DEMO MANUAL DC2293A

BoarD photo

TOP OF THE SPRING
LOADED SOCKET FRAME
DC1613 CONNECTOR J1
POWER SWITCH S1

orDer information

There are two versions of the DC2293A. Each version of the programming board comes with only one socket. See table below.
ORDER NUMBER
DC2293A-A
DC2293A-B
2
DC2293A-A
16-LEAD PLASTIC SSOP
ORDER OPTION A
USB +5V SCL
Figure 2. DC2293A Top Side Details (DC2293A-A Shown)
SUPPORTED DEVICES
LTC2933 16-Lead Plastic SSOP
LTC2933 16-Pin (5mm × 4mm) Plastic DFN
SDA GND
DC2293A-B
16-LEAD PLASTIC DFN
ORDER OPTION B
ASEL0 J2
DC2293 F02
