Use & Care
MANUAL
Professional Freestanding Open Burner Gas Ranges
5 SERIES
VGIC5302
VGIC5362
VGIC5482

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VGIC5302 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Viking VGIC5302

  • Page 1 Use & Care MANUAL 5 SERIES Professional Freestanding Open Burner Gas Ranges VGIC5302 VGIC5362 VGIC5482...
  • Page 2: Table Of Contents

    Congratulations Congratulations and welcome to an elite world of ownership. We hope you will enjoy and appreciate the care and attention we have put into every detail of your new, state-of-the-art range. Your range is designed to off er years of reliable service. This Use and Care Manual will provide you with the information you need to become familiar with your range’s care and operation.
  • Page 3: Warnings

    Warnings Warning and Important Safety Instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. Common sense, caution, and care must be exercised when installing, maintaining, or operating the appliance. ALWAYS contact the manufacturer about problems or conditions you do not understand. Recognize Safety Symbols, Words, Labels DANGER Hazards or unsafe practices which WILL...
  • Page 4 Warnings WARNING WARNING WARNING NEVER cover any slots, holes or passages ELECTRICAL SHOCK BURN OR ELECTRICAL in the oven bottom or cover an entire HAZARD SHOCK HAZARD rack with materials such as aluminum DO NOT touch a hot oven light Make sure all controls are foil.
  • Page 5 Warnings Cooking Safety • To eliminate the hazard of reaching over hot surface burners, cabinet storage should not be provided directly above a unit. If storage is provided, it should be limited to items which are used infrequently and which are safely stored in an area subjected to heat from an appliance.
  • Page 6 Warnings Burners •NEVER touch oven bake and broil burner areas or interior surfaces of oven. • Bake and broil burners may be hot even though they are dark in color. Areas near burners and interior surfaces of an oven may become hot enough to cause burns.
  • Page 7: Before Using Range

    Before Using Your Range All products are wiped clean with solvents at the factory to remove any visible signs of dirt, oil, and grease which may have remained from the manufacturing process. Before starting to cook, clean the range thoroughly with hot, soapy water. There may be some burn off and odors on fi rst use of the appliance—this is normal.
  • Page 8: Oven Functions And Settings

    Simmering ensures gentler treatment than boiling to prevent food from toughening and/or breaking up. The size of the pan and the volume of food can have a signifi cant eff ect on how high or low a fl ame is needed for simmering. For this reason, Viking range and rangetop burners are engineered with a Vari-Simmer setting.
  • Page 9: Surface Cooking Tips

    Surface Operation Surface Cooking Tips • Use low or medium fl ame heights when cooking in vessels that are poor conductors of heat, such as glass, ceramic, and cast-iron. Reduce the fl ame height until it covers approximately 1/3 of the cooking vessel diameter. This will ensure more even heating within the cooking vessel and reduce the likelihood of burning or scorching the food.
  • Page 10: Oven Features

    Oven Features Broiler burner Oven lights Oven racks (3) Convection fan Removable bottom Bake burner Rack Positions Each oven is equipped with three tilt-proof racks. All ovens have six rack positions. Position 6 is the farthest from the oven bottom. Position 1 is the closest to the oven bottom.
  • Page 11: Baking

    Baking BAKE (Natural Airfl ow Bake) Full power heat is radiated from the U-shaped bake burners in the bottom of the oven cavity and is circulated with natural airfl ow. This function is recommended for single rack baking. Many cookbooks contain recipes to be cooked in the conventional manner.
  • Page 12 Baking CONVENTIONAL BAKING CHART Food Pan Size Single Rack Temperature Time Position (min.) BREADS Biscuits Cookie sheet 3 or 4 400˚F (204˚C) 10 - 12 Yeast loaf Loaf pan 3 or 4 375˚F (191˚C) 30 - 35 Yeast rolls Cookie sheet 3 or 4 400˚F (204˚C) 12 - 15...
  • Page 13 Baking CONVECTION BAKING CHART Food Pan Size Single Rack Temperature Time Position (min.) BREADS Biscuits Cookie sheet 3 or 4 375˚F (191˚C) 7 - 9 Yeast loaf Loaf pan 3 or 4 375˚F (191˚C) 25 - 30 Yeast rolls Cookie sheet 3 or 4 375˚F (191˚C) 11 - 13...
  • Page 14 Baking Solving Baking Problems Baking problems can occur for many reasons. Check the chart below for the causes and remedies for the most common problems. It is important to remember that the temperature setting and cooking times you are accustomed to using with your previous oven may vary slightly from those required with this oven.
  • Page 15 Broiling BROIL (Infrared Broil) The broil burner at the top of the oven heats the metal screen until it glows. Heat radiates from the GourmetGlo™ infrared broiler located at the top of the oven cavity. The distance between the foods and the broil elements determines broiling speed. For “fast”...
  • Page 16: Broiling

    Broiling Rack Positions for Broiling The broiler uses heat rays to help cook the food. Because these rays travel only in straight lines, the eff ective cooking area of the broiler is reduced when using the higher rack position. At high- rack positions, the rays cannot reach all corners of the broiler grid, so larger pieces of meat might not broil suffi ciently at the outer edges.
  • Page 17: Convection Dehydrate

    Convection Dehydrate Convection Dehydrate This oven is designed not only to cook, but also to dehydrate fruits and vegetables. Warm air is circulated by a motorized fan in the rear of the oven and over a period of time, the water is removed from the food by evaporation. Removal of water inhibits growth of microorganisms and retards the activity of enzymes.
  • Page 18: Cleaning And Maintenance

    Cleaning and Maintenance WARNING BURN OR ELECTRICAL SHOCK HAZARD Make sure all controls are OFF and oven is COOL before cleaning. Failure to do so can result in burns or electrical shock Any piece of equipment works better and lasts longer when maintained properly and kept clean. Cooking equipment is no exception.
  • Page 19: Replacing Oven Lights

    Cleaning and Maintenance Stainless Steel Parts All stainless steel body parts should be wiped regularly with hot soapy water at the end of each cooling period and with a liquid cleaner designed for that material when soapy water will not do the job. DO NOT use steel wool, abrasive cloths, cleansers, or powders.
  • Page 20: Door Removal

    Door Removal Open door completely. Fold latches backward until locked in place. Slowly close until latches stop Lift door up and out. door. Door Replacement Carefully realign door on hinges. Open door completely. Slide in and down. Fold latches forward until locked in place Close door...
  • Page 21: Troubleshooting

    Troubleshooting Problem Possible Cause and/or Remedy Range will not function. Range is not connected to electrical power: Have electrician check power circuit breaker, wiring, and fuses. Broil does not work. Temperature control knob is rotated too far past broil position. Oven light will not work.
  • Page 22: Service Information

    Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact 1-888-845-4641, or write to: VIKING RANGE, LLC PREFERRED SERVICE 111 Front Street Greenwood, Mississippi 38930 Record the information indicated below.
  • Page 23: Warranty

    Freestanding ranges and built-in rangetops and all of their component parts, except as detailed below*, are warranted to be free from defective materials or workmanship in residential housed hold use for a period of two (2) years from the date of original retail purchase. Viking Range, warrantor, agrees to repair or replace at its option, any part which fails or is found to be defective during the warranty period.
  • Page 24 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 662-4551200 For more product information, call 1-888-845-4641 or visit our website at www.vikingrange.com 069749-000B EN (011521)
