Summary of Contents for geratech EGE-SP118-4K
- Page 1 EGE-SP118-4K 11x8 HDMI Splitter Supports resolution 4Kx2K@60Hz(YUV 4:2:0), HDCP, EDID...
- Page 2 EGE-SP118-4K 11x8 HDMI Splitter Supports resolution 4Kx2K@60Hz(YUV 4:2:0), HDCP, EDID...
-
Page 3: Table Of Contents
EGE-SP118-4K 11x8 HDMI Splitter Supports resolution 4Kx2K@60Hz(YUV 4:2:0), HDCP, EDID CONTENTS ............Operating Instructions ................. Features ..............Package Contents ................Specification ..............Panel Descriptions ..............Edit Intoduction Connecting Operating ............Connection Diagram ..........................Safety Information ................Safeguards Product Service .............. -
Page 4: Operating Instructions
EGE-SP118-4K 11x8 HDMI Splitter Supports resolution 4Kx2K@60Hz(YUV 4:2:0), HDCP, EDID Operating Instructions Notice The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute the warranty of any kind, express or implied. -
Page 5: Specification
EGE-SP118-4K 11x8 HDMI Splitter Supports resolution 4Kx2K@60Hz(YUV 4:2:0), HDCP, EDID SPECIFICATIONS Operating Temperature Range -5 to +35°C(+23 to +95°F) Operating Humidity Range 5 to 90%RH (No Condensation) Bandwidth frequency 10.2Gbps Input ports 1xHDMI(female) Output ports 8xHDMI outputs(female) Resolution outputs up to 4Kx2K(3840x2160@60Hz YUV 4:2:0) Dimensions(LxWxH) 270x110x27.5mm... -
Page 6: Edit Intoduction
EGE-SP118-4K 11x8 HDMI Splitter Supports resolution 4Kx2K@60Hz(YUV 4:2:0), HDCP, EDID EDID Introduction 11: Mixed EDID: always follow the lowest resolution of the displays connected to the 8 outputs, in order to support all displays show the source. 00: Copy EDID: output 8 is prior port a. -
Page 7: Safety Information
EGE-SP118-4K 11x8 HDMI Splitter Supports resolution 4Kx2K@60Hz(YUV 4:2:0), HDCP, EDID CONNECTING AND OPERATING Safety Information 1) Connect the HDMI input source (such as HD-DVD/ PS3 /STB etc.) into transmitter over HDMI cable. Safeguards 2) Connect the output of transmitter and input of receiver over CAT5E or CAT6 cable. -
Page 8: Limited Warranty Limits And Exclusions
EGE-SP118-4K 11x8 HDMI Splitter Supports resolution 4Kx2K@60Hz(YUV 4:2:0), HDCP, EDID LIMITED WARRANTY LIMITS AND EXCLUSIONS 1) This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO... - Page 9 www.egerate-store.com...
