- Page 1 ® EGE-UHD-148 1:8 HDMI 4Kx2K Splitter...
- Page 2 EGE-UHD-148 1:8 HDMI 4Kx2K Splitter...
- Page 3 Geratech also makes no commitment to update or to keep current the information contained in this document. Geratech reserves the right to make improvements to this document and/or product at any time and without notice. COPYRIGHT NOTICE No part of this document may be reproduced,...
- Page 4 EGE-UHD-148 1:8 HDMI 4Kx2K Splitter SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...
-
Page 5: Table Of Contents
EGE-UHD-148 1:8 HDMI 4Kx2K Splitter CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 4. System Requirements ......5. Features ..........6. Operation Controls and Functions ..2 6.1 Front Panel .......... 2 6.2 Rear Panel ........ -
Page 6: Introduction
EGE-UHD-148 1:8 HDMI 4Kx2K Splitter 1. INTRODUCTION This range of high performance HDMI splitters provide one HDMI in to eight HDMI outputs and support 4Kx2K, 3D, 12 -bit Deep Coloer as well as High de nition Lossless Audio. With its 3Gbps bandwidth and the additional features of the latest HDMI standards you can be sure of great HDMI distribution. -
Page 7: Operation Controls And Functions
EGE-UHD-148 1:8 HDMI 4Kx2K Splitter 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel EGE-UHD-148 POWER LED: Once the power supply is connected the LED will illuminate SYNC: This LED will illuminate when the HDMI input port is connected to an active source. -
Page 8: Rear Panel
EGE-UHD-148 1:8 HDMI 4Kx2K Splitter 6.2 Rear Panel SYS RESET ON/OFF: This switch allows the user to perform a system reset. The default setting is OFF, leave as it is when in normal use. By switching ON, the unit will perform a reset every 8~10 minutes, in order to perfrom this function the displays must have CEC supported. -
Page 9: Connection Diagram
EGE-UHD-148 1:8 HDMI 4Kx2K Splitter DC 5V: Plug the 5V DC power supply into the unit and connected adaptor to an AC outlet. 7. CONNECTION DIAGRAM www.geratech.com.tr... -
Page 10: Speci Cations
EGE-UHD-148 1:8 HDMI 4Kx2K Splitter 8. SPECIFICATIONS Video Bandwidth 300Mbps/9Gbps Input ports 1 x Female HDMI type A, 1 x USB (Service only) Output ports 8 x HDMI, Resolution Up to 4Kx2K (3840x2160@24/25/30Hz/4096 x2160@24Hz) Power Supply 5V / 3A DC (US/EU standards, CE/FCC/UL... -
Page 11: Acronyms
EGE-UHD-148 1:8 HDMI 4Kx2K Splitter 9. ACRONYMS ACRONYM COMPLETE TERM Digital Theater System EDID Extended Display Identi cation Data HDCP High -bandwidth Digital Content Protection HDMI High -De nition Multimedia Interface HDTV High -De nition Television www.geratech.com.tr... - Page 12 EGE-UHD-148 1:8 HDMI 4Kx2K Splitter www.geratech.com.tr...
- Page 13 www.geratech.com.tr...
