- Page 1 Built-under Dishwasher Integrated HDW15U2I1models Installation guide NZ AU...
- Page 3 Safety and warnings WARNING! WARNING! WARNING! Cut Hazard Electric Shock Hazard Failure to use caution could result in injury. Failure to follow this advice may result in electrical shock or death. • Take care – panel edges are sharp. This appliance must be earthed. This appliance has a cord •...
- Page 4 Do not repair or replace any part of the appliance unless specifically recommended in • Installation of custom panels requires basic mechanical and electrical skills. this guide. All other servicing should be undertaken by a Haier trained and supported service technician or qualified person. •...
- Page 5 Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you bought the product from to report the damage. • Haier is not responsible for shipping damage. Supplied Powered driver...
- Page 6 Product dimensions Product dimensions unit：mm Overall height* 820-880 Overall width** Overall depth** Height of chassis Depth of chassis Plan Height of feet* 0-60 Depth of toe kick recess Depth of inner door** Height from top of chassis to bottom of inner door Height from to bottom of inner door to floor* Depth of door opening**...
- Page 7 Custom panel dimensions Material specifications • Maximum weight of door panels must not exceed 9kg (including handle). • The panel should be adequately sealed to withstand moisture (50°C @ 80% RH). The back and sides of the panel should be completely sealed with a waterproof vapour barrier, such as polyurethane, to prevent damage.
- Page 8 Cabinetry Dimensions Clearances Connections can be located in an adjacent cabinet Plan on either side of the dishwasher*** Isometric Cabinetry dimensions unit：mm Cabinetry dimensions unit：mm Minimum inside height * Minimum clearance to adjacent cupboard door Minimum inside width Minimum clearance to corner cupboard Minimum overall depth ** Height of toe kick area 65-200...
- Page 9 Plumbing & electrical considerations Hose and cord lengths • Your services can be installed to either the left-hand or right-hand side of the product in an adjacent cabinet. Refer to 'Cabinetry preparation' for service access requirements. • The drain hose should not extend more than 4m. A longer drain hose will cause reduced performance.
- Page 10 Service access We recommend locating the service holes on either side of the Dishwasher as shown. If the holes are created through wood, ensure the edges are smooth and rounded. If the holes are created through metal, ensure an edge protector is fitted.
- Page 11 Unpack product Cabinetry preparation Ensure all minimum cabinetry and service Cut straps, lift carton off product and specifications have been met and that all remove the top cap. services will be accessible after installation. Dispose of packaging responsibly. Ensure cabinetry floor is free from bumps Remove the install kit, any internal and obstructions that could prevent the Dishwasher from sliding into the cavity.
- Page 12 Door panel prep Push into cavity Using a flat bladed screwdriver, turn to Ensure door panel meets all raise the leveling feet. Level the rear, specifications. outside legs first followed by the front legs. Do not adjust the rear middle leg yet.
- Page 13 Secure door panel Balance door Use a 4mm Allen key to adjust the door Align the door panel to the product. tension. Rotate clockwise to increase Slot slider bracket and upper screws tension, rotate counterclockwise to into place. Slide the panel upwards to decrease tension.
- Page 14 Secure to cavity Loosely fit 2 x side fixing screws. If needed, adjust the Dishwasher within the cavity before tightly securing in place. Replace the screw covers. Secure to benchtop using 2 x screws if possible.
- Page 15 Install sound seal & toe kick Fit sound seal Custom toe kick panel Mark the pilot hole locations for each bracket. Measure the centre of the panel and mark 237mm to each side. To determine the height of the brackets, measure the height of the lowest bracket hole against the toe kick panel.
- Page 16 Plumbing & electrical connection φ38mm standpipe installation Sink trap/waste tee installation Install the drain hose support to the back Install the drain hose support to the back wall, as close to the underside of the wall, as close to the underside of the countertop as possible.
- Page 17 Installer checklist Test operation To be completed by the installer Installation Check all parts are installed correctly and are secure. Turn power and water supply on and Ensure all packaging, tape and rubberbands have been removed. open the dishwasher. Ensure all clearance gaps have been maintained. Ensure Dishwasher is securely fastened to the cabinetry and door opens and closes freely with no resistance.
- Page 20 条形码尺寸40*8mm，由厂家生成。 012050****...
