For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM4619E
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 5
(Included)
Rev: 18-08-28
Advertisement
Table of Contents
Related Manuals for Furniture of America CM4619E
Summary of Contents for Furniture of America CM4619E
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM4619E ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 10pcs Bolts Ø1/4" x 5/8" #2 x 1pc #B x 6pcs Middle Side Frame Levelers Ø1/4"...
- Page 4 Attach levelers (#B) to the side frames (#3), then adjust the levelers (#B) according to ground level. #B x 2pcs Attach levelers (#B) to the middle frame (#2), then adjust the levelers (#B) according to ground level. #B x 2pcs Page 4 of 5...
- Page 5 Secure frames (#2,3) onto top (#1) by using bolts (#A). #A x 10pcs Page 5 of 5...
