- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Dual Stud Wall Mount Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description WMA2S...
-
Page 2: Installation Instructions
Chief® is a registered trademark of Milestone AV Technologies. Reinforce the structure as required before installing the All rights reserved. - Page 3 Installation Instructions WMA2S LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 4: Tools Required For Installation
3/8" (10mm) concrete and concrete block 7/32" (5.6mm) wood 2" x 4" stud PARTS C (2) [Mount cap top] B (1) A (1) [Mounting bracket] [WMA2S Assembly] D (2) [Mount cap bottom] F (4) 5/16" H (4) 1/4-20 x 1-3/4" J (4) -
Page 5: Site Requirements
Installation Instructions WMA2S Site Requirements WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The figure below identifies the minimum requirements for installation of display mounts onto a steel stud structure. If the structure or its components do not meet these requirements contact the mount manufacturer for specific instructions before attempting installation. -
Page 6: Assembly And Installation
WMA2S Installation Instructions ASSEMBLY AND INSTALLATION The WMA2S dual stud wall mount accessory can be mounted (S) x 4 to concrete, concrete block, 2" x 4" wood studs (16" on center) (E) x 4 or steel studs. It can be mounted to studs up to 16" apart. - Page 7 Installation Instructions WMA2S Install four 5/16 x 2-1/2" hex head lag screws (E) through Hold metal channel on anchor (J) flat alongside plastic four 5/16" washers (F), holes of mounting bracket and into straps and slide channel through hole. (See Figure 6) drilled holes.
- Page 8 (H) x 4 Figure 11 Install two 1/4-20 x 5/8" hex head bolts (P) through holes on WMA2S arm (A) and into sliding nuts on mounting bracket (B). DO NOT TIGHTEN SCREWS AT THIS POINT! (See Figure 12) Anchor Metal Channel...
-
Page 9: Installing Mount Covers
Installation Instructions WMA2S Loosen two bolts on either side of pitch adjustment screw. Lower the upper cover (V) onto the wall mount and fasten (See Figure 13) through upper cover (V), lower cover (W) and into wall mount with two 8-32 x 1/2" Phillips pan head screws (T). -
Page 10: Projector Installation
WMA2S mounting plate. (See Figure 16) IMPORTANT ! : The maximum length column that can be attached to the WMA2S is 48 inches (121.9 cm). Install column (not included) following instructions included (T) x 2 with column. - Page 11 Installation Instructions WMA2S Remove cable management cover (if necessary) from WMA2S arm. (See Figure 19) (bottom view) Cables (example) Wall bracket channels Cable management cover Figure 21 • Routing Cables from Above (Step 7) Thread cables down through a surface mount cable...
- Page 12 WMA2S Installation Instructions Route cables through cover mount, WMA2S arm and into 10. Replace removed cable management cover (if necessary) column. (See Figure 23) by snapping it into place. (See Figure 25) (bottom view) Cable management cover Figure 25 11. Replace mount covers on the mount following instructions in Installing Mount Covers section.
-
Page 13: Pitch Adjustment
Installation Instructions WMA2S Secure wall bracket top covers (C) to wall bracket arms by Pitch Adjustment installing four #8-32 x 1/2" Phillips pan machine screws (T) Remove mount covers from the mount following instructions through holes in covers and wall bracket. (See Figure 27) in Removing Mount Covers section. -
Page 14: Security Screw Installation (Optional)
(bottom view) Extension Adjustment Loosen two bolts holding stop bracket in place on underside of WMA2S mount. (See Figure 31) Adjust mount to desired extension length. (See Figure 31) Tighten two bolts holding stop bracket to secure mount in desired position. (See Figure 31) - Page 15 Figure 34 (See Figure 37) Remove two #8-32 x 1/2" Phillips pan machine screws (T) holding mount covers on WMA2S arm. (See Figure 35) Install two #8-32 x 1/2" button head security screws (M) into Sliding nuts holes on mount covers. (See Figure 35)
- Page 16 WMA2S Installation Instructions Remove one of four bolts from adapter plate. (See Figure 38) Install one 1/4-20 x 3/4" button head security screw (L) into hole vacated by removing bolt in Step 8 and into plastic spacer. (See Figure 39) 10.
- Page 17 Installation Instructions WMA2S...
- Page 18 WMA2S Installation Instructions...
- Page 19 Installation Instructions WMA2S...
- Page 20 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
