OPERATION (continued)
SPA CONTROL PANEL
Adjustment Buttons: Press the increase or decrease buttons to adjust the desire function
settings. Press and hold the button will rapidly increase or decrease the numbers.
LED Display: Once plugged in the LED displays the current water temperature automatically.
If the control panel (3) is not placed on the control base recessed channel, the LED display
will go blank after 5 minutes. Press any button to resume the control panel.
Water Temp
HSDT
o
( C/F)
40/104 000H
40/104 000H
40/104 012H
40/104 012H
S AVE THESE INSTRUCTIONS
(346PO) SPA ENGLISH 7.5" X 10.3" PANTONE 295U 08/10/2019
J: Decrease Button
K: Increase Button
L: LED Display
L
RF frequency band:2408~2476 MHz
K
Transmitter power: 10dBm
J
Setting Examples
HSOH
HSDT & HSOH functions are off. Heating system has to
000H be activated manually by pressing (
Control Panel" section for details.
HSDT is off. Heating system starts operating for 5 hours
and then stop, regardless if the water temperature has
005H reached 104°F/40°C or not. The information shown
on the LED display alternates between the remaining
operating hours and the water temperature.
The heating system will start after 12 hours and
then operate for 5 hours only, regardless if the water
temperature has reached 104°F/40°C or not. The
005H
information shown on the LED display alternates
between the remaining countdown delay time and the
water temperature.
The heating system will start after 12 hours, then operate
until the water reaches 104°F/40°C and stop. When the
spa water temperature drops 1.8-3.6°F(1-2°C) below the
set temperature the heating system will restart. When the
000H
fl ame icon on the display is red, the heating system is
activated. When the fl ame icon turns green, the water is
at the set temperature. The heating system is at rest and
the fi ltration system will continue working nonstop.
English
Action
) button. See "Spa
