INSTRUCTION
MANUAL
FOR
DISHWASHING
Mod.
... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... . . ... . . ... ... ... ...
ACS122
ACS151 – ACS152
ACS181 – ACS182
ACS201 – ACS202
ACS241 – ACS242
... ... ... ... ... ... ... ... ... . . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... . ... ... ... ... ... ... ... ... ... ... ... . . ... ... ...
Advertisement
Table of Contents
Related Manuals for Comcater ACS122
Summary of Contents for Comcater ACS122
- Page 1 … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … . . … . . … … … … ACS122 ACS151 –...
-
Page 3: Table Of Contents
instruction for the user INDEX Introduction............................4 INSTRUCTIONS FOR USE....................... 7 Notes before washing......................... 8 Operation and use ..........................8 Switching on............................8 Washing............................... 9 Instruction during washing......................... 9 Instruction after the washing session....................10 Useful advice ............................10 Maintenance............................10 Hygienic care............................11 Removal of lime scale encrustation’s ....................11 Optimum results ..........................11 Prolonged standstill of the machine ....................11... - Page 4 instruction for the user...
-
Page 5: Introduction
instruction for the user INTRODUCTION 1. Please read carefully the remarks contained in this manual, as they confirm important information for the correct installation, use and maintenance. Keep this manual for future reference by the staff. 2. After removal of the packing, check the machine is not damaged and is complete. In case of any doubt, do not use the machine and contact the service technician. - Page 6 instruction for the user...
-
Page 7: Instructions For Use
instruction for the user INSTRUCTIONS FOR USE... -
Page 8: Notes Before Washing
instruction for the user NOTES BEFORE WASHING 1)Make sure that: ?? wall isolating switch is connected ?? water and steam taps* are open ?? there is no lack of water and steam* in the supply net ?? tank and pump suction filters are clean and are located correctly and the overflow pipe is in position and closed ?? curtains are correctly placed ?? inspection doors are closed... -
Page 9: Washing
instruction for the user WASHING 1) Before starting the wash operations remove from the dishes all possible food leftovers and grease. 2) Pre-soak cutlery and also any dishes before washing, if they have been left for some time after being used. 3) Place the items to be washed in the baskets. -
Page 10: Instruction After The Washing Session
instruction for the user INSTRUCTION AFTER THE WASHING SESSION When the wash operations are complete: 1. Press button "S1" and turn switch "Q2" into position "O" to switch off the machine. 2. Isolate the machine by means of the wall switch and close the water valve and steam supply (this applies only to steam heating machines). -
Page 11: Hygienic Care
instruction for the user Ensure the procedures and frequency recommended by the detergent supplier are followed, also ensure that the correct products and equipment are used. In order to avoid damages to the machine, do not exceed the recommended dosing and at the end of the procedures, rinse thoroughly. -
Page 12: Self Cleaning (Optional)
instruction for the user Self cleaning (optional) At least once a week a thorough cleaning of the machine is necessary. For this purpose a specific detergent/disinfectant is advisable. The use of such a product offers the following advantages: ?? guarantee of perfect hygienic conditions as it is composed of active detergents and disinfectants ?? maintenance of the machine in perfect hygienic conditions, also if the machine is not used. -
Page 13: Other Risks
instruction for the user Motor protection Each motor is protected against overload by overload relays QF1, QF2..placed in the control box (see electric diagram). Lamp "H03" is on, if one of the overload relays is activated. In this case the machine must be switched off and qualified staff are to be contacted for the repair work. -
Page 14: Instruction For Installation And Maintenance
instruction for the service people INSTRUCTION FOR INSTALLATION AND MAINTENANCE The following instructions are for qualified staff, who are authorised to carry out inspections and repair work, if necessary. The manufacturer declines all liability for damages due to incorrect installation or any repairs when original spare parts have not been used. -
Page 15: Location
instruction for the service people LOCATION The machine has to be installed in a “ normal” room or environment, which is adequately ventilated, dust free, well illuminated and without risk of explosion. INSTALLATION AND CONNECTIONS The installation of the dishwasher requires previously prepared supplies for the electrical and hydraulic connections, as indicated on the enclosed installation plan and data plates which refer to the model of your choice. - Page 16 instruction for the service people The machine must be included in an equipotential system, whose efficiency has to be checked according to the valid standard. The connection is made by means of a screw with the identification fitted to the back of the machine. The manufacturer declines all liability for damages due to the lack of an efficient earth bonded installation.
-
Page 17: Hot Water Connection (B)
instruction for the service people HOT WATER CONNECTION (B) A water valve has to be provided in an easily accessible position, to which the inlet filter has to be connected. For dimensions of the valve please refer to installation drawing. Strictly observe the national and regional water board regulations in force. -
Page 18: Steam Elimination
instruction for the service people STEAM ELIMINATION For machines with splash-guard protection with collar or machines with heat recovery unit, connections are to be effected according to fig.5. BEFORE STARTING THE MACHINE ?? The boiler circuit breaker QFE10 (and QFE11) has to be open (position OFF). Before reactivating it, check, after having switched on the machine that the boiler is full of water by making sure that water is coming out of the rinsing nozzles. -
Page 19: Setting
instruction for the service people SETTING Cooling of HRU (for machines with heat recovery unit only) Adjust the thermostat ST12, placed in the box of the heat recovery, to ensure that the air coming out from the battery of the heat recovery unit does not exceed 35-40°C. Torque limiter The limiter has already been described in paragraph “SAFETY DEVICES”. -
Page 20: Some Problems Which May Occur During The Use Of The Dishwasher, Their Reasons And Remedies
instruction for the service people SOME PROBLEMS WHICH MAY OCCUR DURING THE USE OF THE DISHWASHER, THEIR REASONS AND REMEDIES PROBLEMS TROUBLE SHOOTING When switching on the machine, a)make sure that the wall isolating Lamp "H01" does not light up switch is making contact and the relevant fuses are not burnt. - Page 21 instruction for the service people PROBLEMS TROUBLE SHOOTING d)make sure that the coil of the solenoid valve for the tank fill is not damaged and that there is voltage at the valve Continuous filling of tanks a)make sure that the air trap of the pressure switch is not damaged and that the connection to the hose is not detached.
- Page 22 instruction for the service people PROBLEMS TROUBLE SHOOTING e)make sure that the plugs of the spray arms are fitted correctly f)if the pump is not running; check the following: - the overload relay of the motor protector has not excluded the respective pump;...
- Page 23 instruction for the service people PROBLEMS TROUBLE SHOOTING If the pressure at the manometer is 0,5 bar min. and the machine starts heating, this means that the problem is on the installation of the steam condense recovery. Insufficient rinsing a)Before checking the rinse system check that the wash section is operating correctly, as poor wash results may...
- Page 24 instruction for the service people PROBLEMS TROUBLE SHOOTING If none of the above reasons appears to be the cause for the problem, proceed as follows: Machine with electric heating Make sure that the circuit breaker "QFE10" (or QFE11)has not switched off or is faulty. make sure that the coil of the contactor "KE10"...
- Page 25 instruction for the service people PROBLEMS TROUBLE SHOOTING make sure that the steam condensate is being discharged freely. make sure that the steam heating coil is not encrusted, thus limiting heat exchange. The manufacturer declines all liability for printing errors in this instruction manual. He furthermore claims the right to carry out modifications which are useful for his products without compromising their essential features.
- Page 26 ACS 122 - eng 03.2003...
