RIOTEC RIOSCAN iLS6303XS Quick Manual

RIOSCAN 2D barcode scanner
Quick Guide
M o d e l n o . :
i L S 6 3 0 3 X S
Introduction
Designed primarily for smartphone, the iLS6303XS is a 2D barcode
scanner that allows you to scan various barcoded items and send data
to smartphone.
Its in-built Honeywell N5680 engine allows you to reliably read 2D
barcodes on various shapes and is a great space-saver for busy or
limited workspaces.
It supports not only iOS devices through Bluetooth communication,
but also Android OTG devices through USB cable
Delivery content
* Bluetooth Barcode scanner x 1
* Charging cradle x 1
* PCB material board+3 screws x 1
* Holder for smartphone x 1
* USB cable x 1
* Quick instructions x 1
Limited Warranty
Riotec provides a one year limited warranty.
This warranty does not cover any product which has been subject
to improper use, neglect or unauthorized repair or installation.
This warranty does not cover consumable parts. (Cables &
batteries are consumables.)
Safety instructions
Read the operating instructions carefully and especially
observe the safety information. If you do not follow the safety
instructions and information on proper handling in this
manual, we assume no liability for any resulting personal
injury or damage to property.
Don't put scanner in places excessively high temperatures,
*
such as expose under direct sunlight
Don't use scanner in extremely humid area or drastic
*
temperature change
The rechargeable battery is permanently built into the
*
product and cannot be replaced.
Never damage the rechargeable battery. Damaging the
*
casing of the rechargeable battery might cause an explosion
or a fire!
1
Charging:
1. Please switch on and charge scanner for 3~4 hours before first
use as shown on Fig.2
2. When user charge smartphone & scanner, please use
smartphone original USB power adapter.
3. The cradle functions as a charger for the scanner. Even if the
scanner's battery is full, the cradle will continue to supply power
to the scanner. We suggest removing the scanner from the cradle
when fully charged.
4. When you charge scanner & smartphone, please enter Wired
OTG mode & switch to "C- Charging mode".
iLS6303XS supports BT communication mode (for iOS & Android
devices) and wired OTG communication mode (for Android OTG
devices)
If you want to switch to another mode, please read the below configuration
code first.
Bluetooth communication
wired OTG communication mode
(default)
