peerless-AV MOD-CPI Installation Instruction page 5

ENG
Parts (Before beginning, make sure you have all parts shown below).
ESP
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes).
FRN
Pièces (avant de commencer, assurez-vous d'avoir toutes les pièces illustrées ci-dessous).
DEU Teile (Achten Sie vor Beginn der Arbeiten darauf, dass alle unten abgebildeten Teile vorhanden sind).
NEL Onderdelen (hoort u zich ervan te overtuigen dat u alle onderdelen hebt, die hieronder te zien zijn).
ITL Parti (prima di iniziare, accertarsi di disporre tutte le parti sotto indicate).
ČEŠ Díly (předtím, než začnete, připravte si všechny díly zobrazené níže).
SLK Diely (predtým, ako začnete, pripravte si všetky diely zobrazené nižšie).
Peças (antes de iniciar, certifi que-se de que tem todas as peças apresentadas em baixo).
POR
Parçalar (Başlamadan önce, aşağıda gösterilen bütün parçaların elinizde olduğundan emin olun).
TÜR
Parts List
Description
A I-beam plate
B I-beam clamp
C M8 x 35mm set screw
D M8 x 20mm screw
E M8 x 65mm screw
F M8 fl at washer
G M8 split washer
H M8 nut
I 5mm allen wrench
J 4mm allen wrench
C ( 2 )
M8 x 35mm set screw
F ( 3 )
M8 fl at waser
MOD-CPI
Qty Part #
1 100-1059
2 100-1057
2 520-1753
4 520-1754
2 520-1750
3 540-9478
1 540-9405
1 530-1068
1 560-9640
1 560-9706
E ( 2 )
M8 x 65mm
G ( 1 )
M8 split washer
D ( 4 )
M8 x 20mm
H ( 1 )
M8 nut
5
2012-04-30
A ( 1 )
i-beam plate
B ( 2 )
I-beam clamp
I ( 1 )
5mm allen wrench
J ( 1 )
4mm allen wrench
#:120-9144-4 (2014-02-26)
