INTRODUCTION

The AVC-2060 is an Plasma Height Control (PHC) for the Pendulum Weaver (WPD-2100) that controls
the tip to work distance and maintains a constant voltage, which provides a more uniform result.
Available in three models, by voltage. Plasma Height Control senses the actual voltage, compares
this value to the set point, and raises or lowers the torch accordingly. It features motion based on the
plasma source "ok to move" signal and automatically shuts off when voltage drops too low (generally
below 36 volts).
The AVC-2060 Plasma Height Control is available as original equipment or as a retrofit unit designed
to provide automated height control on the BUG-O Modular Drive Systems (MDS) with a Pendulum
Weaver (WPD-2100). Height Slide Assembly (CAS-1500) replaces the welding clamp originally
supplied on the Pendulum Weaver.

SPECIFICATIONS

Net Weight:
Travel:
Carrying Capacity:
Operating Range:
Minimum Recommended Standoff: 1/8" (3.2 mm)
Sensitivity
Nominal
24 in/min
Maximum
(609 mm/min)
Slide Speed
Nominal Time
to Reach 90%
Speed

ITEMS SUPPLIED

AVC-2060 Plasma Height Control for WPD-1200 Linear Weaver includes:
CAS-1500-18
CAS-1558
AVC-1550-PL-??
AVC-2051-10
AVC-2055
"??" is the volt sensor option:
ID for use with Internal Divider
RV for use with Raw Voltage of blowback start type sources
PS for installation inside the Power Source for HF or capacitive discharge type sources
Difference between DC cutting voltage and set point (ΔV)
ΔV > 32 32 > ΔV > 15
24 in/min
(609 mm/min)
0.2 seconds 0.2 - 2 seconds
Height Slide Assembly
Pendulum Weaver Adaptor for CAS-1500-18
Hall Effect Current Sensor Assembly
MDS AHC 10' (3.0 m) Remote Control
MDS AHC Control Box
14.5 lbs (6.6 kg)
13" (330 mm)
10 lbs (4.5 kg)
36 to 300 Volts
15 > ΔV > 3
1.55 in/min
per volt
(39.3 mm/min (11.8 mm/min
per volt)
2 seconds
3 > ΔV > 0.4 0.4 > ΔV
0.46 in/min
per volt
slide may
not move
per volt)
slide may
2 seconds
not move
