- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S DISPLAY COVER ACCESSORY DGP32, 42, 50...
-
Page 2: Installation Instructions
The DGP32 weighs 35 lbs (15.88 kg) The DGP42 weighs 40 lbs (18.14 kg) The DGP50 weighs 75 lbs (34.02 kg) - Page 3 Installation Instructions DGP32, 42, 50 DIMENSIONS DGP42 Measurements in: inches [millimeters] DGP50 Measurements in: inches [millimeters]...
-
Page 4: Tools Required For Installation
DGP32, 42, 50 LEGEND Open-Ended Wrench Llave de boca Gabelschlüssel Chave de bocas Chiave a punte aperte Steeksleutel Clé à fourche TOOLS REQUIRED FOR INSTALLATION PARTS A (1) - Display Cover with support brackets B (8) - Bolt assemblies C (4) - Clamp bracket D (8) - Flange nuts 7/16"... -
Page 5: Assembly And Installation
Check display alignment and adjust as necessary. Install clamp brackets (C) over the bolt ends (B). (See Figure 3) Secure with flange nuts (D). NOTE: Clamps may be rotated to best fit cover to display. DGP32, 42, 50 Figure 2 (D) x 4 Figure 3... - Page 6 DGP32, 42, 50 8831-000014 2007 Chief Manufacturing www.chiefmfg.com 03/07 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615...
