For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM4618C
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 5
(Included)
Rev: 18-08-28
Advertisement
Related Manuals for Furniture of America CM4618C
Summary of Contents for Furniture of America CM4618C
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM4618C ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 12pcs Top Panel Bolts Ø1/4" x 1/2" #2 x 1pc #B x 8pcs Bolts Ø1/4"...
- Page 4 Align cross bars (#4) to side frame (#3), then secure by using bolts (#A). #A x 6pcs Secure cross bars (#4) to the other frame (#3) by using bolts (#A). #A x 6pcs Page 4 of 5...
- Page 5 Align top and lower panel (#1,2) to the frame, then secure by using bolts (#B). #B x 8pcs ASSEMBLY IS COMPLETED Page 5 of 5...
