SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electrical shock or death. • This appliance must be earthed. This appliance has a cord with an equipment-earthing conductor and an earthing plug. The plug must be plugged into an appropriate outlet that is installed and earthed in accordance with all local regulations.
SAFETY AND WARNINGS Servicing Do not repair or replace any part of the appliance unless specifically recommended in this guide. All other servicing should be undertaken by a Haier trained and supported service technician or qualified person. Installation Ensure all water connections are turned OFF. It is the responsibility of the plumber and electrician to ensure that each installation complies with all Codes and Regulations.
SERVICE ACCESS We recommend locating the service holes on either side of the Dishwasher as shown. If the holes are created through wood, ensure the edges are smooth and rounded If the holes are created through metal, ensure an edge protector is fitted. REAR WALL FLOOR...
Page 10
PLUMBING AND ELECTRICAL CONSIDERATIONS Left Side Right Side Length of drain hose 1480 1150 Length of power cord* 1450 Length of inlet hose 1450 1300 Distance from floor to top of hose support Max 850 Max 850 Minimum distance from floor to end of drain hoses** Minimum inlet hose radius *excluding plug **standpipe install illustrated.
Page 11
PLUMBING AND ELECTRICAL CONSIDERATIONS Hose and cord lengths Your services can be installed to either the left-hand or right-hand side of the product in an adjacent cabinet. Refer to 'Cabinetry preparation' for service access requirements. The drain hose should not extend more than 4m. A longer drain hose will cause reduced performance. Water connection The dishwasher should not be connected to a water system where there is no temperature control, unless the system is fitted with a suitable tempering valve.
PRIOR TO INSTALLATION 1. Unpack product. Dispose of packaging responsibly. 2. Lift the product to remove from the base packaging, two people are required. 3. Remove the install kit, any internal packaging, all rubber bands and all tape that are securing cords and hoses.
Page 13
TOP PANEL REMOVAL (OPTIONAL) The moisture protection tape must be used when removing the top panel. 1. Unscrew the top panel at the rear either side. 2. Slide backwards 20-30mm, then lift upwards. Ensure moisture tape is installed if removing top panel.
Page 14
CABINETRY PREPARATION 1. Ensure all minimum cabinetry and service specifications have been met and that all services will be accessible after installation. 2. Ensure cabinetry floor is free from bumps and obstructions that could prevent the Dishwasher from sliding into the cavity. 3.
Page 15
PUSH INTO POSITION 1. Using a spanner, level the rear legs first followed by the front legs. Clockwise to raise the height, anticlockwise to lower the height. 2. Push the product into the position, pulling the hoses through as you push to avoid crushing or twisting them.
Page 16
PLUMBING & ELECTRICAL CONNECTION Ø38MM STANDPIPE INSTALLATION 1. Install the drain hose support to the back wall, as close to the underside of the countertop as possible. Refer to 'Plumbing & electrical considerations' for minimum install heights. 2. Pull the hose through the support guide and rest in standpipe.
Page 17
PLUMBING & ELECTRICAL CONNECTION SINK TRAP/WASTE TEE INSTALLATION 1. Install the drain hose support to the back wall, as close to the underside of the countertop as possible. Refer to 'Plumbing & electrical considerations' for minimum install heights. 2. Pull the hose through the drain hose support before threading the hose clamp onto the hose and fitting to the sink trap.
TEST OPERATION 1. Power and water is turned on. 2. All internal packaging and rubber bands are removed. 3. Gaps are consistent.
Page 19
TEST OPERATION 1. Turn power and water supply on and open the dishwasher. 2. Press to select Rinse. 3. Press to begin the cycle. 4. After the Rinse cycle has finished, ensure the dishwasher has run and drained correctly.
INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Installation Check all parts are installed correctly and are secure. Ensure all packaging, tape and rubber bands have been removed. Ensure all clearance gaps have been maintained. Ensure door opens and closes freely with no resistance. ...
Page 21
Complete and keep for safe reference: Model Serial no. Purchase date Purchaser Dealer address Installer’s name Installer’s signature Installation company Installation date...
