Sinclair SDV5 Series Service Manual

Indoor floor-ceiling units
Hide thumbs Also See for SDV5 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
INDOOR FLOOR-CEILING UNITS SDV5-xxFA
C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDV5 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sinclair SDV5 Series

Summary of Contents for Sinclair SDV5 Series

  • Page 1 INDOOR FLOOR-CEILING UNITS SDV5-xxFA C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5...

  • Page 2: Important Note

    Original instructions IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
  • Page 3 Ceiling & floor Specifications ..................4 Dimensions .................... 6 Unit Placement ..................4 Piping Diagram ..................5 Wiring Diagram ..................6 Capacity Tables ..................8 Electrical Characteristics ..............16 Sound Levels ..................17 201805...

  • Page 4: Specifications

    1 Specifications SDV5-36FA / SDV5-45FA / SDV5-56FA / SDV5-71FA Table 1.1: SDV5-36,45,56,71FA specifications Model SDV5-36FA SDV5-45FA SDV5-56FA SDV5-71FA Power supply 1 phase, 220-240V, 50Hz Capacity Cooling kBtu/h 12.3 15.4 19.1 24.2 Power input Capacity Heating kBtu/h 13.6 17.1 21.5 27.3 Power input Model WZDK100-38GS-2...
  • Page 5 Table 1.2: SDV5-80,90,112,140FA specifications Model SDV5-80FA SDV5-90FA SDV5-112FA SDV5-140FA Power supply 1 phase, 220-240V, 50Hz 11.2 14.0 Capacity Cooling kBtu/h 27.2 30.7 38.2 47.8 Power input 10.0 12.5 15.0 Capacity Heating kBtu/h 30.7 34.1 42.7 51.2 Power input Model WZDK100-38GS-1 WZDK100-38GS-2 Type Fan motor...

  • Page 6: Unit Dimensions

    2 Dimensions 2.1 Unit Dimensions Figure 2.1: Ceiling & floor dimensions (unit: mm) Hook Hanging arm Table 2.1: Ceiling & floor dimensions Dimensions (mm) Model SDV5-36FA SDV5-45FA SDV5-71FA SDV5-80FA 1280 1195 SDV5-90FA SDV5-112FA 1670 1070 1542 SDV5-140FA Table 2.2: Ceiling & floor piping connections Model Gas pipe (mm) Liquid pipe (mm)

  • Page 7: Unit Placement

    3 Unit Placement 3.1 Placement Considerations Unit placement should take account of the following considerations:  Units should not be installed in the following locations:  Where exposure to direct radiation from a high-temperature heat source or to interference from a source of electromagnetic radiation may occur.

  • Page 8: Piping Diagram

    4 Piping Diagram Figure 4.1: Ceiling & floor piping diagram motor flare nut gas side heat exchanger flare nut liquid side Legend Indoor ambient temperature sensor Indoor heat exchanger mid-point temperature sensor Indoor heat exchanger outlet temperature sensor 201805...

  • Page 9: Wiring Diagram

    5 Wiring Diagram Figure 5.1: Ceiling & floor wiring diagram 201805...
  • Page 10  Notes for installers and service engineers Caution  All installation, servicing and maintenance must be carried out by competent and suitably qualified, certified and accredited professionals and in accordance with all applicable legislation.  Units should be grounded in accordance with all applicable legislation. Metal and other conductive components should be insulated in accordance with all applicable legislation.

  • Page 11: Capacity Tables

    6 Capacity Tables 6.1 Cooling Capacity Table Table 6.1: Ceiling & floor cooling capacity Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0 27.0...
  • Page 12 Table 6.1: Ceiling & floor cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0 27.0 29.0 31.0 33.0 35.0 37.0 39.0...
  • Page 13 Table 6.1: Ceiling & floor cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 10.4 12.0 10.2 14.0 10.2 16.0 10.0 18.0 20.0 21.0 23.0 25.0 27.0 29.0 31.0...
  • Page 14 Table 6.1: Ceiling & floor cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 10.5 11.2 11.9 13.3 15.5 12.0 10.5 11.2 11.9 13.3 14.4 14.0 10.5 11.2 11.9...
  • Page 15 6.2 Heating Capacity Table Table 6.2: Ceiling & floor heating capacity Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 2.24 2.24 2.24 2.24 2.24 2.24 -18.8 2.40 2.40 2.40 2.40 2.40 2.40 -16.7 2.52 2.52 2.52 2.52 2.52 2.52...
  • Page 16 Table 6.2: Ceiling & floor heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 3.53 3.53 3.53 3.53 3.53 3.53 -18.8 3.78 3.78 3.78 3.78 3.78 3.78 -16.7 3.97 3.97 3.97 3.97 3.97 3.97 -14.7 4.10 4.10...
  • Page 17 Table 6.2: Ceiling & floor heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 5.04 5.04 5.04 5.04 5.04 5.04 -18.8 5.40 5.40 5.40 5.40 5.40 5.40 -16.7 5.67 5.67 5.67 5.67 5.67 5.67 -14.7 5.85 5.85...
  • Page 18 Table 6.2: Ceiling & floor heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 7.00 7.00 7.00 7.00 7.00 7.00 -18.8 7.50 7.50 7.50 7.50 7.50 7.50 -16.7 7.88 7.88 7.88 7.88 7.88 7.88 -14.7 8.13 8.13...

  • Page 19: Electrical Characteristics

    7 Electrical Characteristics Table 7.1: Ceiling & floor electrical characteristics Power supply Indoor fan motors Model Rated motor Volts Min. volts Max. volts output (kW) SDV5-36FA 220-240 0.45 0.10 0.35 SDV5-45FA 220-240 1.20 0.10 0.93 SDV5-56FA 220-240 1.20 0.10 0.95 SDV5-71FA 220-240 1.20...

  • Page 20: Sound Levels

    8 Sound Levels 8.1 Overall Table 8.1: Ceiling & floor sound pressure levels Sound pressure levels dB(A) Model name SDV5-36FA SDV5-45FA SDV5-56FA SDV5-71FA SDV5-80FA SDV5-90FA SDV5-112FA SDV5-140FA Notes: Sound pressure levels are measured in a semi-anechoic chamber. During in-situ operation, sound pressure levels may be higher as a result of ambient noise.
  • Page 21 Figure 8.4: SDV5-80,90FA octave band levels Figure 8.5: SDV5-112,140FA octave band levels NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000 1000 2000 4000 8000 Octave band center frequency (Hz) Octave band center frequency (Hz) 201805...
  • Page 22 FLOOR-CEILING UNITS SDV5-36-140FA C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5...
  • Page 23 SDV5-36FA...
  • Page 24 Description Part Code Note Qty Price Code MODEL: SDV5-36FA FLOOR-CEILING UNIT Cover 12122700000092 Chassis foam 12822700000021 Base assembly 12226000002274 Evaporator ass'y 15826000000258 11201007000382 Pipe Temperature Sensor evaporator output pipe ass'y 15126000001338 evaporator input pipe ass'y 15426000000206 display board installation support 12222700000052 Left hook 12222700000017...
  • Page 25 Room Temp. sensor ass'y 11201007000077 Display connection cable 17401204000066 Accessory package 12011600000128 49.1 Drainage hose 12100509000028 49.2 Throat bander 12200201000001 The data are subject to change without notice.
  • Page 26 SDV5-45FA...
  • Page 27 Description Part Code Note Qty Price Code MODEL: SDV5-45FA FLOOR-CEILING UNIT Cover 12122700000092 Chassis foam 12822700000021 Base assembly 12226000002274 Evaporator parts 15826000000255 11201007000382 Pipe Temperature Sensor Evaporator outlet pipe subassembly 15426000000185 evaporator input pipe ass'y 15426000000196 display board installation support 12222700000052 Left hook 12222700000017...
  • Page 28 Room Temp. sensor ass'y 11201007000077 Display connection cable 17401204000066 Accessory package 12011600000128 49.1 Drainage hose 12100509000028 49.2 Throat bander 12200201000001 The data are subject to change without notice.
  • Page 29 SDV5-56FA...
  • Page 30 Description Part Code Note Qty Price Code MODEL: SDV5-56FA FLOOR-CEILING UNIT Cover 12122700000092 Chassis foam 12822700000021 Base assembly 12226000002274 Evaporator ass'y 15826000000256 11201007000382 Pipe Temperature Sensor evaporator output pipe ass'y 15126000001343 evaporator input pipe ass'y 15426000000203 display board installation support 12222700000052 Left hook 12222700000017...
  • Page 31 Copper nut 15500406000003 Room Temp. sensor ass'y 11201007000077 Display connection cable 17401204000066 Accessory package 12011600000128 49.1 Drainage hose 12100509000028 49.2 Throat bander 12200201000001 The data are subject to change without notice.
  • Page 32 SDV5-71FA...
  • Page 33 Description Part Code Note Qty Price Code MODEL: SDV5-71FA FLOOR-CEILING UNIT Cover 12122700000092 Chassis foam 12822700000021 Base assembly 12226000002274 Evaporator ass'y 15826000000256 11201007000382 Pipe Temperature Sensor evaporator output pipe ass'y 15126000001343 evaporator input pipe ass'y 15426000000203 display board installation support 12222700000052 Left hook 12222700000017...
  • Page 34 Copper nut 15500406000010 Room Temp. sensor ass'y 11201007000077 Display connection cable 17401204000066 Accessory package 12011600000128 49.1 Drainage hose 12100509000028 49.2 Throat bander 12200201000001 The data are subject to change without notice.
  • Page 35 SDV5-80FA...
  • Page 36 Description Part Code Note Qty Price Code MODEL: SDV5-80FA FLOOR-CEILING UNIT Cover 12122700000088 Chassis foam 12822700000020 Base assembly 12226000002273 Evaporator parts 15826000000257 15126000001336 Evaporator output pipe ass'y Evaporator input pipe ass'y 15426000000456 Pipe Temperature Sensor 11201007001784 Pipe temperature sensor assemblies 11201007000030 display board installation support 12222700000052...
  • Page 37 Foam 12822700000023 Support board 12222700000117 Clapboard right subassembly 12222700000086 Cover 12122700000085 Copper nut 15500406000003 Copper nut 15500406000010 Room Temp. sensor ass'y 11201007000077 Accessory package 12011600000128 53.1 Drainage hose 12100509000028 53.2 Throat bander 12200201000001 The data are subject to change without notice.
  • Page 38 SDV5-90FA...
  • Page 39 Description Part Code Note Qty Price Code MODEL: SDV5-90FA FLOOR-CEILING UNIT Cover 12122700000088 Chassis foam 12822700000020 Base assembly 12226000002273 Evaporator parts 15826000000257 15126000001336 Evaporator output pipe ass'y Evaporator input pipe ass'y 15426000000456 Pipe Temperature Sensor 11201007001784 Pipe temperature sensor assemblies 11201007000030 display board installation support 12222700000052...
  • Page 40 Foam 12822700000023 Support board 12222700000117 Clapboard right subassembly 12222700000086 Cover 12122700000085 Copper nut 15500406000003 Copper nut 15500406000010 Room Temp. sensor ass'y 11201007000077 Accessory package 12011600000128 53.1 Drainage hose 12100509000028 53.2 Throat bander 12200201000001 The data are subject to change without notice.
  • Page 41 SDV5-112FA...
  • Page 42 Description Part Code Note Qty Price Code MODEL: SDV5-112FA FLOOR-CEILING UNIT display board installation support 12222700000052 Base assembly 12222700000666 Left hook 12222700000017 Cover 12122700000089 12122700000132 Sealing board Evaporator ass'y 15826000002112 evaporator installation board 12222700000036 Evaporator output pipe ass'y 15126000001342 Pipe Temperature Sensor 11201007000382 Pipe temperature sensor assemblies 11201007000030...
  • Page 43 SDV5-140FA...
  • Page 44 Description Part Code Note Qty Price Code MODEL: SDV5-140FA FLOOR-CEILING UNIT display board installation support 12222700000052 Base assembly 12222700000666 Left hook 12222700000017 Cover 12122700000089 12122700000132 Sealing board Evaporator ass'y 15826000002112 evaporator installation board 12222700000036 Evaporator output pipe ass'y 15126000001342 Pipe Temperature Sensor 11201007000382 Pipe temperature sensor assemblies 11201007000030...

  • Page 45: Technical Support

    SINCLAIR CORPORATION Ltd. 1-4 Argyll St. London W1F 7LD Great Britain www.sinclair-world.com This product was manufactured in China (Made in China). REPRESENTATIVE SINCLAIR Global Group s.r.o. Purkynova 45 612 00 Brno Czech Republic TECHNICAL SUPPORT SINCLAIR Global Group s.r.o. Purkynova 45...
