Package Contents
1. Blade Set of 3
RPL-F1803-**-BD-**
2. Hanger Plate
RPL-F1803-HGR
3. Trim Ring - Decorative
RPL-FH1803-TRIM**
4. Motor Assembly
5. Adapter Plate
6. LED Module
F4IN-120V-R1-30
Hardware Bag
RPL-AXISFLUSH-PART
A Machine Screws (2)
Spring Washers (2)
Flat Washers (2)
B Wood Screw (1)
Spring Washer (1)
Flat Washer (1)
C
Wire Nuts (8)
D
Screw with Fiber Washers (10)
Before discarding packaging materials be certain all parts have been removed.
Place the parts from the hardware bag into a small container to keep them from being lost.
8 Axis Flush Instructions
7. Glass Shade
RPL-F1803-GLA
8. Luminaire Cover
RPL-FH1803-COVER-**
9. Control Receiver
w/Hardware
F-R3-1803-0**
10. Remote w/Wall Cradle
F-RCBT-WT
** denotes finish code of fan/blade sweep
of fan
