1. Click the
menu.
2. Select Add in the bottom menu.
3. In the left Type menu, select Period.
4. In the right menu, select Source as CH1.
5. In the right menu, select Add. The period type is added.
6. In the left Type menu, select Frequency.
7. In the right menu, select Source as CH1.
8. In the right menu, select Add. The frequency type is added.
The measured value will be displayed at the bottom left of the screen automatically.

How to Use Autoscale

This is a very useful function for first time users to carry out a simple and quick test on the
input signal. The function is applied to follow-up signals automatically even if the signals
change at any time. Autoscale enables the instrument to set up trigger mode, voltage
division and time scale automatically according to the type, amplitude and frequency of
the signals.
E.g. If you want to measure the signal, you can do as the follows:
1. Click the icon, click Autoscale to turn on. The function menu will appear.
2. In the bottom menu, Select Mode. In the right menu, select
3. In the bottom menu, Select Wave. In the right menu, select
Multicomp-Pro
icon, click Measure to show the automatic measurement function
