

Related Manuals for ZyXEL Communications FR1000Z

Summary of Contents for ZyXEL Communications FR1000Z

  • Page 1 Introduction FR1000Z is a router that provides high-speed Internet access, a built-in switch, a firewall and high-speed wireless networking capability. It allows you to enjoy high-bandwidth applications, such as video streaming, on- line gaming and peer-to-peer (P2P). You can also set up a secure wireless network connection using the WPS button.

  • Page 2: Hardware Connections

    2. ETHERNET: Use an Ethernet cable to connect a computer to this port for initial configuration and/or Internet access. 3. Use the power adaptor provided with your FR1000Z to connect an appropriate power source to this socket. As of writing, the USB port is reserved for future use.
  • Page 3 Checking the LEDs (Lights) Look at the LEDs (lights) on the top panel of the FR1000Z. • The POWER light blinks during start-up and is green once the FR1000Z is ready. • The WAN light is green if the Internet connection exists and blinks when transmitting data.

  • Page 4: Initial Configuration

    Testing Internet Connection After you have connected the hardware and turned on the FR1000Z, open a web browser on your computer and go to any web site (for example, www.zyxel.com) to test your Internet connection. If you are prompted for a user name and password, enter the account information as given by your Internet service provider (ISP).
  • Page 5  If the main screen does not display, make sure your computer is set to get an IP address automatically from a DHCP server. Click Quick Setup from the main screen. Follow the instructions in the screen and enter the Internet access information exactly as given to you by your ISP and click Apply.
  • Page 6 INTERNET lights should be green. Set Up a WPS Connection Press the WPS button on the FR1000Z’s front panel for more than 5 seconds to turn the WPS function on. Follow these steps to add a WPS-enabled device to the wireless network using the WPS button.

  • Page 7: Wall Mounting

    5. Make sure the screws are snugly fastened to the wall. They need to hold the weight of the FR1000Z with the connection cables. 6. Align the holes on the back of the FR1000Z with the screws on the wall. Hang the FR1000Z on the screws.
  • Page 8 ACTA. On bottom of this equipment is a label that contains, among other information, a product identifier of QWEST FR1000Z. If requested, this number must be provided to the telephone company. 2. If this equipment DL causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required.

  • Page 9: Service Requirements

    6. Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information. 7. If the telephone company requests information on what equipment is connected to their lines, inform them of: a.
  • Page 10 Service can be facilitated through our office at: ZyXEL Communications Corporation 6, Innovation Rd II, Science-Based Industrial Park, Hsin-Chu, Taiwan, R.O.C. +886- 3-578-3942 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 11 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. RF exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any...
