DECLARATION OF CONFORMITY
Manufacturer:
Declares that the CE-marked Product:
Product Model(s):
FCC Compliance Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Complies With:
Compliance Standards:
December 18, 2013
CID Bio Science, Inc.
rd
1554 NE 3
Ave
Camas, WA 98607
Model CI-202
89/336/EEC Electromagnetic Compatibility Directive
73/23/EEC Low Voltage Directive
EN 55027
EN 50082-1
EN 60950
Leonard Felix
President
RF Emissions Information
Technology Equipment
EMC Immunity Standard
Safety of Information
Technology Equipment
Including Electrical
Business Equipment
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for CID Bio-Science CI-202
Summary of Contents for CID Bio-Science CI-202
- Page 1 Camas, WA 98607 Declares that the CE-marked Product: Product Model(s): Model CI-202 FCC Compliance Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 2: Table Of Contents
Manual Threshold Adjustment ....................... 12 Set-Up Storage (check space or erase) ..................13 Set-Up Auto Store Parameter ......................14 Calibrating the CI-202 ..........................15 CI-202 Threshold Set-up Procedure ....................15 CI-202 Care ............................... 19 Charging the Battery..........................19 Cleaning ..............................19 THEORY OF OPERATION ........................ - Page 3 Frequently Asked Questions ......................26 CID Hardware Warranty .......................... 29 CI-202 PRODUCTION TEST CHECK SHEET ..................31 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
-
Page 4: Introduction
Congratulations on the purchase of your new CI-202 Portable Leaf Area Meter. Making leaf measurements in the field or laboratory is now very easy with the CI-202 Portable Leaf Area Meter. This state-of-the-art instrument has been designed to be the most portable leaf area measurement system available. -
Page 5: Ci-202 Specifications
CI-202 Instruction Manual rev. 6/21/2017 CI-202 Specifications Scanner: 670 nm Laser Diode Class 3R Laser specifications: Power output of 4.25 mW Max. Measuring Length: 36cm Max. Measuring Width: 150mm Max. Measuring Thickness: 15mm Max. Scanning Speed: 127 mm/second Area Units: Accuracy: ±1% for samples >... - Page 6 CI-202 Instruction Manual rev. 6/21/2017 Ideal for field use Calculates shape factor and aspect ratio Single self-contained instrument with built-in LCD display Samples may be scanned on the scan board. No calibration required 1554 NE 3...
-
Page 7: Operating Instructions
When there are no files to store data to, the measure menu items will not be available. To correct this situation, create a file. The following sections describe the menus and what they do. The CI-202 menu system allows you to quickly and easily operate the instrument without constantly referring to this manual. -
Page 8: View Data
Note: Because of the amount of information displayed on this screen, the CI-202 cannot display any prompts in this mode. file00 area = 44.04 cm... -
Page 9: Manipulate Files
The CI-202 gives an expanded ability to organize data collection by using a file structure similar to that used by personal computers. The CI-202 has up to 256 files available. Select a unique name for each file to control the data stored in each file to optimize the amount of data stored for research that is carried out. -
Page 10: Transfer Data From A File
Transfer Data from a File Data can be downloaded from the CI-202 to a PC at any time the instrument is idle. Plug in the USB cable to both the instrument and the PC and run the CI202dfV1006.exe program on the PC (downloadable on the CID Bio-Science website). -
Page 11: Delete A File
CI-202 Instruction Manual rev. 6/21/2017 Delete a File Pressing START/ENTER when “Delete files” is displayed on the top line indicates the unit is in the delete file mode. This mode will erase a file completely from memory. In this mode, the top line of the display reads “Delete”... -
Page 12: Close A File
PC. Set-Up Instrument The CI-202 has a number of utility functions that allow the user to manage the instrument’s capability. These functions are accessed using the setup mode. When the instrument is in the setup mode, the top line of the display reads “Setup”... -
Page 13: Set-Up Measure Parameter
“all-around” use. Manual Threshold Adjustment First, adjust the threshold with the CI-202 over the reflective tape of the scan board. Select “Setup Scanner” in the display window and press START. Select “HiThrld” and press START again. -
Page 14: Set-Up Storage (Check Space Or Erase)
Press the down arrow to get back to the Measure display. Press both the left and the right arrows at the same time. The CI-202 will turn on the laser for a short period while it measures the width. Press the up arrow and then the ENTER key to get back into the setup scanner menu. -
Page 15: Set-Up Auto Store Parameter
CI-202 Instruction Manual rev. 6/21/2017 In the format storage mode, the top line of the display will read “Clear all data”. The bottom line of the display will have the word “stop” to the left and “enter” to the right. -
Page 16: Calibrating The Ci-202
CI-202, the instrument should have its timing parameters re-computed the next time it is powered on. The CI-202 can require adjustment after extensive use in the field or downloading/updating firmware. The recalibration is very quick and simple. After recalibrating, the high and low thresholds should be checked and readjusted if necessary. - Page 17 CI-202 Instruction Manual rev. 6/21/2017 4) Use the UP or DOWN arrow to get to “Measure Root.” Press SAVE. The screen will flash “measure root saved.” Then the screen will show “Set-up Measure.” 5) Use the RIGHT arrow key to scroll to “Set-up Scanner.” Press ENTER. You will see “HiThld Scan.”...
- Page 18 CI-202 Instruction Manual rev. 6/21/2017 23) The motor will start, and you will see the “t” and “w” settings appear. Use the UP or DOWN arrow keys to adjust your “t” value to your average setting number (from step 21).
- Page 19 52) Once you have calibrated the unit to read the correct measurements of the standard you are ready to take measurements with the CI-202. Re-compute the timing parameters of the CI-202 by pressing the LEFT and RIGHT arrow at the same time from the Measure Menu after adjusting the threshold.
-
Page 20: Ci-202 Care
Storing a battery in a discharged state could permanently damage it. Cleaning Treat the CI-202 as any other fine optical instrument. Keep the lens clean and free from scratches. When not in use, keep the instrument in its protective case. Use only a mild detergent and damp cloth to clean the exterior areas of the instrument. -
Page 21: Theory Of Operation
Overview of the Parts of the Instrument The CI-202 consists of a number of sub-systems. It has a laser width scanner that is capable of measuring the width of an object in its objective 500 times a second to a resolution of 0.1 mm. -
Page 22: Computing Aspect Ratio And Shape Factor Information
CI-202 Instruction Manual rev. 6/21/2017 Computing Aspect Ratio and Shape Factor Information Aspect ratio and shape factor information can be easily determined from other calculated values. These derived quantities are not stored but calculated, whenever necessary, for the purposes of display or data dumping. The calculations used are shown below. -
Page 23: Troubleshooting
TROUBLESHOOTING Updating the Firmware If the firmware on the CI-202 needs to be updated or is deleted, follow the steps below to reload the firmware onto the CI-202. 1. Download the ‘CI-202 Firmware UpdateV308 and Driver.zip’ from the software page: https://www.cid-inc.com/support/CI-202/software/... -
Page 24: Troubleshooting The Libusb.dll Error
Troubleshooting the LIBUSB.dll Error The LIBUSB.dll error is typically encountered when trying to install the software and CI-202 to transfer data to a 64-bit computer system. 1. Run a Google search for LIBUSB windows (your operating system) Example: “LIBUSB Windows XP”... - Page 25 6. Find the device in the list of USB devices: it will most likely be named a set of numbers, such as 0425:0500: if you can’t determine which device is the CI-202, unplug it from the computer and see which one disappears.
-
Page 26: Technical Support
CI-202 Instruction Manual rev. 6/21/2017 Technical Support If you have a question about the CI-202 features and functions, first look in the CI-202 Instruction Manual. Further questions can also be directed to a Technical Support Representative located in your country. CID Bio-Science, Inc. is committed to provide customers with high quality, timely technical support. -
Page 27: Frequently Asked Questions
Save key. 5. What is the resolution? a. The CI-202 with filter turned off is able to reliably detect objects up to 0.2mm across. Be aware the CI-202 does not process pixels, all measurements are done based on scan times to the edges of the physical object. - Page 28 CI-202 Instruction Manual rev. 6/21/2017 menu. If the wall charger is used, an internal circuit will control charging. No inputs are required from the user and faster charging occurs if the unit is turned off. If the unit is connected to a computer USB port, the unit should be turned on to make use of the full charging current available.
- Page 29 CI-202 Instruction Manual rev. 6/21/2017 3. Switch off the filter 4. Run manual scan while observing "W" value 5. Set filter value as average "W"-1 and turn filter on 6. Run High Threshold and then Run Low Threshold 7. Set threshold as average high/low in manual scan mode 8.
-
Page 30: Cid Hardware Warranty
Repair or alteration by an unauthorized technician voids warranty. Material and equipment which is not manufactured by CID Bio-Science is to be covered only by the warranty of its manufacturer. CID Bio-Science will not be liable to the Buyer for loss, damage, or injury to persons or to property by the use of equipment manufactured by other companies. - Page 31 CI-202 Instruction Manual rev. 6/21/2017 CID Bio-Science is responsible for return shipping charges on repairs and/or replacement covered by warranty. 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914 sales@cid-inc.com http://www.cid-inc.com...
-
Page 32: Ci-202 Production Test Check Sheet
CI-202 Instruction Manual rev. 6/21/2017 CI-202 PRODUCTION TEST CHECK SHEET SERIAL NUMBER: THRESHOLD SET: PRECHARGE: SCAN WIDTH: SCAN TIME: STEP LENGTH: NOTES: 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914 sales@cid-inc.com http://www.cid-inc.com... - Page 33 CI-202 Instruction Manual rev. 6/21/2017 1554 NE 3 Ave, Camas, WA 98607, USA Phone: (360) 833-8835 Fax: (360) 833-1914 e-mail: sales@cid-inc.com Web: www.cid-inc.com PRODUCT REGISTRATION CARD Please complete and return this form to CID within 30 days to validate your Warranty on Parts and Labor.
- Page 34 CI-202 Instruction Manual rev. 6/21/2017 2. What other competing brands did you consider? __________________________ 3. Where did you first learn of this product? □ Advertisement in ________________________________ □ Representative □ Friend/Colleague □ Exhibit □ Other _________________________________________ 4. Who selected this product? □...
