DOREL ASIA
Model No:
SOFA BED
WM3350-SB
UPC CODE:
0-65857-16119-9
NOTE:
THIS INSTRUCTION
BOOKLET CONTAINS
IMPORTANT
SAFETY
INFORMATION. PLEASE
READ AND KEEP FOR
FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR A
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETUR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WM3350-SB and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Asia WM3350-SB

Summary of Contents for Dorel Asia WM3350-SB

  • Page 1 DOREL ASIA Model No: SOFA BED WM3350-SB UPC CODE: 0-65857-16119-9 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) ________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.

  • Page 2: Care And Cleaning

    Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.

  • Page 3: Hardware List

    SOFA BED WM3350-SB HARDWARE LIST Ø5/16" X 55mm Ø12.5 X 1.2mm Ø22 X 1.5mm HEX SOCKET HEAD BOLT SPRING WASHER FLAT WASHER 6 PCS 6 PCS 6 PCS Ø5mm ALLEN KEY 1 PC...

  • Page 4: Parts List

    SOFA BED WM3350-SB PARTS LIST BACK CUSHION SEAT CUSHION RIGHT ARM 1 PC 1 PC 1 PC LEFT ARM SOFA BODY FOOT 1 PC 1 PC 4 PCS PLASTIC WASHER 4 PCS...
  • Page 5 SOFA BED WM3350-SB NOTE: The mattress has been secured inside the sofa bed for transportation purposes. Do not remove the plastic string located on the front bars of the sofa bed until you have finished assembling your sofa bed.
  • Page 6 SOFA BED WM3350-SB STEP 1: Connect right arm (C) to sofa body (E) by inserting the metal bracket on right arm (C) into the glide on sofa body (E) as shown. Repeat this step to attach left arm (D). Note: The sofa bed mattress has been removed from the illustration for clarity.
  • Page 7 SOFA BED WM3350-SB STEP 2: With the help of another person, gently lay the sofa body (E) on its back on a clean, smooth surface. Secure the right arm (C) and the left arm (D) to sofa body (E) with flat washer (3), spring washers (2) and hex socket head bolts (1).
  • Page 8 SOFA BED WM3350-SB STEP 3: Attach feet (F) to sofa body (E) with plastic washers (G) by rotating clockwise. Turn the assembled unit upright. NOTE: The sofa body (E) is lined with a thin fabric underneath. It's is necessary to pierce through this fabric with the bolt on feet (F).
  • Page 9 SOFA BED WM3350-SB STEP 4: Raise the back frame of the sofa body (E) in the upright position. Remove the plastic string located on the front bars securing the mattress to sofa body (E). Place back cushion (A) and seat cushion (B) on sofa body (E).
  • Page 10 SOFA BED WM3350-SB OPENING THE SOFA BED Remove the back cushion and seat cushion. Grasp the sleeper at the handle cut-out section and lift the mattress out of the sofa body into the first folded position. Unfold the front leg until both legs rest on the floor and bed is in the open position.
  • Page 11 SOFA BED WM3350-SB CLOSING THE SOFA BED Remove all objects on the sofa bed. Fold the legs until they completely rest against the folded bed. Once the mattress has been folded, grasp the handle cut out to gently lift and lower the mattress into the sofa body.
  • Page 12 SOFA BED WM3350-SB CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Dust leather regularly with a...
  • Page 13 MODEL #: WM3350-SB Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819...
