(110 Gallon 3-Point Sprayer w/8-Row Boom, Handgun, Coupler & Silver Series Pump)
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
3 Point sprayer.
Retain a copy of your receipt for your unit, as it will be required
to validate any warranty service.
Warranted against manufacturer or workmanship defects from
date of purchase with copy of receipt:
Homeowner Usage: One Year
Commercial Usage: 90 Days.
1.
Install the preassembled tee valve sub-assembly to the 3-point
carrier valve mount and position as shown.
OWNER'S MANUAL
Model: 110-3PT-17N-XL (5303142)
Assembly Instructions
Category I or II
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON, PLEASE CALL
1-800-831-0027
MONDAY-FRIDAY, 8:00 AM TO 5:00 PM CST
If you should have a question or experience a problem with
your Fimco Industries Product: Visit our website @
www.fimcoindustries.com or call the Toll free number above. Our
technical support representatives will be happy to help you.
In most cases a customer service rep. can resolve
the problem over the phone.
To obtain prompt, efficient service, always remember to give the
following information....
• Correct Part Description and/or part number
• Model number and Serial Number
Part descriptions and numbers can be obtained from the
illustrated parts list section(s) of this manual.
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5195446
2.
Slide a hose clamp on to the
1/2" bypass hose (from the
relief valve), then with a twist-
ing motion, slip the bypass
hose over the fitting on the
bottom of the tank. Slide the
hose clamp to the end of the
hose and secure.
(10/20)]
Page 1

Advertisement

loading

Summary of Contents for Fimco 110-3PT-17N-XL

  • Page 1 Install the preassembled tee valve sub-assembly to the 3-point www.fimcoindustries.com carrier valve mount and position as shown. 1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049 Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440 [5195446 (10/20)]...
  • Page 2 3/4” 1” Using a good quality thread sealant, thread the 1” fitting into the inlet (IN) side of the pump and the 3/4” fitting to the outlet (OUT) side of the pump. With a twisting motion, attach the other end of Using a good quality thread sealant, carefully thread the 1”...
  • Page 3 Loosen nut on eye bolt 11. Loosen the eye bolts and remove the 7” hinge bolts. Line up the outer booms and reassemble the hinge bolt through the outer boom yoke, the hinge casting and the spring connector. Tighten the eye bolt until the spring is at the desired tension. Lock the eye bolt in place with the inner whiz flange locknut.
  • Page 4 Spray Tip Rate Chart (20" Spacing) Information About the Sprayer Roller pumps are positive displacement pumps, which means that Gal. Per Acre - Based on Water Pressure Capacity the entire solution being pumped must go somewhere or the pump (psi) (GPM) will break.
  • Page 5 Testing the Sprayer plain water and use FIMCO Tank Neutralizer and Cleaner and repeat cleaning instructions above (If no tank cleaner is available, you may Attach the sprayer to the tractor 3 point hitch. Mount the pump to the substitute dish soap for this step, about 1-2 oz. per gallon). Flush the PTO and affix the torque chain.
  • Page 6 Piston Type Pressure Relief/Regulating Valves Bypasses excess fluid. Adjustable to maintain control of line pressure at any pressure within the valve operating range. Selected pressure setting firmly held in place by locknut. Extra large passages to handle large flows.  Polypropylene with stainless steel spring ...
  • Page 7: Troubleshooting

    Roller Pump General Safety Information Use a pressure relief device on the discharge side of the Disconnect power before servicing. pump to prevent damage from pressure buildup when the 10. Release all pressure within the system before servicing any pump discharge is blocked or otherwise closed and the pow- component.
  • Page 8: Exploded View

    Refer to pages 9-11 For Boom breakdown Exploded View: & 110-3PT-17N-XL Part (5303142) Numbers Refer to the parts list next page for part numbers. Bypass Hose Plumbing Detail Page 8...
  • Page 9 Parts List: 110-3PT-17N-XL (5303142) * *: Available ONLY in complete assembly Back Rack Assembly (5277359) Refer to the boom parts list next page for part numbers. NOTE: Assembly of opposite end is similar to this end. Bolt (Ref. #1.9) goes through the yoke on the outer boom(s), then through Ref.
  • Page 10 Model: 257-8 (8-Row) Boom Assembly See Detail A (5300658) Detail A See Detail B See Detail C Detail B Detail C Mounting Angles Mounting Angles ARE Used are NOT Used Center “Back-Rack” Mounted Center “Back-Rack” Mounted In “High” Position In “Low” Position Page 10...
  • Page 11 257-8 (STD) Harness Parts List Ref. #20.1 - 257-8 Center Nozzle Harness (#5277761) Ref. #20.2 - 257-8 LH Nozzle Harness (#5277806) Ref. #20.2 - 257-8 RH Nozzle Harness (#5277806) NOTES: All hoses in this boom assembly are part #5020569 (Ref. # 1) All hose clamps (2 per hose) are #5051114 (Ref.
  • Page 12 Dimensions 59.500” 44.000” 30.000” 52.875” 8.938” 37.750” 41.000” Boom Width Folded Out: 28’ NOTES: Page 12...
  • Page 13 NOTES: Page 13...
  • Page 14: Warranty

    WHAT REMEDIES ARE AVAILABLE UNDER THIS LIMITED WARRANTY. If the conditions set forth above are fulfilled and the Equipment or any part thereof is found to be defective, Fimco, Inc. shall, at its own cost, and at its option, either repair or replace the defective Equipment or part.
