ASSEMBLY AND INSTALLATION
T0434
WARNING:
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. Read and save these instructions.
Important to Know
1. Read all instructions carefully before installation and
operation.
2. If you are not familiar with state and local electrical codes,
it is recommended that you consult with a qualified
electrician.
3. Before installation, shut off power at the main fuse or
circuit breaker box. Be aware that simply turning off the
wall switch is not sufficient to prevent an electrical shock.
4. This fixture requires a 120 VAC, 60 Hz power source.
5. Do not attempt to take the lantern apart; there are no
serviceable parts inside.
6. To avoid sensor damage by lightning or electrical surge,
make sure the grounding wire is securely connected.
Maximum Wattage: 60W Incandescent Bulb
Work Temperature: - 4°F~104°F
HARDWARE CONTENTS Note: Hardware not shown actual size.
AA
Cross Bar
X1
BB
Mounting Screw
X2
INSTRUCTIONS
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
CC
Wire Connector
X3
DD
Headless Screw
X2
Page 1 of 6
Features
1. Energy saving fixture.
2. Use the dim-to-bright illumination option
where you want some minimum illumination
through out the night, such as at your front
entrance or garage door. Use the dark-to-bright
illumination option where you do not need
minimum brightness, such as the backyard
or back porch.
3. When in manual override mode, use wall switch
to keep the light ON till dawn.
EE
Ball Nut
X2
FF
Lock Nut
X4
GG
Rubber Pad
X2
