- Page 1 EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX)
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...
-
Page 5: Table Of Contents
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) CONTENTS 1. Introduction ..................1 2. Applications ................... 1 3. Package Contents ................. 1 4. System Requirements ..............1 5. Features..................2 6. Operation Controls and Functions ..........3 6.1 Front Panel ................. -
Page 6: Introduction
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) 1. INTRODUCTION The HDMI over HDMI and CAT5e/6/7 Transmitter can convert a single HDMI input, 2-way IR and RS-232 control and LAN serving to a single CAT5e/6/7 output and includes a simultaneous HDMI bypass output. -
Page 7: Features
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) 5. FEATURES • HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant • Simultaneous HDMI and CAT5e/6/7 outputs • Supports data rate from 250Mbps up to 3Gbps •... -
Page 8: Operation Controls And Functions
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) "6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel RS232 IN HDMI OUT HDMI IN HDMI to CAT5e/6 with LAN/IR/RS232 Transmitter HDMI OUT: Connect to HDMI display for instant image display or cascade with another family type Transmitter. -
Page 9: Rear Panel
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) 6.2 Rear Panel POWER IR 1 BLASTER LINK IR 2 DC 24V EXTENDER CAT5e/6 OUT POWER LED: Once the power supply is connected the LED will illuminate. -
Page 10: Ir Cable Pin Assignment
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) 6.3 IR Cable Pin Assignment IR Blaster Power 3.3V IR Blaster Signal IR Extender IR Signal Power 3.3V Grounding 6.4 D-Sub 9-Pin Definitions Define TX / RX... -
Page 11: Connection Diagram
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) 7. CONNECTION DIAGRAM Smartphone or 3D TV/Display Tablet Blu-ray or PS3 Player HDMI HDMI Router with Internet Connection RS-232 Cable RS232 IN HDMI OUT... -
Page 12: Specifications
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) 8. SPECIFICATIONS Video Bandwidth 340Mbps/10.2Gbps Input ports 1 x HDMI, 1 x 3.5mm Phone Jack for RS-232, 1 x IR IN, 1 x LAN,... -
Page 13: Cat5E/6/7 Cable Specification
EGE-UHD-5HDB-1411 1×2 HDMI over 1 HDMI and 1 CAT5e/6/7 Splitter,100m with IR,PoC, LAN Serving,(not include 507RX) 8.1 CAT5e/6/7 Cable Specification Cable Range Pixel clock Video Data Supported Video Type rate Rate CAT5e/6/7 100 m <=225 MHz <=5.3 Gbps Up to 1080p, 60 Hz,... - Page 14 20130625 MPM-CHDBT1H1CE www.geratech.com.tr www.egerate.com www.egerate-store.com...
