- Page 1 D01236020G US-2x2 US-4x4 USB Audio/MIDI Interface REFERENCE MANUAL Before connecting this unit to a computer, you must download and install dedicated software on the computer.
-
Page 2: Table Of Contents
Connecting with iOS devices ..........12 6 – Using the Settings Panel ......13 Opening the Settings Panel ..........13 Windows ................13 Mac ..................13 Windows Settings Panel overview........13 HOME page ..............13 Settings page ..............14 Custom page ..............15 Mac Settings Panel overview ..........16 TASCAM US-2x2/US-4x4... -
Page 3: Introduction
Since the power supply is insufficient when using the unit connected by USB to an iOS device, however, please o TASCAM is a trademark of TEAC CORPORATION, registered in purchase a separate external power supply device for this the U.S. and other countries. -
Page 4: Names And Functions Of Parts
• Set the phantom power switch to +48V only when using a This knob does not affect the recording level of input signals. condenser microphone that requires phantom power. Turning phantom power +48V when a dynamic mic or other TASCAM US-2x2/US-4x4... -
Page 5: Rear Panel
Speed mode equivalent to USB 2.0 (480 Mbps maximum). • After waking a computer from suspend (sleep) mode, if the unit does not operate properly, turn it off and turn it on again or disconnect and reconnect the USB cable. TASCAM US-2x2/US-4x4... -
Page 6: Installation
“Yes” button. When the Setup Wizard screen appears, click the “Next” 2 GB or more button. Apple iOS devices Supported operating systems iOS 7 or later Supported audio drivers Windows: ASIO2.0, WDM, MIDI Mac: Core Audio, Core MIDI TASCAM US-2x2/US-4x4... -
Page 7: Installing The Mac Dedicated Software
If the unit is still not recognized after a while, open the software installation screen from the notification area at the bottom right of the computer display, and click “Skip obtaining driver software from Windows Update” to stop the search. TASCAM US-2x2/US-4x4... -
Page 8: Working With Gatekeeper
When the Gatekeeper setting is not “Allow applications downloaded from: the Mac App Store” ‘“US-2x2_US-4x4 Installer.dmg” is an application downloaded from the Internet. Are you sure you want to open it?” might appear as a security warning message. In this case, click the “Open” button. TASCAM US-2x2/US-4x4... -
Page 9: Uninstalling The Dedicated Software
Select and double-click “TASCAM US-2x2 & US-4x4 Driver” risks. and “TASCAM US-2x2 & US-4x4 Software Mixer” in the list. If you changed the Gatekeeper setting to decrease security (use one of the lower settings), set it back to the original Then, follow the instructions that appear on the screen. -
Page 10: Preparation
To power this unit when it is connected to an cover) to request repair. iOS device, however, you must connect a TASCAM PS-P520E AC adapter, TASCAM BP-6AA external battery pack or other power supply device to the DC IN 5V connector. In this case, connect the power source to the unit as shown below. -
Page 11: Connections
IN1 or IN2 jack on the front of the unit and set the MIC/LINE recommend connecting this unit to a separate USB port. INST switch for that jack to INST. Connecting USB keyboards and mice, however, to the same bus should not be a problem. TASCAM US-2x2/US-4x4... -
Page 12: Electronic Instruments And Other Audio Equipment
• When using Windows Media Player, if the “Sound and Audio Devices Properties” Control Panel “MIDI music playback (default device)” is set to “Microsoft GS Wavetable SW Synth”, you will not be able to hear MIDI performances through this unit's LINE OUT [BALANCED] or PHONES jacks. TASCAM US-2x2/US-4x4... -
Page 13: Using The Settings Panel
96 kHz). o Using the Finder, open the Applications folder and click Firmware Ver. This is the firmware version used by the “TASCAM US-2x2 & US-4x4 Settings Panel” to open the connected unit. Settings Panel. Device This is the name of the connected unit. -
Page 14: Settings Page
Putting a check (4) in the checkbox will turn the automatic power saving function on so the unit will automatically turn off (enter standby mode). o Removing the check (4) in the checkbox will turn the automatic power saving function off. TASCAM US-2x2/US-4x4... -
Page 15: Custom Page
Home page. NOTE • Turn the MONITOR BALANCE knob on the unit all the way to the right (COMPUTER) to check levels while adjusting the volume sliders. • Double-click a volume slider to reset it to its default value. TASCAM US-2x2/US-4x4... -
Page 16: Mac Settings Panel Overview
When an input is on, signals on that channel will be input. o Turn an input off by removing the check from its checkbox . When an input is off, signals on that channel will not be input. TASCAM US-2x2/US-4x4... -
Page 17: Notification Function
• Put a check (4) in the “Do not show the same message again” checkbox to prevent the same window from being shown the next time it is launched. • After closing the update window, you can reopen it by selecting Help w Update from the menu. TASCAM US-2x2/US-4x4... -
Page 18: Application Guide
• If you still cannot hear sound after making the settings and completing the procedures above, restart the computer. • If you make this setting, sound will be output through this unit, but no sound will be output from the computer’s speakers or headphone jack. TASCAM US-2x2/US-4x4... -
Page 19: Mac Os X And Itunes
Audio Device”) to select it and right-click or control-click it. Then, click “Use this device for sound output” in the pop-up menu. The speaker mark appears next to “TASCAM US-2x2 Audio Device” (or “TASCAM US-4x4 Audio Device”). NOTE To use this device as the recording device, select “Use this device for sound input”... -
Page 20: Standalone Mode
Direct Monitor Settings Input 3-4 : Mono (US-4x4 only) o Audio Input On/Off : All on o Line Outputs 1-2 : MONITOR o Line Outputs 3-4 : MONITOR (US-4x4 only) o ERP2 Setting On/Off : Current setting retained TASCAM US-2x2/US-4x4... -
Page 21: Midi Implementation Chart
All notes off — — Other Thru Active sense — — Reset — — Notes Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO –: YES Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO —: NO TASCAM US-2x2/US-4x4... -
Page 22: Troubleshooting
If you are still unable to resolve a problem, please contact turned all the way to the left (toward INPUT). If that is the case, TASCAM customer support with the following information turn the MONITOR BALANCE knob to the right of center. - Page 23 Sound breaks up or there is noise. Support for Bundled DAW Software The processing load on the computer causes sound to break up TASCAM does not provide end-user support for the bundled and noise to occur. DAW Software. Please check the Help menu of the installed software to find where this support is available.
-
Page 24: Specifications
57 dB Distortion 0.003% or less ( MIC/LINE input to LINE OUT, 1kHz sine wave, at nominal input level and maximum output level, JEITA) Crosstalk 95 dB or more ( MIC/LINE input to LINE OUT, 1 kHz, JEITA) TASCAM US-2x2/US-4x4... -
Page 25: Computer System Requirements
Supported audio drivers Windows: ASIO2.0, WDM, MIDI Mac: Core Audio, Core MIDI o Illustrations in this reference manual might differ in part from the actual product. o Specifications and external appearance might be changed without notification to improve the product. TASCAM US-2x2/US-4x4... - Page 26 TEAC CORPORATION https://tascam.jp/jp/ Phone: +81-42-356-9143 1-47 Ochiai, Tama-shi, Tokyo 206-8530 Japan TEAC AMERICA, INC. http://tascam.com/ Phone: +1-323-726-0303 1834 Gage Road, Montebello, California 90640 USA TEAC MEXICO, S.A. de C.V. http://teacmexico.net/ Phone: +52-55-5010-6000 Río Churubusco 364, Colonia Del Carmen, Delegación Coyoacán, CP 04100, México DF, México TEAC UK Ltd.
