9.
Release the microphone cable and the wireless antenna cables from the clips (2) built into the
top cover.
CAUTION:
To prevent damage to the display assembly, support it before removing the screws.
10.
Remove the two Torx T8M2.5×6.0 screws (1) that secure the display assembly to the computer.
NOTE:
78
Chapter 4 Removal and replacement procedures
The display assembly will be unsupported when the following screws are removed.
The screw on the left display hinge also secures a display panel cable ground loop (2).
ENWW
