Summary of Contents for geratech EGE-SP112-4K
- Page 1 EGE-SP112-4K 1x2 HDMI Splitter, Support 3D, 4Kx2K,HDCP...
- Page 2 EGE-SP112-4K 1x2 HDMI Splitter, Support 3D, 4Kx2K,HDCP...
-
Page 3: Table Of Contents
EGE-SP112-4K 1x2 HDMI Splitter, Support 3D, 4Kx2K,HDCP CONTENTS ............Operating Instructions ................. Features ..............Package Contents ................Specification ..............Panel Descriptions ............Connecting Operating Connection Diagram ..........................Safety Information ................Safeguards ..............Product Service Warranty ................................ Mall-In Service ...... -
Page 4: Operating Instructions
EGE-SP112-4K 1x2 HDMI Splitter, Support 3D, 4Kx2K,HDCP Supports 4Kx2K Operating Instructions Notice The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute the warranty of any kind, express or implied. -
Page 5: Specification
EGE-SP112-4K 1x2 HDMI Splitter, Support 3D, 4Kx2K,HDCP SPECIFICATIONS Operating Temperature Range -5 to +35°C(+23 to +95°F) Operating Humidity Range 5 to 90%RH (No Condensation) Bandwidth frequency 10.2Gbps Input ports 1xHDMI(female) Output ports 2xHDMI outputs(female) Resolution outputs up to 4Kx2K(3840x2160@30Hz) Dimensions(LxWxH) 75x68x25.2mm... -
Page 6: Connecting Operating
EGE-SP112-4K 1x2 HDMI Splitter, Support 3D, 4Kx2K,HDCP Connecting And Operating 1) Connect the HDMI input source to input port of HDMI splitter. 2) Connect the HDMI splitter output ports to the display input ports. 3) Power up splitter, source and displays. -
Page 7: Safety Information
EGE-SP112-4K 1x2 HDMI Splitter, Support 3D, 4Kx2K,HDCP CONNECTING AND OPERATING Safety Information 1) Connect the HDMI input source (such as HD-DVD/ PS3 /STB etc.) into transmitter over HDMI cable. Safeguards 2) Connect the output of transmitter and input of receiver over CAT5E or CAT6 cable. -
Page 8: Limited Warranty Limits And Exclusions
EGE-SP112-4K 1x2 HDMI Splitter, Support 3D, 4Kx2K,HDCP LIMITED WARRANTY LIMITS AND EXCLUSIONS 1) This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO... - Page 9 www.egerate-store.com...
