- Page 2 ASSEMBLY INSTRUCTIONS YNJ-1411-4 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For most Phillips Screwdriver products, two persons are recommended.
- Page 3 Page2of7...
- Page 4 PRE- ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 4 of 7...
- Page 6 BOOKCASE ASSEMBLY INSTRUCTIONS MODEL # YNJ-1411-4 Please keep for future reference PARTS LIST 35.43" (W) 2PCS 2PCS 2PCS 4PCS DIMENSION :35.43" (W) X 13.94" (D) X69.76" (H) 5PCS Before you begin, Please read “Assembly and Care Advice” and “Pre-Assemble introduction...
- Page 7 ASSEMBLY INSTRUCTIONS STEP : 1 Hardware 1 =8pcs prepare and screw cam lock pin into panels Hardware 2 =8pcs EMBLY INSTRUCTIONS EMBLY INSTRUCTIONS prepare and insert wood dowels into panels STEP : 2 Hardware 3 =16pcs allen key to fasten allen-head wood screw Page6of7...
- Page 8 ASSEMBLY INSTRUCTIONS STEP : 3 STEP : 4 Hardware 3 = 20pcs allen key to fasten allen-head wood screw Make sure the item on a flat surface and it does not feel loose or wobbly. lf it does double check that the bolts/screws ASSEMBLY IS COMPLETED are secured and properly tighten.
