- Page 1 MANUALE DI ISTRUZIONE PER LAVASTOVIGLIE INSTRUCTION MANUAL FOR DISHWASHERS NOTICE D’UTILISATION POUR LAVE-VAISSELLE GEBRAUCHSANWEISUNG FÜR GESCHIRRSPÜLER...
- Page 2 FOREWORD 1. Read the instructions contained in the enclosed booklet carefully, because it contains important information on installation, operation and maintenance safety. Store this booklet carefully for any further consultation by other operators. 2. Having removed the packing material, check that all the equipment is present.
- Page 3 INSTRUCTIONS FOR USE...
-
Page 4: Operation And Use
INSTRUCTIONS FOR THE USER OPERATION AND USE 1)Before washing make sure that: • the wall-mounted on/off switch is switched on; • the water tap is open; • water is present in the distribution network; • the pump protection filters are installed in their respective positions; •... - Page 5 INSTRUCTIONS FOR THE USER START With closed door, select the wash cycle according to conditions of the dishware: • with normally dirty dishes press "S3" button (rapid flashing of the lamp "H3") (short cycle started); • with particularly dirty dishes or deep dishes, press "S3" button for 3 sec. (slow flashing of the lamp “H3”) (long cycle started).
- Page 6 INSTRUCTIONS FOR THE USER SELF-CLEANING AND DRAIN When the wash operation has been completed (machine off) pull out the overflow pipe, close the front door and press the "S5" button for the self- cleanig and drain cycle. The machine will carry out the cycle (lamp "H5" flashes) for 2 minutes and 20 seconds.
-
Page 7: Useful Suggestions
INSTRUCTIONS FOR THE USER USEFUL SUGGESTIONS 1) MAINTENANCE IMPORTANT: Before carrying out the cleaning and maintenance operations, disconnect the equipment from the electric supply. Frequently check and clean the nozzles. The frequency of this operation will depend on the quantity of residues, which may result in an unsatisfactory washing result. -
Page 8: Hard Water Conditions
INSTRUCTIONS FOR THE USER 3) TEMPORARY MACHINE NON-USE In case the machine is stopped for some weeks, it is recommended before closing it to fill the tank and run the machine with clean water, then empty it out, in order to avoid the forming of bad odour and that any residue remains in the pump. - Page 9 INSTRUCTIONS FOR THE USER 6) RESINS REGENERATION OF THE WATER SOFTENER (only for machines with built-in water softener) The regeneration of the water softener resins is completely automatic. The flashing of the regeneration lamp “H4” indicates the need to regenerate the resins, in any case the presence of some opaque spots on the glasses will show that it is necessary to start the regeneration.
-
Page 10: Control Panels
INSTRUCTIONS FOR THE USER CONTROL PANELS Main switch Push button “CYCLE SELECTION / START CYCLE” Push button “REGENERATION” (mod. FC54-EA) Push button “SELF-CLEANING / DRAIN CYCLE” (machine OFF) Push button “DRAIN CYCLE” (machine ON / door frontal opened) H1-H2 Pilot lamp “MACHINE ON" (flashing) H1-H2 Pilot lamp “MACHINE READY"... - Page 11 INSTALLATION AND MAINTENANCE INSTRUCTIONS The following instructions are addressed to a qualified personnel the only one authorised to carry out checks and repairs, if any. The manufacturer declines any responsibility in the case of interventions made by a non qualified personnel or the use of spare parts other than those supplied by the Manufacture.
-
Page 12: Installation
Model 220/230V∼ 220/230V3∼ 380/400V 3N∼ FC54-E FC54-EA For other supplies the cable cross section must be calculated according to voltage and length of cabling. If cabling too long adjust cable size to Amp rating; do not pull on supply cable or install it under tension. If cable needs to... -
Page 13: Water Connection
INSTRUCTIONS FOR TECHNICAL PERSONNEL 3)WATER CONNECTION Install a 55°C water tap and for machines with cold rinse a 12°C water tip in a well accessible place, terminating in a 3/4" fitting, which the pipe strainer and inlet hose shall be connected to. Carefully comply with any national or regional regulations in force. - Page 14 INSTRUCTIONS FOR TECHNICAL PERSONNEL 6)DETERGENT DOSAGE (for machines with built-in detergent dispenser) With the screw on the side of the detergent pump, close completely the product intake, then slowly open the screw until the desired intake quantity has been reached. The correct quantity is indicated by the detergent supplier. Check that the intake of the pipe during the rinse cycle is as preset.
- Page 15 INSTRUCTIONS FOR TECHNICAL PERSONNEL 7) WASH CYCLE SETTING Using the "S5" button it is possible to select different wash cycles according to the type of requirement. Set the cycles time, as follow: Turn on the machine by switching on the wall switch and keep pressed "S5"...
-
Page 16: Energy Consumption
(l) racks with racks with inlet water inlet water at at 55°C 12°C FC54-E 2000 3000 3450 30/20 FC54-EA 2000 3000 3450 30/20 In the event of low water supply temperature, the will be a subsequent... -
Page 17: Wiring Diagram
INSTRUCTIONS FOR INSTRUCTIONS FOR TECHNICAL PERSONNEL TECHNICAL PERSONNEL WIRING DIAGRAM Main switch Start switch Regeneration switch Self-cleaning / drain switch H1-H2 Pilot lamp power on / machine ready Pilot lamp machine working Pilot lamp regeneration Pilot lamp Self-cleaning/drain cycle Control electronic panel Power electronic panel Door microswitch Rinse solenoid valve... - Page 18 05.2001 CODICE 900173...
