Options - Icom IC-F60V Instruction Manual

8

OPTIONS

D D BATTERY PACK/CASE
• BP-226
BATTERY CASE
Battery case for 5 × AA (LR6) alkaline cells.
• BP-227 -
i on
L I BATTERY PACK
7.2 V/1700 mAh Li-Ion battery pack. The same as supplied with
the transceiver. BP-227 must be charged with the optional BC-
152/BC-119N/BC-121N.
D D CHARGERS
• BC-152
DESKTOP CHARGER
Used for regular charging of the battery pack. The AC adapter,
BC-147, must be purchased separately.
Charging time: approx. 9–10 hours when BP-227 is attached.
• BC-119N
DESKTOP CHARGER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is not supplied
with some versions.
Charging time: approx. 2 to 2.5 hours when BP-227 is attached.
• BC-121N -
MULTI CHARGER
+ BC-157
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-100's are re-
quired) simultaneously. An AC adapter should be purchased sep-
arately.
Charging time: approx. 2 to 2.5 hours when BP-227 is attached.
D D BELT CLIPS
• MB-86
SWIVEL BELT CLIP
• MB-98
BELT CLIP
Exclusive alligator-type belt clip. The same as supplied with the
transceiver.
• MB-96N/MB-96F
LEATHER BELT HANGERS
38
+ BC-147
AC ADAPTER
+ AD-100
CHARGER ADAPTER
+ AD-100 (6 pcs.)
CHARGER ADAPTER
D D DC CABLES
• CP-17L
CIGARETTE LIGHTER CABLE
Allows charging of the battery pack through a 12 V cigarette lighter
socket. (For BC-152/BC-119N)
• OPC-515L/OPC-656
DC POWER CABLES
Allows charging of the battery pack using a 13.8 V power source
instead of the AC adapter.
OPC-515L : For BC-152/BC-119N
OPC-656 : For BC-121N
D D OTHER OPTIONS
• HM-138/HM-168 -
SPEAKER MICROPHONES
Full-sized waterproof (IPX7 waterproof protection) speaker-micro-
phones including alligator type clip to attach to your shirt or collar, etc.
• HS-94/HS-95/HS-97
HEADSET
HS-94 : Ear-hook type
HS-95 : Neck-arm type
HS-97 : Throat microphone
VS-1SC : VOX/PTT switch box for hands-free operation, etc.
*These items are IPX4 waterproof protection. So, the transceiver's wa-
terproofing meets IPX4 when it is connected.
• OPC-966U
INTERFACE CABLE
Provides advanced operation, such as printer, GPS connection for
position data transmission capabilities during BIIS operation.
• FA-S62VS/FA-S63VS/FA-S57US
FA-S62VS: 150–162 MHz FA-S63VS: 160–174 MHz
FA-S57US: 450–490 MHz
• FA-S24V/FA-S59V/FA-S27U/FA-S56U/FA-S74U
FA-S24V: 136–150 MHz FA-S59V: 150–174 MHz
FA-S27U: 400–470 MHz FA-S56U: 450–520 MHz
FA-S74U: 490–520 MHz
Some options may not available in some countries. Please ask your
dealer for details.
OPTIONS
+ VS-1SC
/
VOX PTT CASE
STUBBY ANTENNAS
ANTENNAS
