CID Bio-Science CI-203CA Instruction Manual

Hide thumbs Also See for CI-203CA:
Table of Contents

Advertisement

Quick Links

Download this manual
DECLARATION OF CONFORMITY
Manufacturer:
Declares that the CE-marked Product:
Product Model(s):
FCC Compliance Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Complies With:
Compliance Standards:
December 18, 2013
CID Bio Science, Inc.
rd
1554 NE 3
Ave
Camas, WA 98607
Model CI-203
Model CI-203CA
89/336/EEC Electromagnetic Compatibility Directive
73/23/EEC Low Voltage Directive
EN 55027
EN 50082-1
EN 60950
Leonard Felix
President
RF Emissions Information
Technology Equipment
EMC Immunity Standard
Safety of Information
Technology Equipment
Including Electrical
Business Equipment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CI-203CA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CID Bio-Science CI-203CA

Summary of Contents for CID Bio-Science CI-203CA

  • Page 1 Declares that the CE-marked Product: Product Model(s): Model CI-203 Model CI-203CA FCC Compliance Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    CI-203 Instruction Manual rev. 8/9/2016 DOCUMENT OVERVIEW DOCUMENT OVERVIEW............................1 INTRODUCTION................................. 4 Specifications ............................4 Features ..............................4 OPERATING INSTRUCTIONS ..........................6 Menus and What They Do ........................7 MEASURE MENU............................... 8 SETUP INSTRUMENT MENU ..........................10 Setup AutoSave Feature ........................10 Setup Measure .............................
  • Page 3 Technical Support ..........................31 Customer Service ..........................31 Error Message ............................32 Frequently Asked Questions ......................33 APPENDIX I: OPERATING THE CI-203 LASER LEAF AREA METER WITH THE CI-203CA CONVEYOR ATTACHMENT ................................36 Hardware Setup ........................... 36 Measure ..............................40 CI-203 Conveyor Calibration ......................
  • Page 4 Unavailable Parameters ........................42 Setup Scanner Threshold ........................42 APPENDIX II: RESOTRING SET-UP DATA FOR THE CI-203 ................. 43 Restoring Set-Up Data for the CI-203CA Conveyor Attachment..........44 WARRANTY INFORMATION ..........................45 CI-203 PRODUCTION TEST CHECK SHEET ..................... 46 WARRANTY REGISTRATION CARD ........................48...

  • Page 5: Introduction

    CI-203 Instruction Manual rev. 8/9/2016 INTRODUCTION Congratulations on the purchase of your new CI-203 Portable Laser Area Meter. Making leaf measurements, in the field or laboratory, is now very easy with the CI-203 Portable Laser Area Meter. This state-of-the-art instrument has been designed to be the most portable leaf area measurement system available.
  • Page 6 CI-203 Instruction Manual rev. 8/9/2016  Records GPS location of measurement  Area resolution down to 0.01 cm  Unlimited storage capacity (replaceable 4GB SD card)  USB port for viewing/copying files, upgrading firmware and debugging the output  Supports USB mass-storage device class ...

  • Page 7: Operating Instructions

    CI-203 Instruction Manual rev. 8/9/2016 OPERATING INSTRUCTIONS The CI-203 is a self-contained, hand-held, battery-powered instrument with a built-in display. It contains an optical scanner to measure leaf width, a roller with a shaft encoder to measure length, and a microcomputer to coordinate the measurement functions, calculate results, and store collected data.

  • Page 8: Menus And What They Do

    CI-203 Instruction Manual rev. 8/9/2016 Error messages should rarely appear during normal operation of the CI-203. However, in the event that the display does not show the “Measure” prompt after displaying the copyright notice, see the Error Message section of this manual. Note: To force a power off and reset of the instrument at any point, a user may press and hold the POWER button for 10 seconds.

  • Page 9: Measure Menu

    CI-203 Instruction Manual rev. 8/9/2016 MEASURE MENU In the measure mode, the top line of the screen will read “Measure” on the left with the name of a file on the right. The bottom line of the screen will have the word “arm” in brackets on the left, and the four direction arrows on the right.
  • Page 10 CI-203 Instruction Manual rev. 8/9/2016 To bring an image into view, press the RIGHT arrow key. Pressing the RIGHT arrow key again will display the barcode data. Pressing the LEFT arrow key from any screen will return the instrument to the ready to measure mode. To discard the last measurement, press the STOP button.

  • Page 11: Setup Instrument Menu

    CI-203 Instruction Manual rev. 8/9/2016 SETUP INSTRUMENT MENU The CI-203 has a number of utility functions that allow the user to manage the instrument’s capabilities. These functions are accessed by pressing the RIGHT arrow when Setup is highlighted on the Main Menu. The setup utility options are: Autosave, Measure, Scanner, Storage, Time and SDcard.

  • Page 12: Threshold Adjustment (Width Calibration)

    CI-203 Instruction Manual rev. 8/9/2016 The CI-203 automatically adjusts an internal threshold to a level that is optimum for detecting the presence of a leaf in the scanner objective. If out-of-the-ordinary measurements are being recorded or if the instrument has suffered from abuse or excessive aging, the manual threshold setting may need to be adjusted.

  • Page 13: Calibration Of The Scanner Length

    Make sure to check the width reading with and without the filter. When checking the reading without the filter, the width should be above 0 but still a very small value. If the instrument malfunctions after manual threshold adjustment, contact CID Bio-Science, Inc. for assistance.

  • Page 14: Setup Scanner Filter

    CI-203 Instruction Manual rev. 8/9/2016 Setup Scanner Filter The scanner filter is used to filter out particles on the conveyor cylinder that may be mistaken as objects to be measured. Press the RIGHT arrow when Filter is highlighted to see the current filter settings and whether it is turned on or off.

  • Page 15: Setup Storage (Spi Flash Management)

    CI-203 Instruction Manual rev. 8/9/2016 Scan time 40787 Scan time should be in the  <stop> 40xxx to 41xxx range. At the ‘Step Len’ (step length) selection, press the RIGHT. Use the UP/DOWN arrow to change the step length value in the upper right corner. Press ENTER to increase the step length value to the maximum of 900.

  • Page 16: Format Storage

    CI-203 Instruction Manual rev. 8/9/2016 CI-203 uses only special files with the removable SDcard. Without the SDcard inserted, the instrument is still able scan an object, but cannot store or save the measurement. space = 128K Format Storage Pressing the UP/DOWN key switches the display to the “format storage” mode screen. Be careful! Formatting the storage space of the CI-203 will erase all data and all files.

  • Page 17: Setup Sdcard

    CI-203 Instruction Manual rev. 8/9/2016  <stop> <save> 14:40:32 04:02:12 Setup SDcard The Setup SDcard menu selection is only accessible by CID technicians. 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914 sales@cid-inc.com http://www.cid-inc.com...

  • Page 18: View Menu

    CI-203 Instruction Manual rev. 8/9/2016 VIEW MENU The View Menu can be accessed from the main menu screen by pressing the RIGHT arrow key when “View” is highlighted on the display. This menu allows the user to navigate to and view the files or data saved on the instrument, as well as check on many features of the CI-203.

  • Page 19: Gps System Features

    The View Voltage screen shows the current voltage of the instrument and the View Battery displays the percent battery life left. The View Flash option is only accessible by CID Bio-Science technicians. The View Time screen displays the current time on the instrument. The View GPS screen displays the current GPS values for latitude, longitude, altitude and indicates the number of satellites currently connected to.
  • Page 20 CI-203 Instruction Manual rev. 8/9/2016 The View SDcard screen indicates if an SDcard is present in the unit. If no SDcard is in the instrument, or if the SDcard is not fully inserted, “no” will appear in the display next to SDcard. 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914...

  • Page 21: File Menu

    CI-203 Instruction Manual rev. 8/9/2016 FILE MENU The File Menu is accessed by highlighting “File” on the Main Menu and pressing the RIGHT arrow key. Here, the user can manipulate files on the CI-203, with options to clear, delete, create and open files. The CI-203 uses an SDcard to store all measurements.

  • Page 22: Create A File

    CI-203 Instruction Manual rev. 8/9/2016 Create a File Press the RIGHT arrow when “Create” is highlighted on the display to get the unit into the create files mode. The top line of the screen will read “Name” on the left, and a file name (e.g. “file00”) on the right.

  • Page 23: Transfer Data To A Computer

    CI-203 Instruction Manual rev. 8/9/2016 duplicate name <enter> The CI-203 will save all parameters for each measurement (width, length, perimeter, area, aspect ratio, and shape factor) on the SDcard. Use the LEFT/RIGHT arrows to scroll through the parameters and the UP/DOWN arrows to include or exclude parameters. Once finished creating the file name and setting parameters, press the ENTER key.

  • Page 24: Wireless Transfer

    CI-203 Instruction Manual rev. 8/9/2016 Figure 6. SDcard and USB cable connection for CI-203 Do not connect the USB cable to the instrument and the computer while performing measurements. If the user tries to operate the instrument through the computer, the files are subject to becoming out of sync, breaking alignment and causing errors in the files.
  • Page 25 CI-203 Instruction Manual rev. 8/9/2016 FlashAir™ For more information on the Toshiba W-03 Wireless SD Memory Card, contact the application vendor at https://www.toshiba.co.jp/p-media/wwsite/contact.htm, 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914 sales@cid-inc.com http://www.cid-inc.com...

  • Page 26: How Data Appears In A File

    CI-203 Instruction Manual rev. 8/9/2016 How Data Appears in a File Data saved by the instrument during measurement can be viewed later on a computer using a spreadsheet program. Fifteen different columns of data will be seen in the downloaded or transferred file, including the date (month/day/year), time of measurement (hour/minute/second), area, length, width, perimeter, ratio, factor, voids, latitude, longitude and altitude.

  • Page 27: Theory Of Operation

    CI-203 Instruction Manual rev. 8/9/2016 THEORY OF OPERATION Overview of the Parts of the Instrument The CI-203 consists of a number of sub-systems. It has a laser width scanner that is capable of measuring the width of an object in its objective 500 times a second to a resolution of 0.1 mm.

  • Page 28: Computing Aspect Ratio And Shape Factor Information

    CI-203 Instruction Manual rev. 8/9/2016 If the width measurement reaches zero and the instrument is not operating as part of the conveyer attachment, the measurement stops and is displayed. Computing Aspect Ratio and Shape Factor Information Aspect ratio and shape factor information can be easily determined from other calculated values.

  • Page 29: Care And Cleaning

    CI-203 Instruction Manual rev. 8/9/2016 CARE AND CLEANING Treat the CI-203 as any other fine optical instrument. Keep the lens clean and free from scratches. When not in use, keep the instrument in its protective case. Use only a mild detergent and damp cloth to clean the exterior areas of the instrument.

  • Page 30: Ci-203 Firmware Upgrade

    CI-203 Instruction Manual rev. 8/9/2016 CI-203 Firmware Upgrade Occasionally, firmware updates are released to correct bugs or problems found. The firmware of the instrument is tied to the hardware and serial number of the unit. All firmware updates are categorized by serial number, so be sure to check that you are installing the proper firmware file (.bin).

  • Page 31: Ci-203 Driver Installation

    CI-203 Instruction Manual rev. 8/9/2016 CI-203 Driver Installation There are two driver files (CI-203.inf and CI-203.cat) on the CD or that need to be downloaded http://www.cid-inc.com/leaf-area/ci-203-software.php If you need to install the CI-203 USB drivers on a Windows computer, you can use the software that was sent with the CI-203 or go to: http://sourceforge.net/projects/libusb-win32/files/libusb-win32-releases/1.2.4.0/libusb-win32-bin-1.2.4.0.zip/download The libusb-win32-bin-1.2.4.0.zip should be unzipped in your Documents folder and the .inf file...

  • Page 32: Troubleshooting

    Customer Service Customer Service Representatives answer questions about specifications and pricing, and sell all of the CID Bio-Science, Inc. products. Customers sometimes find that they need CID Bio-Science, Inc. to upgrade, recalibrate or repair their system. In order for CID Bio-Science, Inc.

  • Page 33: Error Message

    CI-203 Instruction Manual rev. 8/9/2016 Error Message The following error messages should rarely appear in normal operation. If they do appear, see Appendix III and follow the steps to restore the setup data. MESSAGE: MEANING: Instrument setup data has been lost. Pressing the START key will restore default values and display the message “NVRAM Bad NVRAM Checksum <start>...

  • Page 34: Frequently Asked Questions

    CI-203 Instruction Manual rev. 8/9/2016 Frequently Asked Questions 1. Where do I download the most current version of CI-203 software? The latest version of software and the driver can be downloaded at www.cid- inc.com/Software/CI-203. This webpage has links for CI-203 transfer software, USB driver and firmware downloads.
  • Page 35 Rec_Length has length of image information. 8. What do I do if the leaf length isn’t accurate? If your CI-203 or CI-203CA is not measuring length accurately, you may be losing the length value for either or both of the following reasons: a) You may not be pulling the longest portion of the leaf exactly perpendicular to the roller.
  • Page 36 CI-203 Instruction Manual rev. 8/9/2016 There are two commonly used ways to transfer data from a CI-203 with an SDcard. The first is to connect the CI-203 to a computer using the USB cable. Typically, the computer’s “Autoplay” will pop-up with a message asking what to do with the “Removable Device.”...

  • Page 37: Appendix I: Operating The Ci-203 Laser Leaf Area Meter With The Ci-203Ca Conveyor Attachment

    (see Figure 7). Orient the CI-203 so that the display will be lined up with the notch on the housing of the CI-203CA. Once this is done, insert the CI-203 all the way into the hole in the side of the CI-203CA. Confirm that the CI-203 is inserted into the CI-203CA all the way by verifying that the housing on the CI- 203CA covers the left edge of the display.
  • Page 38 CI-203 Instruction Manual rev. 8/9/2016 Figure 8. Insert the CI-203 into the housing (hole) in the side of the CI-203CA. 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914 sales@cid-inc.com http://www.cid-inc.com...
  • Page 39 2. 2. Connect a suitable 9V DC power source, such as the AC adapter supplied by CID Bio- Science, Inc., to the power input socket on the back of the CI-203CA. Figure 10. The RS232 port and the Power Jack of the CI-203CA.
  • Page 40 CI-203 Instruction Manual rev. 8/9/2016 3. Press the power switch on the CI-203CA (see Figure 10) to the ON position. Note: The CI-203/CI-203CA combination must be turned on with the switch for the CI-203CA in order to take measurements! Anytime a CI-203 is reinserted into the conveyor, or if any problems are encountered, press the right and left buttons simultaneously.

  • Page 41: Measure

    To view the measurements, see the View Menu section of this manual. Note: To properly power down the conveyor power off the CI-203 and then secondly, power off the CI-203CA. 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914...

  • Page 42: Ci-203 Conveyor Calibration

    CI-203 Instruction Manual rev. 8/9/2016 CI-203 Conveyor Calibration A new CI-203 needs to be calibrated to the conveyor. Put the 203 in the conveyor, plug the conveyor in and turn on the conveyor. If you have more than 1 CI-203 or update the firmware, the instrument and conveyor should be re-calibrated together.

  • Page 43: Setup Instrument

    There are some operating modes which are not available to the user when the CI-203CA is being used. The user does not have access to the menu options for the CI-203CA when the CI- 203 is being used. The threshold setting is available only when the CI-203CA is being used (at the same time, the hand-held threshold setting is not available).

  • Page 44: Appendix Ii: Resotring Set-Up Data For The Ci-203

    CI-203 Instruction Manual rev. 8/9/2016 APPENDIX II: RESOTRING SET-UP DATA FOR THE CI-203 “Leaf Not cal’ed” or “Bad NVRAM Checksum <start>”. If the display has the message: “Leaf Not cal’ed” or “Bad NVRAM Checksum <start>”, the instrument may have lost the setup data. To correct this, in the same display window, press START.

  • Page 45: Restoring Set-Up Data For The Ci-203Ca Conveyor Attachment

    After checking the above figures, press “stop” and “stop” again. If you have made changes, it will ask if you want to save changes. Press “save”. Restoring Set-Up Data for the CI-203CA Conveyor Attachment “Conveyor Not Cal’ed <start> To restore setup data in the conveyor, plug the CI-203 into the conveyor and switch on the conveyor power.

  • Page 46: Warranty Information

    Material and equipment which is not manufactured by CID Bio-Science is to be covered only by the warranty of its manufacturer. CID Bio-Science will not be liable to the Buyer for loss, damage, or injury to persons or to property by the use of equipment manufactured by other companies.

  • Page 47: Ci-203 Production Test Check Sheet

    CI-203 Instruction Manual rev. 8/9/2016 CI-203 PRODUCTION TEST CHECK SHEET SERIAL NUMBER: TESTING FUNCTION THRESHOLD: H THRESHOLD SET: PRECHARGE: SCAN WIDTH: SCAN TIME: STEP LENGTH: NOTES: CONVEYOR AND/OR ROOT LENGTH THRESHOLD SET: SCAN WIDTH: SCAN TIME: PRECHARGE: STEP LENGTH: ROOT LENGTH 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914...
  • Page 48 CI-203 Instruction Manual rev. 8/9/2016 THRESHOLD SET: SCAN WIDTH: SCAN TIME: PRECHARGE: STEP LENGTH: 1554 NE 3 Ave, Camas, WA 98607, USA Phone (360) 833-8835 Fax (360) 833-1914 sales@cid-inc.com http://www.cid-inc.com...

  • Page 49: Warranty Registration Card

    CI-203 Instruction Manual rev. 8/9/2016 WARRANTY REGISTRATION CARD 1554 NE 3 Ave, Camas, WA 98607, USA Phone: (360) 833-8835 Fax: (360) 833-1914 e-mail: sales@cid-inc.com Web: www.cid-inc.com PRODUCT REGISTRATION CARD Please complete and return this form to CID within 30 days to validate your Warranty on Parts and Labor.
  • Page 50 CI-203 Instruction Manual rev. 8/9/2016 2. What other competing brands did you consider? __________________________ 3. Where did you first learn of this product? □ Advertisement in ________________________________ □ Representative □ Friend/Colleague □ Exhibit □ Other _________________________________________ 4. Who selected this product? □...
