I N S T A L L A T I O N I N S T R U C T I O N S
Pole Clamp Accessory
Model: FSA-1017
The FSA-1017 Pole Clamp Accessory is used to provide
a means for attaching a desktop or wall mount to a
1 1/2" to 2" pole.

BEFORE YOU BEGIN

CAUTION!
To prevent damage to the Kit, which could affect or void the Factory warranty, and to the equipment that will be
attached to it, thoroughly study all instructions and illustrations before you begin the installation.
•
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE 700
SAVAGE, MINNESOTA 55378 USA
8807-000042
©2005 Chief Manufacturing
www.chiefmfg.com
12/05
