ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
show the degree of effort needed in assem-
bling a specific product (with 1 being easy and
5 being difficult). For most products, two per-
sons are recommended.
EASY
YNJ-1412-5
TOOLS REQUIRED FOR ASSEMBLY
Allen Wrench
Phillips Screwdriver
DIFFICULT
Page 1 of 9
2 PERSONS RECOMMENDED
(Included)
(Not Included)
14-09-05
Advertisement
Related Manuals for Furniture of America YNJ-1412-5
Summary of Contents for Furniture of America YNJ-1412-5
- Page 1 ASSEMBLY INSTRUCTIONS YNJ-1412-5 ASSEMBLY RATING TOOLS REQUIRED FOR ASSEMBLY Allen Wrench The Assembly Rating is a 5-point system that show the degree of effort needed in assem- (Included) Phillips Screwdriver bling a specific product (with 1 being easy and 5 being difficult). For most products, two per- (Not Included) sons are recommended.
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3 of 9...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5 of 9...
- Page 6 BOOKCASE ASSEMBLY INSTRUCTIONS MODEL # YNJ-1412-5 Please keep for future reference PARTS LIST " " 37.48 12.52 " 68.11 4PCS DIMENSIONS 4PCS 37.48''(W) X 12.52''(D) X 68.11''(H) 4PCS Before you begin, please read “Assembly and Care Advice”, “Pre- Assembly Introduction”...
- Page 7 ASSEMBLY INSTRUCTIONS STEP1 Hardware #1 = 12pcs Hardware #3 = 8pcs STEP2 Hardware #3 = 20pcs prepare and insert wood dowels into panels Page 7 of 9...
- Page 8 ASSEMBLY INSTRUCTIONS STEP3 Hardware #4 = 20pcs STEP4 Hardware #2 = 12pcs Page 8 of 9...
- Page 9 ASSEMBLY INSTRUCTIONS STEP5 Hardware #4 = 30pcs With the help of another person, carefully place the completed product upright. Make sure the product is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened.
