DEMO MANUAL DC2293A
QUick start proceDUre
8. Click the "Program and Verify" button (See Figure 10)
and wait for the process to complete. After the process
is complete, you will see "Successfully Programmed
and Verified Device" in the status bar at the bottom.
See Figure 11.
Figure 10. Device Programming Utility.
6
Figure 11. Programmed and Verified Device
9. Set the power switch S1 to the OFF position prior to
removing the device.
Repeat steps above to program additional devices.
LTpowerPlay's Programming Utility does not need to
be closed. The ribbon cable may remain connected to
the programming board.
