- Page 1 USER'S MANUAL ELEMENT SERIES ASH-09AIE, ASH-12AIE, ASH-18AIE, ASH-24AIE...
- Page 2 “Original instructions” ...
-
Page 3: Table Of Contents
CONTENTS Operation and maintenance ■ ...............1 Notices for operation ■ ..............3 Notices for use ■ ..........5 Names and functions of each part ■ ..........6 Operation of Remote Controller ■ ............11 Emergency operation ■ ..............12 Clean and care ■... -
Page 4: Operation And Maintenance Notices For Operation
Operation and maintenance - notices for operation ★ ★ ★ Earth: The ground Select the most appropriate Be sure to pull out the power temperature. plug when not using the air co- be connected! nditioner for a long time. Keep room cool - er than outside about 5 degree. - Page 5 Notices for operation ★ The airflow direction can be adjusted appro- ★ If the supply cord is damaged, it must be replaced priately. At operating, adjust the vertical airflow by the manufacturer or its service agent or a direction by adjusting the louvers of upward/do- similarly qualified person in order to avoid a wnward direction.
-
Page 6: Notices For Use
Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function: If the unit is running in COOL mode and in low temperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 0... - Page 7 Notices for use Working temperature range Indoor sideDB/WB( Outdoor sideDB/WB( 32/23 Maximum cooling 43/26 Maximum heating 27/- 24/18 The operating temperature range (outdoor temperature) for cooling unit is 18℃~ 43℃; for cooling and heating unit is -7℃ ~ 43℃. - 4 -...
-
Page 8: Names And Functions Of Each Part
Names and functions of each part Indoor unit Air in ⑴ ⑶ ⑺ ⑹ ⑸ Air out ⑷ SET TEMP ⑵ Power cable (Note This dispaly is not available for some models.) Remote controller Cool Front panel Heat Filter Receive Guide louver ON/OFF window... -
Page 9: Operation Of Remote Controller
Operation of Remote Controller ON/OFF Press it to start or stop operation. AUTO HEALTH X-FAN MODE HUMIDITY Press it to select operation mode FILTER (AUTO/COOL/DRY/FAN/HEAT). TURBO HOUR : Press it to decrease temperature ON/OFF setting. : Press it to increase temperature setting. - Page 10 Operation of Remote Controller AUTO HEALTH X-FAN HUMIDITY FILTER TURBO HOUR ON/OFF MODE icon: Up & down swing icon: If MODE button is pressed, current operation mode icon is displayed when pressing (AUTO), ( COOL), button. up & down swing (DRY), (FAN) or (HEAT...
- Page 11 Operation of Remote Controller Remote controller description ON/OFF : Press this button to turn on the unit. Press this button again to turn off the unit. MODE : Each time you press this button,a mode is selected in a sequence that goes from AUTO, , as the following: COOL, DRY, FAN,and HEAT COOL...
- Page 12 Operation of Remote Controller HEALTH SAVE: Press HEALTH part of this button to turn on or off HEALTH function. Pressing SAVE part of this button, is displayed and the unit goes into SAVE operation mode. Press SAVE part of the button again to cancel SAVE function. During SAVE operation, the temperature and fan speed is not adjustable.
- Page 13 Operation of Remote Controller TURBO: Press this button to activate / deactivate the Turbo function which enables the unit to reach the preset temperature in shortest time. In COOL mode, the unit will blow strong cooling air at super high fan speed. In HEAT mode, the unit will blow strong heating air at super high fan speed.
-
Page 14: Emergency Operation
Emergency operation Control of indoor indicator light Special selection button: for those users who do not want light at night. Light on: press “light” button when the light is off, the indoor indicator light will ● be on. Light off: press “light” button when the light is on, the indoor indicator light will ●... -
Page 15: Clean And Care
Clean and care Caution Turn power off and pull out the power plug before cleaning air conditioner, or it may cause electric ● shock. Never sprinkle water on the indoor unit and the outdoor unit for cleaning because it can cause an ●... - Page 16 Clean and care Check before use ① Be sure that nothing obstructs the air outlet and intake vents. ② Check that whether ground wire is properly connected or not. ③ Check that whether the batteries of air conditioner are changed or not. ④...
-
Page 17: Troubleshooting
Troubleshooting CAUTION Don't attempt to repair the air conditioner by yourself, it can cause an electric shock or fire. Please check the following items before asking for repair, it can save your time and money. Phenomenon Troubleshooting Not operate immediately when the air Once the air conditioner is stopped, it will ●... - Page 18 Troubleshooting Phenomenon Troubleshooting Has the power been shut down? ● The unit can not run . Is power plug loosed? ● ● Is the circuit protection device tripped off or not? Is voltage higher or lower? ● (Tested by professionals) Breaking off Is the TIMER correctly used? ●...
- Page 19 Troubleshooting Phenomenon Troubleshooting Indoor unit can not blow air: ● In HEAT mode, when the temperature of indoor heat exchanger is very low, air flow is stopped in order to prevent cold air. (Within 2 minutes) ● In HEAT mode, when the outdoor temperature is low or humidity is high, frost will be formed on the outdoor heat exchanger.
-
Page 20: Notices For Installation
Notices for installation Important Notices 1. The unit installation work must be done by qualified personnel according to the local rules and this manual. 2. Before installation, please contact with local authorized maintenance center, if unit is not installed by the authorized maintenance center, the malfunction may not solved, due to discommodious contacts. - Page 21 Notices for installation Safety Requirements For Electric Appliances 1. The power supply should be used the rated voltage and AC exclusive circuit, the power cable diameter should be satisfied. 2. Don't drag the power cable emphatically. It should be reliably earthed, and it should be connected to the special earth device, the installation work should be operated by the professional.
-
Page 22: Installation Dimension Diagram
Installation dimension diagram Installation dimension diagram Space to the ceiling 15cm Above Space to the wall 15cm Above 15cm Above Space to the wall 300cm Above Above Air outlet side Space to the floor The dimensions of the space necessary for correct ●... -
Page 23: Install Indoor Unit
Install indoor unit Install the rear panel 1. Always mount the rear panel horizontally. Due to the water tray of indoor unit has been adopted the both-way drainage design, the outlet of water tray should be adjusted slightly down when installing, that is taking the outlet of the water tray as the center of a circle, the included angle between the evaporator and level should be 0 or more, that is good for condensing water drainage. - Page 24 Install indoor unit Note: The insulating tube should be connected reliably with bulge distortion the sleeve outside the outlet pipe. The drain hose should be slanted downward slightly, without distortion, bulge or fluctuation. Do not put the outlet in the water. Flooded Connect indoor and outdoor electric wires 1.
- Page 25 Install indoor unit Install the indoor unit External connection The piping can be lead out from right, right rear, left Gas side pipe electric wire ● Liquid side piping or left rear. When routing the piping and wiring from the left Tailing 2 or right side of indoor unit, cut off the tailings Gas side piping...
-
Page 26: Install Outdoor Unit
Install outdoor unit Electric wiring 1. Disassemble the handle on the outdoor unit right side plate. 2. Take off cord anchorage. Connect and fix power connect cord to term inal block. 3. Fix the power connection cable with cord anchorage. Handle blue yellow-... -
Page 27: Check After Installation And Test Operation
Check after installation and test operation Check after installation Items to be checked Possible malfunction Has it been fixed firmly? The unit may drop, shake or emit noise. It may cause insufficient cooling (heating) Have you done the refrigerant leakage test? capacity It may cause condensation and dripping. -
Page 28: Installation And Maintenance Of Healthy Filter
Installation and Maintenance of Healthy Filter Installation Instructions 1. Forcibly pull the panel for a specific angle from the two ends of the front panel according to the arrow direction. Then pull the air filter downwards to remove it. (See Fig.a) Fig. -
Page 29: Install Snow Guard (Optional)
Install snow guard (Optional) Installation method of snow guard In consideration of snow during installation of outdoor units Note: It is required to equip snow guard and a higher foundation base to prevent snow from covering air inlet and outlet. Correct Incorrect The snow guard shall... -
Page 30: Configuration Of Connection Pipe And Additional Volume Of Refrigerant
Configuration of connection pipe and additional volume of refrigerant 1. Standard length of connection pipe 5m， 7.5m, 8m 2. Min length of connection pipe For the unit with standard connection pipe of 5m, there is no limitation for the min length of connection pipe. For the unit with standard connection pipe of 7.5m and 8m, the min length of connection pipe is 3m. - Page 31 Configuration of connection pipe and additional volume of refrigerant Sheet 2. Additional refrigerant charging amount for R22 R407C R410A and R134a Diameter of connection pipe mm Indoor unit throttle Outdoor unit throttle Liquid pipe Gas pipe Cooling only, Cooling only Cooling and cooling and heating (g / m)
- Page 33 ...
- Page 34 Manufacturer: Sinclair Corporation Ltd., 1-4 Argyll Street, London W1F 7LD, UK Supplier and technical support: Nepa, spol.s.r.o. Purky ova 45 612 00 Brno Czech Republic www.nepa.cz Toll-free info line: +420 800 100 285...
