WASHER SAFETY ..................................................................... 2
INSTALLATION REQUIREMENTS ............................................ 3
PERMANENT INSTALLATION INSTRUCTIONS ...................... 6
PORTABLE INSTALLATION INSTRUCTIONS........................ 10
CONTROL PANEL AND FEATURES ...................................... 13
W11254174A
W11254180A-SP
WASHER
USE AND CARE GUIDE
Table of Contents
Designed to use only HE High Efficiency detergents.
Diseñada para utilizar solamente detergentes de alto rendimiento (HE).
USING YOUR WASHER .......................................................... 15
WASHER MAINTENANCE ...................................................... 18
TROUBLESHOOTING ............................................................. 20
WARRANTY ............................................................................. 25
Advertisement
Table of Contents
Related Manuals for Whirlpool WTW2000HW
Summary of Contents for Whirlpool WTW2000HW
-
Page 1: Table Of Contents
WASHER USE AND CARE GUIDE Table of Contents WASHER SAFETY ..............2 USING YOUR WASHER ............15 INSTALLATION REQUIREMENTS ..........3 WASHER MAINTENANCE ............18 PERMANENT INSTALLATION INSTRUCTIONS ...... 6 TROUBLESHOOTING ............. 20 PORTABLE INSTALLATION INSTRUCTIONS......10 WARRANTY ................25 CONTROL PANEL AND FEATURES ........ -
Page 2: Washer Safety
WASHER SAFETY... -
Page 3: Installation Requirements
INSTALLATION REQUIREMENTS Permanent Installation Parts needed (not provided with washer): Tools and Parts NOTE: Replace inlet hoses Gather the required tools and parts before starting installation. after 5 years of use to reduce The parts supplied are in the washer basket. the risk of hose failure. - Page 4 Alternate Parts You will need: Your installation may require additional parts. For information A water heater set to deliver 120°F (49°C) water to ■ on ordering, please refer to the back cover of this manual. the washer. A grounded electrical outlet located within 5 ft (1.5 m) of If You Have: You Will Need to Buy: ■...
- Page 5 Stacked Check with a qualified electrician if you are not sure the ■ washer is properly grounded. Do not have a fuse in the neutral or ground circuit. ■ 3" (76 mm) 12" (305 mm) 3" (76 mm) DRYER 48 in. (310 cm 12"...
-
Page 6: Permanent Installation Instructions
PERMANENT INSTALLATION Drain System INSTRUCTIONS The washer can be installed using the standpipe drain system (floor or wall), the laundry tub drain system, or the floor drain system. Select the drain hose installation method you need. Install Leveling Feet – Optional See “Tools and Parts.”... - Page 7 Remove drain hose form To avoid damage to the floor, set the washer onto cardboard ■ before moving across floor. (Floor drain installations only) Move the washer to within approximately 3 ft (900 mm) ■ of the final location. Connect Drain Hose Attach drain hose to drain port For floor drain installations, you will need to remove the drain hose form from the end of the drain hose.
- Page 8 Clear water lines Check for leaks Run water for a few seconds through hoses into a laundry tub, Turn on water faucets to check for leaks. A small amount of drainpipe, or bucket to avoid clogs. Water should run until clear. water may enter washer.
- Page 9 Level the Washer IMPORTANT: Level washer properly to reduce excess noise and vibration. For Permanent Installations: Check levelness of washer Move the washer to its final location. Place a level even with top edges of washer (B). Use side seam as a guide to check levelness of sides (A).
-
Page 10: Portable Installation Instructions
PORTABLE INSTALLATION Connect fill hose INSTRUCTIONS Drain System The washer must drain into a sink or laundry tub with a carry-away capacity of 17 gal. (64.5 L) per minute (for portable installations). The top of the tub must be at least 27" (686 mm) above floor and no higher than 48"... - Page 11 Secure drain hose Set TEMP to Tap Cold ¼" Drain hose ⁄ " (6 mm) (6 mm) Clamp ¼" ⁄ " (6 mm) (6 mm) Cabinet Set the temperature setting on your washer to Tap Cold. Set Place clamp over area marked “CLAMP.” Release clamp. the water temperature for the Wash cycle by adjusting the Hot and Cold water faucets.
- Page 12 Disconnect Washer Complete Installation Checklist ❑ Check electrical requirements. Be sure you have correct Remove fill-and-drain hose electrical supply and recommended grounding method. connector from faucet ❑ Check that all parts are now installed. If there is an extra part, go back through steps to see what was skipped. ❑...
-
Page 13: Control Panel And Features
CONTROL PANEL AND FEATURES LED TIME/STATUS DISPLAY CYCLES The Remaining Time display shows the time required for Press CYCLES to select a wash cycle. Choose from Normal, the cycle to complete. Factors such as load size and water Delicate, Heavy Duty, Rinse, Spin, or Clean Washer. pressure may affect the time shown in the display. - Page 14 Dispensers Cycle Guide This section describes the available wash cycles and will help you make the best cycle selections for your wash loads. Each cycle is designed for different types of fabric and soil levels. Always read and follow fabric care labels instructions to avoid Liquid fabric softener dispenser damage to your items.
-
Page 15: Using Your Washer
USING YOUR WASHER Add laundry products Sort and prepare your laundry IMPORTANT: If you are using the Compact Dryer Stack Stand (Part Number 49971), pull the washer forward before lifting the washer lid. Do not permanently install the washer in the Empty pockets. - Page 16 Using Laundry Product Dispensers Add liquid fabric softener NOTE: Do not add liquid laundry detergent, single-dose laundry packets, color-safe bleach, Oxi-type boosters, or fabric softener crystals to dispensers. They will not dispense correctly. Add to the basket prior to adding laundry. Add powdered HE detergent Pour a measured amount of liquid fabric softener into dispenser;...
- Page 17 For Portable Installations Select cycle Open the faucets connected to the water supply hoses. Wash and Rinse water temperatures are set at your faucet. The Temperature control does not set the temperature. Adjust the Hot and Cold water faucets to desired wash temperature.
-
Page 18: Washer Maintenance
WASHER MAINTENANCE WATER INLET HOSES Washer care (cont.) Replace inlet hoses after 5 years of use to reduce the risk of 2. Chlorine Bleach Procedure (Alternative): hose failure. Periodically inspect and replace inlet hoses if bulges, kinks, cuts, wear, or leaks are found. a. - Page 19 Washer care (cont.) Non-use and vacation care Operate your washer only when you are home. If moving, Cleaning The Lint Filter or not using your washer for a period of time, follow these Clean filter after every load. steps: 1. Press down, then out to remove the lint filter. 1.
-
Page 20: Troubleshooting
TROUBLESHOOTING First try the solutions suggested here for assistance and to possibly avoid a service call. If you experience Possible Causes Solution Vibration or Off-Balance Vibration, rocking, or Feet may not be in contact with Front and rear feet or wheels must be in firm contact with floor “walking”... - Page 21 TROUBLESHOOTING First try the solutions suggested here for assistance and to possibly avoid a service call. If you experience Possible Causes Solution Washer not performing as expected (cont.) Washer won’t run or fill; Check for proper water supply. Hose(s) must be attached and have water flowing to inlet valve. washer stops working Water faucet(s) must be turned on.
- Page 22 TROUBLESHOOTING First try the solutions suggested here for assistance and to possibly avoid a service call. If you experience Possible Causes Solution Washer not performing as expected (cont.) Washer not draining/ Load off-balanced. See “Vibration or Off-Balance” in “Troubleshooting” section for spinning, loads are more information.
- Page 23 TROUBLESHOOTING First try the solutions suggested here for assistance and to possibly avoid a service call. If you experience Possible Causes Solution Washer not performing as expected (cont.) Not cleaning or Not using HE detergent or using too The suds from regular detergent can keep washer from operating removing stains (cont.) much HE detergent.
- Page 24 TROUBLESHOOTING First try the solutions suggested here for assistance and to possibly avoid a service call. If you experience Possible Causes Solution Washer not performing as expected (cont.) Incorrect dispenser Clogged dispensers or laundry Do not overfill dispenser. Overfilling causes immediate dispensing. operation products dispensing too soon.
-
Page 25: Warranty
Please take a few minutes to review the Troubleshooting section of the Use and Care Guide or visit producthelp.whirlpool.com. 2. All warranty service is provided exclusively by our authorized Whirlpool Service Providers. In the U.S. and Canada, direct all requests for...
