User Manual
RFT10, RFT32, RFT50, RFT55
Handheld Refractometers
Introduction
Thank you for selecting the Triplett MS300 Pinless Moisture Meter. The
MS300 sensor performs non-invasive, relative moisture measurements on
wood and building materials such as wallboard, sheet rock, cardboard,
plaster, concrete, and mortar. The MS300 also offers auto power off
(APO), display lock (hold), and self-calibration features.
The MS300 is ideal for building restoration projects and applications
where moisture detection on floors and under carpets is critical. The
MS300 is also a handy tool for analyzing the effects of water leakage
behind walls and in ceilings
Advertisement
Table of Contents
Related Manuals for Triplett RFT10
Summary of Contents for Triplett RFT10
- Page 1 RFT10, RFT32, RFT50, RFT55 Handheld Refractometers Introduction Thank you for selecting the Triplett MS300 Pinless Moisture Meter. The MS300 sensor performs non-invasive, relative moisture measurements on wood and building materials such as wallboard, sheet rock, cardboard, plaster, concrete, and mortar. The MS300 also offers auto power off (APO), display lock (hold), and self-calibration features.
-
Page 2: Meter Description
Meter Description Operation Step 1. Open daylight plate, and place 2-3 drops of distilled water on the main prism. Close the daylight plate so the water spreads across the entire surface of the prism without air bubbles or dry spots. Allow the sample to temperature adjust on the prism for approximately 30 seconds before going to step 2. - Page 3 Step 2. Hold daylight plate in the direction of a light source and look into the eyepiece. If you will see a circular field with graduation down the entrance, you may have to focus the eyepiece to clearly see the graduation. The upper portion of the field should be blue, while the lower portion should be white.
- Page 4 **NOTE: Each model of scale different, but the operation method is totally the same.
-
Page 5: Maintenance
5. This is an optical instrument. It needs careful handling and storage. Failure to do so can result in damage to the optical components and its basis structure. With care, this instrument will last years of reliable service. Specifications RFT10 RFT32 Type Sucrose... -
Page 6: Warranty
Triplett / Jewell Instruments extends the following warranty to the original purchaser of these goods for use. Triplett warrants to the original purchaser for use that the products sold by it will be free from defects in workmanship and material for a period of (1) one year from the date of purchase.
