ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-1463
DIFFICULT
Page 1 of 12
E-commerce-Enitial Lab
Tools Required for Assembly
Phillips Screwdriver
Hammer
2 PERSON RECOMMENDED
(Not Included)
(Not Included)
14.11.14
Advertisement
Related Manuals for Furniture of America YNJ-1463
Summary of Contents for Furniture of America YNJ-1463
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-1463 ASSEMBLY RATING Tools Required for Assembly The Assembly Rating is a 5-point system that shows the degree of effort Phillips Screwdriver needed in assembling a specific (Not Included) product (with 1 being easy and 5 being Hammer difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3 of 12...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5 of 12...
-
Page 6: Parts List
CABINET ASSEMBLY INSTRUCTIONS MODEL # YNJ-1463 Please keep for future reference PARTS LIST 3PCS 5PCS 5PCS 5PCS DIMENSIONS 5PCS 31.49" (W) X15.74" (D) X45.27" (H) 5PCS Before you begin, please 3PCS read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions"... - Page 7 ASSEMBLY INSTRUCTIONS Assembling Drawer’s Runners (a.k.a. Rails, Glides, Slides or Guides) An assembly of ONE drawer requires two sets of runners. The runner is composed of an inner rail and outer slide. Please read completely first before assembling. Mounting the Inner Rail (Fixed) of the Runner: Before mounting, please determine which side of the panel is the front and rear.
- Page 8 ASSEMBLY INSTRUCTIONS STEP2 Hardware #1=12pcs Hardware #3=4pcs STEP3 Hardware #3=22pcs Page 8 of 12...
- Page 9 ASSEMBLY INSTRUCTIONS STEP4 Hardware #1=15pcs STEP5 Hardware #1=5pcs Hardware #3=10pcs Page 9 of 12...
- Page 10 ASSEMBLY INSTRUCTIONS STEP6 Hardware #2=20pcs Hardware #4=20pcs STEP7 Hardware #2=4pcs front Page 10 of 12...
- Page 11 ASSEMBLY INSTRUCTIONS STEP8 Hardware #2=4pcs Hardware #8=4pcs STEP9 Hardware #2=4pcs Hardware #9=6pcs Hardware #10=6pcs Page 11 of 12...
- Page 12 ASSEMBLY INSTRUCTIONS STEP10 Hardware #6=10pcs Extend the two outer slides of the runners so that they are align with the sides of the drawer. Make sure the pre-drilled holes from the drawer align with the screw holes of the outer slides.
