- Page 1 Display Operating Manual FUJITSU Display B27-9 TE QHD / B27-9 TS QHD...
- Page 2 Internet at: "http://www.fujitsu.com/fts/" You can find driver updates at: "http://support.ts.fujitsu.com/download" Should you have any technical questions, please contact: • our Hotline/Service Desk ("http://support.ts.fujitsu.com/contact/servicedesk") • Your sales partner • Your sales office We hope you enjoy working with your new Fujitsu system!
- Page 4 Published by / Contact address in the EU Fujitsu Technology Solutions GmbH Mies-van-der-Rohe-Straße 8 80807 Munich, Germany "http://www.fujitsu.com/fts/" Copyright © Fujitsu Client Computing Limited 2019. All rights reserved. Publication Date 12/2019 Order No.: A26361-K1684-Z327-1-7619, edition 1...
-
Page 5: Table Of Contents
FUJITSU Display B27-9 TE QHD / B27-9 TS QHD Operating Manual Your LCD screen... Important notes Getting started Operation Notes on the program "DisplayView" Driver installation Notes on power management Notes on low blue light mode Notes on ergonomic colour adjustment... - Page 6 Remarks Notes on the product description meet the design requirements of Fujitsu and are provided for the purposes of comparison. The actual results may differ due to several factors. Subject to technical changes without prior notification. Fujitsu accepts no responsibility for technical or editorial mistakes or omissions.
- Page 7 Driver installation ..............37 Fujitsu...
- Page 8 Appendices: ................50 Fujitsu...
-
Page 9: Your Lcd Screen
You don’t need to be an "expert" to perform the operations described here. Nonetheless, it is important to always observe the safety notes given in the operating instructions for the computer and in this manual. In the event of any problems, please contact your sales office or our Service Desk. Fujitsu... -
Page 10: Further Information
"Safety information" • cross-references to an external source, e.g. a web address: For more information, go to "http://www.fujitsu.com/fts/" • Names of CDs, DVDs and titles or designations of other materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety" Manual indicates a button on the monitor, e.g:... -
Page 11: Important Notes
Use a screen saver with moving images and activate the power management for • your monitor to prevent still images from "burning in". • If you operate the device with the swivel arm or a similar accessory, it must not be turned by 180°. Fujitsu... -
Page 12: Power Cable
If the device is brought from a cold environment into the room where it will be used, condensation may occur. Before operating the device, wait until it is absolutely dry and has reached approximately the same temperature as the installation site. Fujitsu... -
Page 13: Cleaning The Device
CE marking The shipped version of this device complies with the requirements of EU directives 2014/30/EC "Electromagnetic compatibility", 2014/35/EC "Low voltage directive", 2009/125/EC "Ecodesign directive" and 2011/65/EC "RoHS directive". Fujitsu... -
Page 14: Disposal And Recycling
"http://www.recupel.be" can be found at: environment-care/recycling/" "http://www.swico.ch" Asia Taiwan: Fujitsu America, Inc. Environmental Protection 1250E. Arques Avenue Administration Sunnyvale, CA 94085 U.S.A. Executive Yuan R.O.C. Phone No.: (408) 746-6000 "http://recycle.epa.gov.tw" You can also find information about this on the Internet at "https://www.fujitsu.com/emeia/about/local/csr/recycling/". -
Page 15: Getting Started
► Should you discover that the delivery does not correspond to the delivery note, notify your local sales outlet immediately. Do not discard the original packing material of the devices. You may need the packaging in the future if you need to transport your device. Fujitsu... -
Page 16: Setting Up The Device
To ensure sufficient ventilation, the air inlet and outlet openings of the device must be kept clear. Setting up an ergonomic video workstation ► Do not position the video workstation opposite a window (1). ► Position the monitor outside the reach of a light source (1). Fujitsu... - Page 17 Depending on the situation, it may be advisable to use a swivel arm or similar accessory (VESA FPMPMI), which are available from specialist dealers. For this purpose the monitor base must be removed beforehand as described in Chapter "Removing monitor base", Page Fujitsu...
-
Page 18: Mounting The Monitor Base
The inclination of the monitor can be adjusted by -3° (forwards) and +35° (backwards) from its vertical position. ► Hold the monitor with both hands on the left and right sides of the case and move it to the desired angle (2, see "Adjusting height", Page 14). Fujitsu... -
Page 19: Adjusting The Rotation
(see "Functions of the control panel and the OSD menu", Page 21). To reset the monitor to landscape mode, the monitor should be turned anti-clockwise. The OSD display can be reset again in the OSD menu. Fujitsu... -
Page 20: Removing Monitor Base
For instructions on how to mount the swivel arm or a similar accessory, please see the documentation for the swivel arm or similar accessory. The assured ergonomics and safety of the monitor may be limited if the foot provided for the monitor is not used. Fujitsu... -
Page 21: Connecting The Device
8 = USB 3.1 Gen1 (5Gbps, downstream) 4 = Display port socket 9 = USB 3.1 Gen1 (5Gbps) type C 5 = AUDIO-IN socket 10 = Security slot for Security Lock ► Select the appropriate data cable for your computer. Fujitsu... -
Page 22: Connecting Cables To The Computer
► Plug the power connector of the computer into a properly grounded mains outlet. If your computer has two monitor ports ("onboard" screen controller and separate graphics card), the monitor port for the separate graphics card is active as standard. Fujitsu... -
Page 23: Operation
Monitor and computer are switched on (ECO mode). orange Monitor is not receiving a video signal or is in power saving mode. does not light up Monitor is switched off. ► Switch the device on again with the ON/OFF switch (1). Fujitsu... -
Page 24: Changing The Monitor Settings
Going to the next setting Running a function Going to the previous setting Decreasing the set value Increasing the set value Accepting the applied settings and returning to the previous menu Return to the parent menu Exiting OSD menu Fujitsu... -
Page 25: Functions Of The Control Panel And The Osd Menu
When an OSD menu button is activated for the first time, the language selection window will appear: ► Press the button or the button to choose the desired language. ► Press the button to confirm. After selecting the OSD language for the first time, you can change it at any time in the OSD. Fujitsu... -
Page 26: Setting Screen Display
This setting only appears with an analogue video signal (e.g. VGA). Adjust the horizontal position H-position With this function you move the picture to the left or to the right. This setting only appears with an analogue video signal (e.g. VGA). Fujitsu... - Page 27 Full screen = maximum picture size with distortion (no black bands) Keep aspect = Maximum picture size without distortion (black bands could appear in one direction) 1:1 = Centred image without scaling (black bands could appear in both directions). This function is not available on all models. Fujitsu...
-
Page 28: Configuring The Osd Menu
OSD submenu. ► Press the button to mark a function in the submenu. ► Press the button to make the desired setting. ► Press the button to save the settings and return to the main menu. Fujitsu... - Page 29 Auto = orientation of the OSD menu will automatically be matched to the orientation of the monitor. The Auto setting only appears on models with a rotation sensor. The Rotation function cannot be selected when the monitor is in Picture in Picture mode (Picture in Picture). Fujitsu...
-
Page 30: Advanced Setting Functions
This setting can be used to set the distance within which you want the sensor to react. If the vertical line is outside the setting bar, this will be judged as "absent" by the presence sensor. This setting can only be applied if the Presence Sensor function is active. Fujitsu... -
Page 31: Displaying Information
With a VGA data cable, the message Auto Processing is displayed. Displaying information ► Press the button to call up the main menu. ► Press the button to call up the Information window. Details such as the model designation, serial number, resolution, H/V frequency and ECO mode are displayed. Fujitsu... -
Page 32: Activate/Deactivate Eco Operating Mode
► Press the button to open the INPUT setting window. ► Press the button to select the desired monitor port. ► Press the button to confirm the selected monitor port or to close the window without making any changes. Fujitsu... -
Page 33: Selecting The Application Mode
Mode for the display of photos Photo Increased picture definition and colour saturation. Mode for the display of videos Video Enhanced reaction time (overdrive), dynamic contrast (ACR). Mode for special application purposes Custom Free choice of colour temperature, advanced configuration capabilities. Fujitsu... - Page 34 Operation The brightness set in Mode is stored under Office, Photo, Video and Custom. Fujitsu...
-
Page 35: Setting Colour Temperature And Colours
► Press the button to select the desired colour channel. ► Press the button to make the desired setting. ► Press the button to save the settings and return to the previous menu. Fujitsu... -
Page 36: Adjusting The Volume
Set the volume for playback with the integrated loudspeakers Volume Switch the loudspeakers off or on Mute Change the audio input signal to another source Input The setting only appears when more than one audio input signal is possible (e.g. display port and AUDIO-IN socket). Fujitsu... -
Page 37: Adjusting The Brightness And Contrast
This function improves the contrast by automatically controlling the background lighting in relation to the image being displayed. This setting can only be configured in Office and Custom application mode. As soon as ACR is enabled, Auto brightness is automatically disabled. Fujitsu... -
Page 38: Locking The Osd Menu
► Press the buttons at the same time and keep them pressed for a few seconds. The message Power button locked / unlocked is displayed. To remove the locking of the ON/OFF button again, proceed in the same way. Fujitsu... -
Page 39: Notes On The Program "Displayview
Auto brightness Contrast Black level Sharpness Apply settings to all connected monitors Undo DisplayView Can be downloaded here: "www.fujitsu.com/fts/displayview" Function overview: • OSD management for screens equipped with DDC/CI • OSD direct access for quick changes • Settings for power saving mode and security settings for the presence sensor (only for models with presence sensor) •... -
Page 40: Presence Sensor
The desktop area of the Microsoft Windows operating system can be divided into several areas into which program windows can be fitted automatically by adjusting their size. Brightness/Contrast Connected displays Mode Rotation Desktop Partitioning Desktop Partitioning Display1 Display2 Presence Sensor Desktop Partitioning Profiles Information Press left Ctrl key for Desktop Partitioning Fujitsu... -
Page 41: Driver Installation
Driver installation The display drivers are automatically installed when the Microsoft Windows operating system is updated. ► For manual installation, download the monitor drivers from "http://www.fujitsu.com/fts/download". ► Unpack the zip file. ► Open the Device Manager and select directory Monitors. -
Page 42: Notes On Power Management
ECO mode is the preset factory default. Once an input is made at the computer the screen contents are restored. For detailed information on how energy-saving mode operates, please refer to the operating manual or technical manual of the computer. Fujitsu... -
Page 43: Notes On Low Blue Light Mode
When working continuously at a display screen, it is recommended that you take a five minute break every hour. During these breaks, do eye exercises to relax your eyes. To prevent eye strain and dryness, focus regularly on objects in the distance. Fujitsu... -
Page 44: Notes On Ergonomic Colour Adjustment
+ Colour combination very suitable - Colour combination not suitable because colour hues are too close together, thin characters are not identifiable or rigorous focusing is demanded of the human eye. Fujitsu... -
Page 45: Explanatory Information About Standard Iso 9241-307
According to ISO 9241-3 (Class I), a maximum of 2 lit and 2 unlit pixels plus 9 lit or 18 unlit subpixels, or a corresponding combination, may be faulty (1 lit subpixel counts as two unlit subpixels). Because Fujitsu supplies displays that are free of pixel faults, only subpixel faults enter into the evaluation. Fujitsu... -
Page 46: Troubleshooting
Troubleshooting Troubleshooting Should an error occur, first check the following points. If the distortion is still not eliminated, the monitor should, if possible, be checked on another computer. If you cannot solve the problem, please contact our Service Desk. Fujitsu... - Page 47 ► Run the function Auto adjust (see Chapter noise) "Setting screen display", Page 22). The screen becomes darker The background lighting has a limited lifetime. If your monitor display should become too dark, the background lighting will have to be replaced. ► Contact our Service Desk. Fujitsu...
-
Page 48: Technical Specification
Technical specification Technical specification Condensation is not permitted, neither in the rated range of operation nor in the limit range of operation. Product name B27-9 TE QHD / B27-9 TS QHD Name of model B27-9TQ Dimensions and weight Visible diagonals 68.5 cm... -
Page 49: Preset Operating Modes
60/75 Hz (SXGA) 1440 x 900 60 Hz (WXGA+) 1600 x 900 60 Hz (HD+) 1680 x 1050 60 Hz (WSXGA+) 1920 x 1080 60 Hz (FHD) 1920 x 1200 60 Hz (WUXGA) 2560 x 1440 60 Hz (QHD) Fujitsu... -
Page 50: Video/Tv Operating Modes Via Digital Video Inputs
50 / 60 Hz 16:9 720 x 480 p 60 Hz 4:3 / 16:9 720 x 480 i 60 Hz 4:3 / 16:9 720 x 576 i 50 Hz 4:3 / 16:9 1920 x 1080 i 50 / 60 Hz 16:9 Fujitsu... -
Page 51: Dvi-D Port
Analog Vertical Sync TMDS Data1– TMDS Data1+ TMDS Data 1/3 Shield not connected not connected +5V Power Earth Hot Plug Detect TMDS Data0– TMDS Data0+ TMDS Data 0/5 Shield not connected not connected TMDS Clock Shield TMDS Clock+ TMDS Clock– Fujitsu... -
Page 52: Hdmi Port
HDMI port Meaning TMDS Data2+ TMDS Data2 Shield TMDS Data2– TMDS Data1+ TMDS Data1 Shield TMDS Data1– TMDS Data0+ TMDS Data0 Shield TMDS Data0– TMDS Clock+ TMDS Clock Shield TMDS Clock– N.C. DDC/CEC Ground +5 V Power Hot plug detect Fujitsu... -
Page 53: Displayport Socket
Lane 1 (negative) Earth Lane 1 (positive) Lane 0 (negative) Earth Lane 0 (positive) Connected to earth Connected to earth Auxiliary channel (positive) Earth Auxiliary channel (negative) Hot Plug Detect Return for Power Power for connector (3.3 V 500 mA) Fujitsu... -
Page 54: Appendices
Appendices: Appendices: TCO: "https://support.ts.fujitsu.com/IndexDownload.asp?SoftwareGuid=0b1846d6-c0bc-4535-8ad5- 1adb49610945" ENERGY STAR®: "https://support.ts.fujitsu.com/IndexDownload.asp?SoftwareGuid=d64ffa5e-9f01-475a-9269- 975391774341" BSMI RoHS: "https://support.ts.fujitsu.com/IndexDownload.asp?SoftwareGuid=2318189a-c6bc-4691-a45d- 2c37884197b6" China RoHS: "https://support.ts.fujitsu.com/IndexDownload.asp?SoftwareGuid=e8358fb7-83a3-45ca-b707- c36a868bf0ca" Fujitsu...
