4. Attaching the Fan Blades

1. Insert the blade through the slot in the housing. Align the holes
in the blade with the fan motor assembly holes and secure with
blade attachment screw with lock washers (Fig. 4).
Use C hardware.
2. Repeat this procedure with the remaining blades.

5. Making the Electrical Connections

WARNING: Installation of this fan requires that a three-conductor
cable (including ground and neutral wires) which should run between
ceiling and wall outlet box.
WARNING: Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire nuts,
except for the ground wire. Use electrical tape as needed.
Before inserting and wiring the receiver - make note of the MAC ID on
the receiver.
Insert the receiver into the motor assembly with the flat side of the
receiver facing the ceiling (Fig. 5).
