USE AND CARE GUIDE
MERRYN POINTE 52 IN. CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday
HOMEDEPOT.COM/HOMEDECORATORS
1-800-986-3460
THANK YOU
THANK YOU
Item #752 973
#753 638
Model # YG583-BN
# YG583-WH
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection MERRYN POINTE YG583-WH
Summary of Contents for Home Decorators Collection MERRYN POINTE YG583-WH
- Page 1 USE AND CARE GUIDE MERRYN POINTE 52 IN. CEILING FAN Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............Operation ..............Wall Control Operating Instructions ........Safety Information ............Reverse Switch Operating Instructions ......... Warranty ................. Care and Cleaning ............Pre-installation .............. Specifications ................Troubleshooting ............Tools Required ................. Hardware Included ..............Service Parts ............... -
Page 3: Safety Information
Safety Information To reduce the risk of electric shock, ensure electricity has However, there is no guarantee that interference will not occur been turned off at the circuit breaker or fuse box before in a particular installation. If this equipment does cause harmful beginning. -
Page 4: Warranty
Warranty We warrant the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. We also warrant that all other fan parts, excluding any glass or acrylic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of two years after the date of purchase by the original purchaser. -
Page 5: Hardware Included
Pre-Installation (continued) HARDWARE INCLUDED HARDWARE INCLUDED NOTE: Hardware shown to actual size unless noted otherwise in the table below. Part Part Description Description Quantity Quantity Plastic wire nut Canopy mounting screw with lock washer (preassembled) Blade arm screw and lock washer (not to scale) Clevis pin (preassembled) Cotter pin (preassembled) Collar setscrew (preassembled) -
Page 6: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS PACKAGE CONTENTS Part Part Description Description Quantity Quantity Part Part Description Description Quantity Quantity Mounting bracket (preassembled) Blade Canopy ring (preassembled) Light kit mounting plate Canopy 24 watt LED Light kit Hanger ball/downrod assembly Glass shade Coupling cover Wall switch Fan motor assembly... -
Page 7: Installation
Installation MOUNTING OPTIONS MOUNTING OPTIONS WARNING: To reduce the risk of fire, electric shock, or NOTE: You may need a longer downrod to maintain proper personal injury, mount the fan to an outlet box marked blade clearance when installing on a steep, sloped ceiling. acceptable for fan support using the screws provided with the The maximum angle allowable is 18°... -
Page 8: Assembly
Assembly Preparing the canopy Preparing the motor □ □ Remove the cotter pin (EE) and clevis pin (DD), and Remove the canopy ring (B) from the canopy (C). loosen the two collar setscrews (FF) from the motor collar. □ Remove the two non-slotted canopy mounting screws (BB) from the canopy (C), and loosen the slotted □... -
Page 9: Hanging The Fan
Assembly — Hanging the Fan Hanging the fan to the mounting Installing the mounting bracket bracket to the electrical box WARNING: To reduce the risk of fire, electric shock or WARNING: The tab in the ring must rest in the groove of other personal injury, mount the fan only to an outlet box or the hanger ball/downrod assembly (D). - Page 10 Assembly — Hanging the Fan (continued) Making the electrical connections WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. NOTE: Installation of this fan requires that a three-conductor cable with ground wire be run between ceiling and wall outlet box (VV). If you feel you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician.
- Page 11 Assembly — Hanging the Fan (continued) Installing the wall switch WARNING: Hook up in "series only". Do not connect the hot and neutral wires of the electric circuit to the wall switch - damage to the switch and possible fire could occur. WARNING: Remember to shut the power off at the circuit breaker or fuse box.
- Page 12 Assembly — Hanging the Fan (continued) Installing the canopy WARNING: Make sure the tab on the mounting bracket (A) properly sits in the groove in the hanger ball/downrod assembly (D) before attaching the canopy (C) to the mounting bracket (A) by turning the canopy (C) until it drops into place. WARNING: The locking slots of the canopy (C) are provided only as an aid to mounting.
-
Page 13: Attaching The Fan Blades
Assembly — Attaching the Fan Blades Fastening the blade assemblies to the motor WARNING: To reduce the risk of personal injury, do not insert foreign objects between rotating fan blades (G). □ Align the holes from the blade (G) to the holes from the motor (F), and secure the blade in place with screws and washers (CC) provided. -
Page 14: Installing The Light Kit
Assembly — Installing the Light Kit Attaching the light kit mounting Attaching the LED light kit plate to the mounting ring and glass shade □ Remove one of the three light kit mounting plate CAUTION: Before starting installation, disconnect the screws (HH) from the mounting ring (WW) and loosen power by turning off the circuit breaker or removing the fuse the other two screws. -
Page 15: Operation
Operation WALL SWITCH OPERATING INSTRUCTIONS WALL SWITCH OPERATING INSTRUCTIONS Restore power to the ceiling fan, and test for proper operation. “ ” button: The button is used to set the fan speed as follows: = Turns the fan off, 1 = High Speed, 2 = Medium High Speed, 3 = Medium Speed, and 4 = Low Speed. -
Page 16: Reverse Switch Operating Instructions
Operation (continued) REVERSE SWITCH OPERATING INSTRUCTIONS REVERSE SWITCH OPERATING INSTRUCTIONS The reverse switch is located on the surface of the coupling cover. This switch controls directions: forward (switch down) or reverse (switch up). NOTE: Wait for the fan to stop before reversing the direction of the blade rotation. -
Page 17: Troubleshooting
Troubleshooting WARNING: Make sure the power is off at the electrical panel box before you attempt any repairs. Refer to step 6 “Making the electrical connections” on page 10. Problem Problem Solution Solution □ Check the main and branch circuit fuses or breakers. □... -
Page 18: Service Parts
Service Parts Part Part Description Description Part Part Description Description Mounting bracket (preassembled) Blade arm screw and lock washer Canopy ring (preassembled) Clevis pin (preassembled) Canopy Cotter pin (preassembled) Hanger ball/downrod assembly Collar setscrew (preassembled) Coupling cover Collar mounting screw with lock washer (preassembled) Fan motor assembly Light kit mounting plate screw (preassembled) Blade... - Page 19 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use. YG583001-A...
