Simple Fiber Amplifiers
E3X-SD/NA Series
Simplicity and High Performance
The Series now includes models with digital displays and direct key setting.
Digital Display – Direct Key Setting
NEW
Bar Display – Manual Setting

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E3X-NA F Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Omron E3X-NA F Series

  • Page 1 Simple Fiber Amplifiers E3X-SD/NA Series Simplicity and High Performance The Series now includes models with digital displays and direct key setting. Digital Display – Direct Key Setting Bar Display – Manual Setting...
  • Page 2 Simplicity and High Performance Operation and Displays So Simple That Anyone Can Use the Amplifier Right Away A design that focuses on simple operation has resulted in an Amplifier that is so simple it can be operated without the manual. The Amplifier also uses a large, easy-to-read operation indicator and a simple display for excess gain (i.e., incident level/operating level).
  • Page 3 High Performance Simplicity and General-purpose Performance for Simple Use The three most important performance capabilities when selecting a sensor are achieved to a high standard: distance, speed, and precision. Distance A balance is provided between reliable Super-long-distance Fiber Unit detection performance and capability for a E32-T17L broad range of applications.
  • Page 4 Selecting Fiber Amplifiers Simple For simple operation: Select a Simple Fiber Amplifier. Digital display and direct setting Bar display and adjuster setting Reliable Intuitive Standard Amplifiers E3X-SD@ E3X-NA@ Fastest in class Super-high-speed Amplifiers (20 µs) E3X-NA@F Water-resistant Amplifiers (IP66) E3X-NA@V All in One For multifunctional capability: Select an Advanced Fiber Amplifier.
  • Page 5: Ordering Information

    Simple Fiber Amplifier E3X-SD/-NA The Standard for Fiber Amplifiers with Simple Operation and High Performance ■ Operation so simple that essentially anyone can use the amplifier right way. ■ Immediately determine operation and amount of light with a simple, bright display. ■...
  • Page 6 E3X-SD/-NA Amplifier Unit Connectors (Order Separately) Note: Stickers for Connectors are included as accessories. Item Appearance Cable length No. of conductors Model Master Connector E3X-CN11 Slave Connector E3X-CN12 Amplifier Units Applicable Connectors (Order Separately) Combining Amplifier Units and Connectors Type Master Connector Slave Connector (Basically, Amplifier Units and Connectors are sold...
  • Page 7: Ratings And Specifications

    E3X-SD/-NA Ratings and Specifications Amplifier Units Digital display and direct key setting Bar display and adjuster setting Type High-speed detection Standard models Standard models Water-resistant models models Model E3X-SD@ E3X-NA@ E3X-NA@F E3X-NA@V Item Light source (wavelength) Red LED (620 nm) Red LED (680 nm) 12 to 24 VDC ±10%, ripple (p-p): 10% max.
  • Page 8 E3X-SD/-NA Fiber Unit Overview No snagging, no breaking: Right-angle (L-shaped) Models New Head Shape Feature L-shaped Attachment Feature Reflective model, 90 mm M6 screw E32-D11N 10 mm* 280 mm No snagging during maintenance. Fiber flexibility prevents breaking. Through-beam model, M4 screw E32-T11N 8 mm* Convenient design...
  • Page 9 E3X-SD/-NA Sensing Distance Through-beam Models (Unit: mm) E3X-SD@ Model E3X-NA@F E3X-NA@ Standard High-speed detection Type models models E32-T11R/E32-T12R/E32-T15XR/E32-TC200BR (B4R) E32-T14LR/E32-T15YR/E32-T15ZR Flexible E32-T21R/E32-T22R/E32-T222R/E32-T25XR/ (new standard) E32-TC200FR (F4R) E32-T24R/E32-T25YR/E32-T25ZR E32-TC200/E32-T12/E32-T15X/E32-TC200B (B4) E32-T14L/E32-T15Y/E32-T15Z Standard models Standard E32-TC200A E32-TC200E/E32-T22/E32-T222/E32-T25X/E32-TC200F (F4) E32-T24/E32-T25Y/E32-T25Z E32-T11/E32-T12B/E32-T15XB Break resistant E32-T21/E32-T221B/E32-T22B E32-T25XB Fluorine coating...
  • Page 10 E3X-SD/-NA Reflective Models (Unit: mm) E3X-SD@ Model E3X-NA@F E3X-NA@ Standard High-speed detection Type models models E32-D11R/E32-D12R/E32-D15XR/E32-DC200BR (B4R) E32-D14LR E32-D15YR/E32-D15ZR Flexible E32-D211R/E32-D21R/E32-D22R/E32-D25XR/ (new standard) E32-DC200FR (F4R) E32-D24R E32-D25YR/E32-D25ZR E32-DC200/E32-D15X/E32-DC200B (B4) E32-D12 E32-D14L Standard models E32-D15Y/E32-D15Z Standard E32-D211/E32-DC200E/E32-D22/E32-D25X/ E32-DC200F (F4) E32-D24 E32-D25Y/E32-D25Z E32-D11/E32-D15XB E32-D21B/E32-D221B Break resistant...
  • Page 11: I/O Circuit Diagrams

    E3X-SD/-NA I/O Circuit Diagrams Output Output Operation Model transistor Timing charts Output circuit form selector operation mode Incident light Brown No incident light Operation indicator Operation (orange) indicator (orange) LIGHT ON Load Light-ON Photo- (L-ON) Black Output electric 12 to Sensor E3X-SD11 transistor...
  • Page 12: Safety Precautions

    E3X-SD/-NA Nomenclature Amplifier Units E3X-SD@ E3X-NA Operation Keys Sensitivity adjustment (UP/DOWN or teaching) Sensitivity indicator Operation Selector 8-turn sensitivity adjuster Use to switch between Operation Indicator Light-ON and Dark-ON Operation Selector Timer switch Use to switch between Incident level Lock lever OFF/D: OFF-delay timer Incident level indicators Lock lever...
  • Page 13: Precautions For Correct Use

    E3X-SD/-NA Precautions for Correct Use Do not use the product in atmospheres or environments that Fiber Connection and Disconnection exceed product ratings. The E3X Amplifier Unit has a lock lever. Connect or disconnect the fibers to or from the E3X Amplifier Unit using Amplifier Units the following procedures: ●...
  • Page 14 E3X-SD/-NA Amplifier Units with Connectors ● Mounting Mounting End Plate (PFP-M) Mounting Connectors Depending on how it is mounted, an Amplifier Unit may move during operation. In this case, use an End Plate. 1. Insert the Master or Slave Connector into the Amplifier Unit Before mounting an End Plate, remove the clip from the until it clicks into place.
  • Page 15 E3X-SD/-NA Dimensions (Unit: mm) Amplifier Units Amplifier Units with Cables E3X-SD11 Vinyl-insulated round cable E3X-SD41 4 dia. cable / 3 conductors / Standard length: 2 m E3X-NA11 (Conductor cross section: 0.2 mm (AWG24), Operation indicator Insulator diameter: 1.1 mm) E3X-NA11F E3X-NA41 DIN track mounting 128.95...
  • Page 16 E3X-SD/-NA Amplifier Units with Connectors E3X-SD6 E3X-SD8 E3X-NA6 E3X-NA8 Operation indicator DIN track mounting 128.95 128.95 180° 93.75 93.75 Hole for optical communications A dia. * 31.5 31.5 12.95 10.7 Two, 2.4 dia. Multiple connection diagram 30.4 12.4 End Plate (sold separately) 64.3 64.3...
  • Page 17 E3X-SD/-NA Amplifier Units with Cables, Area of digital indication Water-resistant Models 28.65 E3X-NA11V 25.95 E3X-NA41V Vinyl-insulated round cable 4 dia. cable / 3 conductors / Standard length: 2 m (Conductor cross section: 0.45 mm (AWG24), Insulator diameter: 1.1 mm) Operation indicator Incident level indicators DIN track mounting 152.3...
  • Page 18 E3X-SD/-NA Amplifier Units with Connectors, Area of digital indication Water-resistant Models E3X-NA14V 28.65 25.95 E3X-NA44V Operation indicator Incident level indicators DIN track mounting 152.3 152.3 105.9 105.9 180° 11.2 10.7 Two, 2.4 dia. Hole for optical communications 14.4 31.9 Multiple connection diagram 67.2 67.2 End Plate...
  • Page 19 E3X-SD/-NA Amplifier Unit Connectors Master Connector 2,000 Edge of amplifier E3X-CN11 * E3X-CN11: 4 dia. 4 dia. cable / 3 conductors 3 conductors / Standard length: 2 m (Conductor cross section: 0.2 mm (AWG24), Insulator diameter: 1.1 mm) Slave Connector 2,000 E3X-CN12 Edge of amplifier...
  • Page 20: Operating Procedure

    E3X-SD/-NA Operating Procedure E3X-SD@ Operation description Switch/Key Display Hold down the UP Key during detection. Let the workpiece Displays pass while the key is held down. A 7-segment display showing excess gain is provided in Set the TEACH/RUN selector TEACH addition to the orange operation indicator.
  • Page 21 MEMO...
  • Page 22 MEMO...
  • Page 23 WARRANTY OMRON’s exclusive warranty is that the products are free from defects in materials and workmanship for a period of one year (or other period if specified) from date of sale by OMRON. OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE PRODUCTS.
  • Page 24 Industrial Automation Company IL 60173-5302 U.S.A. Sensing Devices Division H.Q. Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 Industrial Sensors Division OMRON ASIA PACIFIC PTE. LTD. Shiokoji Horikawa, Shimogyo-ku, No. 438A Alexandra Road # 05-05/08 (Lobby 2), Kyoto, 600-8530 Japan Alexandra Technopark, Singapore 119967...
