ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
show the degree of effort needed in assem-
bling a specific product (with 1 being easy and
5 being difficult). For most products, two per-
sons are recommended.
EASY
YNJ-1414&1420
TOOLS REQUIRED FOR ASSEMBLY
DIFFICULT
Page 1
Page 1
Phillips Screwdriver
Hammer
2 PERSONS RECOMMENDED
(Not Included)
(Not Included)
15-07-10
Advertisement
Table of Contents
Related Manuals for Furniture of America YNJ-1414
Summary of Contents for Furniture of America YNJ-1414
- Page 1 ASSEMBLY INSTRUCTIONS YNJ-1414&1420 ASSEMBLY RATING TOOLS REQUIRED FOR ASSEMBLY The Assembly Rating is a 5-point system that Phillips Screwdriver show the degree of effort needed in assem- (Not Included) bling a specific product (with 1 being easy and Hammer 5 being difficult). For most products, two per- (Not Included) sons are recommended.
- Page 2 NIGHTSTAND ASSEMBLY INSTRUCTIONS MODEL # YNJ-1414&1420 Please keep for future reference PARTS LIST 23.62 15.75 2PCS 2PCS 2PCS 2PCS DIMENSIONS 23.62”(W) X 15.75”(D) X 24.33”(H) Before you begin, please read “Assembly and Care Advice”, “Pre- 2PCS Assembly Introduction” and “Cam Lock Fastener Assembly Instructions”.
- Page 3 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5 of 13 Page 3...
- Page 4 ASSEMBLY INSTRUCTIONS STEP1 Insert the cam bolts (1) into the holes Hardware #1 = 14pcs shown below. Turn right to tighten. Hardware #2 = 4pcs Apply glue into the holes along (J), then insert the wood dowels (2) Page 7 Page 4...
- Page 5 ASSEMBLY INSTRUCTIONS Assembling Drawer’s Runners (a.k.a. Rails, Glides, Slides or Guides) An assembly of ONE drawer requires two sets of runners. The runner is composed of an inner rail and outer slide. Please read completely first before assembling. Mounting the Inner Rail (Fixed) of the Runner: Before mounting, please determine which side of the panel is the front and rear.
- Page 6 ASSEMBLY INSTRUCTIONS STEP3 Refer to page #3 Hardware #9 = 4pcs for cam lock assembly. Hardware #11 = 8pcs STEP4 Hardware #2 = 6pcs Hardware #11 = 6pcs Refer to page #3 for cam lock assembly. Page 9 Page 6...
- Page 7 ASSEMBLY INSTRUCTIONS STEP5 Hardware #11 = 4pcs Refer to page #3 for cam lock assembly. STEP6 Hardware #1 = 4pcs Insert screws (3) Hardware #2 = 4pcs Hardware #3 = 8pcs Hardware #7 = 2pcs Hardware #11 = 4pcs Hardware #15 = 2pcs Align the door knob (7) to Slide (Q) along the ridges.
- Page 8 ASSEMBLY INSTRUCTIONS STEP7 Hardware #6 = 4pcs Extend the two outer slides of the runners so that they are align with the sides of the drawer. Make sure the pre-drilled holes from the drawer align with the screw holes of the outer slides. Secure two screws from the inside of the drawer using a Phillips screwdriver to tight-...
