Summary of Contents for geratech EGE-6UHD-1410
- Page 1 EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...
-
Page 5: Table Of Contents
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability CONTENTS 1. Introduction ..................1 2. Applications ..................1 3. Package Contents ................1 4. System Requirements ..............1 5. Features..................... 2 6. Operation Controls and Functions ..........3 6.1 Front Panel ..................3 6.2 Rear Panel.................. -
Page 6: Introduction
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability 1. INTRODUCTION The 1 by 10 HDMI Splitter with HDCP 2.2 is an advanced solution for splitting a single HDMI input to 10 HDMI outputs. It provides high performance audio and video output up to 4K2K@60Hz (YUV444) resolution and is capable of provide high end of audio and video performance. -
Page 7: Features
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability 5. FEATURES • 4Kx2K 6G supported, HDCP 2.2, HDMI2.0 and DVI compliant. • 1 HDMI input and 10 HDMI outputs • System Reset function supported (CEC active source command) • Displays any of 1 Ultra High-Definition sources on 10 UHDTV displays simultaneously •... -
Page 8: Operation Controls And Functions
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel POWER OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6 OUT 7 OUT 8 OUT 9 OUT 10 EDID SYS-RST... -
Page 9: Rear Panel
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability 6.2 Rear Panel INPUT OUTPUT SERVICE DC 5V INPUT: Connect with HDMI source equipment such as DVD/Blue-ray players and or PC/Laptop devices. OUTPUT 1~10: Connect to HDMI TV / display or HD amplifier for output display. -
Page 10: Connection Diagram
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability 7. CONNECTION DIAGRAM DVD or Blu-ray Player HDMI Input Power Supply INPUT OUTPUT SERVICE DC 5V Simultaneous HDMI Outputs UHDTV Projector UHDTV Projector UHDTV Projector UHDTV Projector UHDTV Projector... -
Page 11: Specifications
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability 8. SPECIFICATIONS 8.1 Technical Specifications Video Bandwidth 600 MHz/18 Gbps Input Ports 1×HDMI, 1×USB (Service only) Output Ports 10×HDMI HDMI Resolutions VGA~WUXGA (RB), 408i~1080p@24/50/60, 4K@24/25/30, 4K@50/60 (YUV444) HDMI Cable I/O 15 m@1080p/8-bit, 10 m@1080p/12-bit,... -
Page 12: Supported Resolutions
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability 8.2 Supported Resolutions Resolution Input Output 640×480@60/72/75/85 √ √ 720×400@85 √ √ 800×600@56/60/72/75/85 √ √ 1024×768@60/70/75/85 √ √ 1152×864@75 √ √ 1280×720@60 √ √ 1280×768@60/75/85 √ √ 1280×800@60 √ √ 1280×960@60 √... -
Page 13: Acronyms
EGE-6UHD-1410 1×10 HDMI 4K UHD Splitter with 6G Capability 9. ACRONYMS ACRONYM COMPLETE TERM Consumer Electronics Control Digital Theater System Digital Visual Interface EDID Extended Display Identification Data HDCP High-bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface HDTV High-Definition Television... - Page 14 www.egerate-store.com...
