Switch horizontal or vertical lines
If vertical lines are selected, drag up and down.
When the C icon appears, in the full screen, swipe left/right to move the selected line.
Click the direction buttons of the C icon to fine-turn, long-press to move continuously.
Click the center "ab" button to select a, b, or a&b.
Control the vertical
cursor line

How to Measure Automatically

Click the icon on the right bottom of the display area, click Measure to display the
menu for the settings of the Automatic Measurements. At most 8 types of measurements
could be displayed on the bottom left of the screen.
The oscilloscopes provide 39 parameters for auto measurement, including Period,
Frequency, Mean, PK-PK, RMS, Max, Min, Top, Base, Amplitude, Overshoot, Preshoot,
Rise Time, Fall Time, +PulseWidth, -PulseWidth, +Duty Cycle, -Duty Cycle, Screen
Duty, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF, Delay A→B , Delay A→B ,
Cycle RMS, Cursor RMS, Phase A→B , Phase A→B , +PulseCount, -PulseCount,
RiseEdgeCnt, FallEdgeCnt, Area, and Cycle Area.
E.g. Measure the period, the frequency of the CH1, following the steps below:
Multicomp-Pro
Switch to select the lines
21
Cursor line
Selected Unselected
