User Manual Dishwasher HDW15V2/ HDW15V3 Models...
Page 2
Thank you for purchasing a Haier pro Please read these instructions carefully before using this appliance. The instructions contain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.
Content Safety ....................3 Product Description ............... 5 Control Panel ................. 6 Programmes ................... 9 ................Daily Use ..................14 Care and Cleaning ................ 24 Troubleshooting ................26 Economic and Environmental Use ..........29 Installation ..................30 Technical Data ................34 Customer Service ................
Safety Intended Use The appliance is designed for domestic use inside the house. It is not intended for commercial or industrial use. Do not use it for purposes other than that for which it was designed. may cause hazards and loss of warranty claims. Standards and Directives This product meets the requirements of all applicable EC directives with the corresponding harmonised standards, which provide for CE marking.
Page 5
Safety During Daily Use Do… supervise children to prevent them playing with the appliance. put sharp pointed objects (e.g. knives) in a way that there is no danger of injury. Do not… open the door while a programme operates. The appliance can release hot steam.
Product Description Thermo dry Rating label Top spray Cutlery basket Upper spray arm Lower basket Lower spray arm Upper basket Filters Knife rack Rinse aid dispenser Detergent dispenser Accessories Check the accessories and literature in accordance with this list: water inlet hose U-support User manual 2) Applicable to models HDW15V3.
Control Panel HDW15V2W1/S1 : 1. ON / OFF button START / PAUSE button PROGRAMME Touch button Time & Info Display/Indicator Icon Option Indication Status Indication HDW15V3W1/S1 : 1. ON / OFF button START / PAUSE button PROGRAMME Touch button Time & Info Display Option Indication Status Indication...
Page 8
Control Panel Time & Info display like Programme cycle time ► Programme start delay time ► Error codes and service information ► Remaining time in hours of a delayed programme starts, e.g. ► Remaining programme cycle time in hours + minutes, e.g. ►...
Page 9
Control Panel Option Indication You can delay the start of a programme in 1 hour steps up to 24 hours. Check the according paragraph under “Daily Delay start use”. To activate or cancel Child lock , press and hold Child Lock until the Child lock indicator comes on or turn off.
Programmes Non-delicate: Light to heavy soil: Dinnerware, cutlery, Casseroles, sauces, potatoes, pots and pans pasta, rice, roasted or fried food Auto Non-delicate: Heavy soil: Casseroles, sauces, potatoes , Dinnerware, cutlery, rice, roasted or fried f ood pasta, pots and pans Heavy Normal soil: Non-delicate:...
Page 11
Programmes On HDW15V3 models Light or fresh soil: Non-delicate: Soups, eggs, sauces, potatoes, Dinnerware, pasta, rice, roasted or fried food cutlery Saving Mixed soil: Non-delicate: Coffee, cake, milk, cold drinks, Dinnerware, cutlery, salad, sausages, casseroles, glassware sauces, potatoes, pasta, rice, pots and pans Pre-Rinse roasted or fried food...
Page 12
First Steps Remove all packaging materials, keep them out of children’s reach and dispose them in an environmentally friendly manner. There could be water residue inside the appliance due to quality checks in the factory. Perform the following steps: 1. Install the appliance. Refer to section INSTALLATION.
Page 13
Different Settings for Rinse Aid Rinse aid is added during the last rinsing phase to dry the dishes without streaks and stains. Detergent (e.g. powder, tablets, ...) requires separate rinse aid: Factory default setting: . No settings are necessary. The rinse aid is added from the rinse aid dispenser only. Detergent with multifunction (e.g.
Page 14
How to Adjust Settings To adjust the Rinse Aid level 1. The appliance is switched off. 2. Press and hold a bout 3 seconds until The display shows the current Rinse Aid setting (the default is ► to change the Rinse Aid setting Press in steps between (minimum dispense) and...
Daily Use Please note that not all sales models comes with identical features and options. So pictures of that chapter are sometimes different to your dish- washer model. Explanations try only to point out basic model variants. Load the baskets. Press the ON/OFF button to activate the appliance.
Page 16
Daily Use Load the Baskets With delicate glasses and porcelain make sure they are labelled dishwasher-proof. Do not put in the appliance items made of wood, horn, aluminium, pewter and copper. Do not put in the appliance items that can absorb water (sponges, household cloths).
Page 17
Daily Use The lower basket has folding spikes. HDW15V2 and HDW15V3: Fold down these spikes to improve arrangement of pots, pans and bowls. Cutlery Basket Mix spoons with other cutlery to HDW15V2: prevent them to bond together. Use the grid element in order to separate the cutlery.
Page 18
Daily Use Upper Basket and utensil tray Utensil tray The upper basket is designed to hold HDW15V2: ► items like glasses, cups, saucers, plates, small bowls and shallow pans. Use the utensil tray to securely hold ► long or sharp items like knives, chopsticks, or ladles.
Page 19
Daily Use Model with lever for easy height adjustment of the upper basket. HDW15V2 / HDW15V3 : Lift the basket 1. Pull out the upper basket. 2. Hold the basket on both sides on the edge above the lever. 3. Lift the basket till you hear a click. 4.
Page 20
Daily Use The third Basket The third basket can be pulled out, it is easy to put down and take out the cutlery. Depending on the model, you can take out the third basket. Depending on the model, you can take out the left and right side shelves to provide more room for taller goblet.
Page 21
Daily Use Detergent Please use only a dedicated dishwasher detergent and follow the related instructions and dosage on its package. 1. If the lid is closed press the release button (A) to open the lid. 2. Put any detergent into compart- ment (B).
Page 22
Daily Use Start a Programme 1. Close the door. 2. Press the ON/OFF button and then the required Press the program button you want to select programme indicator lights up. 4. If desired select a start time for a delay start. Refer to section START A PROGRAMME WITH DELAY.
Page 23
Daily Use the additional function indicates that the icon will be lit, and if it cannot be matched, it will not be lit. If the currently selected washing procedure is rapid washing, washing and single rinsing, press the and add the button, the washing time can be increased by 10 minutes at a time ,up to three times .
Page 24
Daily Use Cancel Start Delay / Programme Press the ON/OFF button for about 1 second. The start delay is cancelled. The programme is aborted. The appliance is switched off. Start a new programme and a delayed start if desired. CAUTION! If a programme will be aborted in the process of washing dishes, the residue of detergent remains on the dishes.
Care and Cleaning Inspect and clean your appliance at regular intervals. Basically any detergent Care and Cleaning the Filters A anticlockwise and remove it. A press the latches and unplug A1 from A2. B to its initial posi- tion. A and put it into B.
Page 26
Care and Cleaning Care and Cleaning of the Spray Arms Spray arms should be regularly inspected for dirt. If needed the spray arms could be removed. Upper spray arm 1. Turn bayonet socket to the left to remove spray arm. 2.
Troubleshooting expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service CAUTION! Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket. trical experts, because improper repairs can cause considerable consequential damages.
Page 28
Troubleshooting Error codes on the display Problem Possible cause Possible solution Acoustic alarm, Water tap is closed. • Open the water tap. display shows Note: Whenever Error ‘ ’ is solved switch off the appliance ALARMCODE and restart the programm. The appliance does Water inlet hose has a kink or Make sure that the position of...
Page 29
Troubleshooting Washing Results are not satisfactory Problem Possible cause Possible solution The dishes are not Filters are clogged. clean. Filters are not correctly assem- bled and installed. correctly assembled and installed. Spray arms are clogged. Remove remaining food remnants with a thin pointed object. Programme was not applicable Make sure that the programme is for the type of load and food...
Troubleshooting Problem Possible cause Possible solution Dry water drop Rinse aid dosage is too low. Increase the released quantity of rinse aid. stains on glasses Refer to section DIFFERENT SETTINGS and dishes. FOR RINSE AID. Quality of rinse aid or Multitab. Cleaning product too old; change the product.
Installation WARNING! Any i refer to section SAFETY. Free Standing Installation 1. Install the appliance on solid ground. Adjust accurately all feet INFORMATION! Only with a correct level the appliance door closes and seals correctly. Installation under Worktop 1. The dimensions of the recess should at least agree with the dimensions in 2.
Page 32
Installation Fresh Water Connection IMPORTANT! The appliance should be connected to the water main using the new water >10mm inlet hose supplied. Old hoses should not be used. Do not shorten the inlet hose. fig.A Take note of water connection requirements. The dishwasher has a single valve water connection.
Page 33
Installation Some models are fitted with an “Aquastop” water supply hose (see fig.B) in which the small filter is already housed in the threaded end. fig.B Anti-Flooding protection The dishwasher is equipped with a system that stops the supply of water in the event of a problem with the water supply hose, or leaks within the unit, in order to prevent damage to your home.
Page 34
Installation Drain Water Connection Fix the water drain hose properly to the piping. The hose has to reach at one point a height between 400 and 850 mm above the appliance bottom line! An extension hose for the water drain hose must not exceed a total length of 4 m and must have the same diameter as the water drain hose.
Rated capacity in standard -place settings Mains water pressure 0.03-1 MPa (= 0.3-10 bar) Power voltage 220-240 V (50Hz) 220-240 V (50Hz) Maximum current intensity 10 A Total absorbed power 1720-2050 W 1720-2050 W Colour White HDW15V2W1 /HDW15V2S1 /HDW15V3W1/HDW15V3S1 Stainless Steel...
Customer Service We recommend our Haier Customer Service and the use of original spare parts. TROUBLESHOOTING. your local dealer or the Service & Support area at www.haier.com.au or at www.haier.co.nz To contact our Service, ensure that you have the following data available.
Standards Test Wash programme When the programme is finished, open the door 100mm to help with drying Powdered detergent quantities 5 g pre-wash + 28.75 g main wash Rinse aid dosage level (HDW15V2 model ) Maximum number of place settings Height adjustment of upper basket Ensure the upper basket is in its upper most position...
Page 38
Standards Test Wash programme When the programme is finished, open the door 100mm to help with drying Powdered detergent quantities 5 g pre-wash + 28.75 g main wash Rinse aid dosage level (HDW15V3) Maximum number of place settings Height adjustment of upper basket Ensure the upper basket is in its lower most position Recommended loading patterns...
