Furniture of America CM7549EK Assembly Instructions Manual

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM7549EK

DIFFICULT

Tools Required For Assembly:

Allen Wrench

Phillips Screwdriver

2 PERSONS RECOMMENDED

Page 1 of 6

(Included)

(Not Included)

Rev : 19-01-11

Table of Contents

Do you have a question about the CM7549EK and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7549EK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Allen Key m5 Headboard Panel CSK m4 x 32mm Headboard Corner Panel Headboard Leg (L&R) CSK m4 x 25mm Pan Head Screw Footboard m3.5 x 20mm...
Page 4 Attach Head Board Leg ( #3 ) to Head Board ( #1 ) then secure by using screws ( #B ) #B x 4pcs #D x 8pcs Attach and tighten Headboard Corner Panel (#2) to the Headboard and secure by using Panhead screw (#D).
Page 5 Align side rails (#5) to thebolts of the Headboard Leg(#3) and footboard (#4). Fully tighten the bolts. adjustable glider Attach support legs (#7) to the slats (#6), then adjust the leveler according to ground level. Page 5 of 6...
Page 6 Align slats (#6) evenly to the side rails, then secure by using screws (#B) #B x 8pcs Page 6 of 6...
