Installation and Assembly:
Wall Mount with PC Storage
Maximum Load Capacity
Model
Wall Mounted MOD-MBL
Wall Mounted MOD-MBL
with dedicated adapter plate
MOD-FPMS
SP850
FPS-1000
SA745PU
SA750PU
SA760PU
SA770PU
SA752PU
SA761PU
SA763PU
SA771PU
Visit the Peerless Web Site at www.peerless-av.com
Max. Load
200 lb (90kg)
150 lb (68 kg)
20 lb (9kg)
150 lb (68 kg)
150 lb (68 kg)
70 lb (32 kg)
130 lb (59 kg)
170 lb (77 kg)
170 lb (77 kg)
80 lb (36 kg)
130 lb (59 kg)
160 lb (73 kg)
160 lb (73 kg)
Model: MOD-MBL
1
For customer care call 630-375-5100 or 800-865-2112.
ISSUED: 05-08-13 SHEET #:125-9434

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOD-MBL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for peerless-AV MOD-MBL

Summary of Contents for peerless-AV MOD-MBL

  • Page 1 170 lb (77 kg) SA752PU 80 lb (36 kg) SA761PU 130 lb (59 kg) SA763PU 160 lb (73 kg) SA771PU 160 lb (73 kg) ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.

  • Page 2: Parts List

    M4 x 12 mm socket pin serrated washer head screw 510-1079 #14 x 2.5" hex head wood screw 5S1-015-C03 concrete anchor 590-0320 M5 x 10mm type f screw 520-1164 ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
  • Page 3 Attaching adapter plate (A) to tilt box assembly (not included) with four self taping screws (Q). MOD-FPMS NOT INCLUDED ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
  • Page 4 (K), M5 x 12 mm screws (L) washers (K) or (L) with #10 washers (H) M6 x 12 mm screws (G) with #10 washers (H) DETAIL 2 ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.

  • Page 5: Mounting Pattern

    MOUNTING PATTERN UNIVERSAL ADAPTER BRACKET ACC-950 SPACER AND M10 X 40 MM SCREWS (SUPPLIED WITH ACC950) M10 x 40 mm (supplied with ACC950) ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
  • Page 6 Secure wall plate (B) to adapter plate (A) with four M8 x 15 mm screws (D) using 4 mm allen wrench (I) as shown below. ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
  • Page 7 Hook wall plate (B) and two exposed M10 x 15 mm penta-pin screws (E) into keyhole slots on mount. 1/8" KEYHOLE SLOT ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
  • Page 8 Tighten all (M5 x 20 mm, M5 x 25 mm) screws. M5 X 20 MM SCREW ROLL BRAKE ADAPTER PLATE TILT BRACKET WALL ARM MOUNT ADAPTER PLATE M5 X 25 MM SCREW ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.

  • Page 9: Installation To Wood Stud Wall

    Hook wall plate (A) onto exposed #14 x 2.5" wood screws (O). Secure using one #14 x 2.5" wood screws (O) as shown in figure 5.2 Skip to Step 6. 1/4" Figure 5.2 Figure 5.1 ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.

  • Page 10: Installation To Solid Concrete Or Cinder Block

    INCORRECT CORRECT Tighten all fasteners. concrete concrete wall wall plate plate plaster/ plaster/ dry wall dry wall ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
  • Page 11 Figure 6.1 Figure 6.2 REMOVE ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112. © 2010, Peerless Industries, Inc. All rights reserved. All other brand and product names are trademarks or...
  • Page 12 44 (0) 1923 200 100 01-800-849-65-77 www.peerless-av.com www.peerless-av.com www.peerless-av.com © 2013, Peerless Industries, Inc. © 2013, Peerless Industries, Inc. © 2013, Peerless Industries, Inc. ISSUED: 05-08-13 SHEET #:125-9434 Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
