® to preserve the right product, in the right place, at the right temperature. Since 2014, U-Line has been part of the Middleby family of brands. All products are designed, engineered, and assembled in Milwaukee, Wisconsin, USA, and select products are available worldwide.
For more details, see the complete User Guide & Service Manual on u-line.com. 1 year + 1 with registration This product is eligible for an additional one-year warranty at no charge when you register your product on u-line.com. See complete warranty for details.
QUICK START GUIDE u-line.com Safety and Warning DANGER NOTICE Your product may contain R600a (Isobutane) Please read all instructions before installing, which is a flammable hydrocarbon. To confirm, operating, or servicing the appliance. check serial tag inside of unit. It is safe for regular use.
QUICK START GUIDE u-line.com Environmental Requirements NOTICE Electrical installation must observe all state and local codes. This unit requires connection to a This model is intended for indoor/interior applications only grounded (three-prong), polarized receptacle and is not to be used in installations that are open/ that has been placed by a qualified electrician.
CAUTION The water valve uses a standard 1/4” (6.35 mm) is under pressure at all times. Plastic may crack compression fitting. U-Line recommends using accessory or rupture with age and cause damage to your PREPARE PLUMBING Do not use any plastic water supply line. The line water hook up kit –...
Page 7
QUICK START GUIDE USER GUIDE u-line.com u-line.com 3. Locate water valve inlet. 9. Install retaining clip. 4. Break away filler feature in bushing with flat screwdriver. Remove screwdriver 5. Thread water line through back panel hole (with bushing). 6. Locate water valve inlet and connect to valve.
Page 8
CAUTION The water valve uses a standard 1/4” (6.35 mm) is under pressure at all times. Plastic may crack compression fitting. U-Line recommends using accessory or rupture with age and cause damage to your PREPARE PLUMBING Do not use any plastic water supply line. The line water hook up kit –...
Page 9
QUICK START GUIDE USER GUIDE u-line.com u-line.com 3. Locate water 8. Install retaining clip. valve in the front of the unit and thread water supply line through. NOTICE Route the water supply line through the unit so it does not come into contact with any internal components other than the solenoid valve.
Page 10
CAUTION The water valve uses a standard 1/4” (6.35 mm) is under pressure at all times. Plastic may crack compression fitting. U-Line recommends using accessory or rupture with age and cause damage to your PREPARE PLUMBING Do not use any plastic water supply line. The line water hook up kit –...
Page 11
QUICK START GUIDE USER GUIDE u-line.com u-line.com Turn off water supply and disconnect electrical supply to product prior to attempting installation. Remove the back panel. Thread water line through back panel hole (with bushing). Locate water valve inlet and connect to valve.
DRAIN CONNECTION CAUTION With Trap and Vent Proper Drain If your U-Line unit did not come with a factory installed drain pump you must use a gravity A gravity drain may be used if: style drain connection. For assistance in Drain line has at least a 1"...
(Optional Hook-Up) spigot assembly, or does not otherwise meet the requirements for a gravity drain, you may have ordered a pre-installed U-Line P60 drain pump. Waste If you need to install a P60 drain pump into your unit, see Valve DRAIN PUMP section in the User Manual.
Page 14
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Door Adjustments 5. Tighten bottom hinge screws. CRESCENT ICE MAKERS 6. Tighten top hinge screws and replace hinge cover. REVERSING THE DOOR HINGE COVER Location of the unit may make it desirable to mount the Hinge cover included with the literature bag is optional.
Page 15
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Install top hinge and door: 4. Remove door by tilting forward and lifting door off bottom hinge. Retain shoulder washers; they will be Top Hinge Right Side reused. 5. Remove three screws from hinge holes on the opposite side.
Page 16
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Door Adjustments 5. Tighten bottom hinge screws. 15” REFRIGERATORS AND CLEAR ICE MACHINES 6. Tighten top hinge screws and replace hinge cover. REVERSING THE DOOR HINGE COVER Location of the unit may make it desirable to mount the Hinge cover included with the literature bag is optional.
Page 17
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Remove bottom hinge: Install top hinge and door: 1. Remove bottom hinge from cabinet using 1/4” socket. Top Hinge Right Side Top Hinge Left Side Pivot Screw 1. Remove pivot screw from hinge, flip hinge over, and 2.
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Door Adjustments 6. Tighten top hinge screws and replace hinge cover. 24” MODELS AND NUGGET ICE MACHINES REVERSING THE DOOR HINGE COVER Hinge cover included with the literature bag is optional. Location of the unit may make it desirable to mount the door on the opposite side of the cabinet.
Page 19
QUICK START GUIDE u-line.com QUICK START GUIDE u-line.com Prepare door for reinstallation: 1. Remove gasket. This will reveal mounting holes for the magnet assembly. 2. Remove magnet assembly from door with T-10 TORX driver. Be sure to only remove the two screws holding the assembly to the door.
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com General Installation INSTALLATION 1. Plug in the power/electrical cord. LEVELING INFORMATION 1. Use a level to 2. Gently push the unit into position. Be careful not to confirm the unit is entangle the cord or water and drain lines, if level.
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Control Operation REFRIGERATORS CONTROL FUNCTION GUIDE CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES FUNCTION COMMAND NOTES ON/OFF Press and release Unit will turn On or OFF ON/OFF Press and hold for 5 seconds...
Page 22
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Control Operation CLEAR ICE MACHINES CONTROL FUNCTION GUIDE CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES FUNCTION COMMAND NOTES ON/OFF Press and release Unit will immediately turn On or OFF ON/OFF Press and release...
Page 23
QUICK START GUIDE u-line.com Control Operation CONVERTIBLE FREEZER CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and release Unit will immediately turn On or OFF Press and release to leave interior After 12 hours, factory default is restored; light will Leave interior light on light on for 12 hours;...
Page 24
QUICK START GUIDE u-line.com Control Operation NUGGET ICE MACHINES CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and release Unit will immediately turn On or OFF Adjust ice density See “Ice” section The o F / o C symbol will flash briefly after 5 seconds.
CRESCENT ICE MAKERS Initial startup requires no adjustments. • 30ºF to 0ºF - 1 hour U-Line recommends discarding the ice produced during the • 0ºF to 38ºF - 4 hours first two to three hours of operation to avoid possible dirt or scale that may dislodge from the water line.
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com During periods of limited use or high ambient temperatures, it is common for cubes to fuse together. CRESCENT ICE MAKERS Gently shake the bucket to break apart cubes. If not using the ice maker regularly, empty the ice bucket periodically to ensure fresh cubes.
Page 27
QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com CLEAR ICE MACHINES CAUTION ICE CUBE THICKNESS ADJUSTMENT Too large of an adjustment to the screw can Ice thickness adjustment should only be made cause the water to overflow the ice maker and one increment at a time.
Page 28
This ensures a constant supply of fresh ice is always available. The factory default ice setting is 0, which produces a firm and compact ice nugget. U-Line’s exclusive U-Choose™ ice adjustability feature allows you five levels of Factory Default Setting - 0 adjustment from 0 to -5.
Do not use stainless steel cleaners or polishes on any glass surfaces. CLEAR ICE MACHINE CLEANING CYCLE Your U-Line clear ice machine has an automatic clean Clean any glass surfaces with a non-chlorine glass alert function. Cleaning cycles should be run as notified.
Page 30
Water trough before use. 6. Clean the Interior Bin as follows: U-Line Ice Machine Cleaner is used to remove lime scale and other mineral deposits. Refer to the following steps to initiate the self-cleaning cycle. • Dilute one packet of CLR cleaner into two quarts of water.
Page 31
. You may initiate maintenance, your unit may become excessively coated in a cleaning cycle at any time by pressing and lime scale or calcium. U-Line offers a cost effective refresh Cleaning holding the clean button for 10 seconds. will...
Page 32
While the machine is circulating the cleaning Need more cleaner? Visit u-line.com and odors. U-Line recommends replacing the solution, use 1⁄2 of the remaining cleaning solution Press and release filter (Part No. ULANUGGETFILTER) when you...
Page 33
USER GUIDE QUICK START GUIDE u-line.com u-line.com When appears in the display, 3 soft tones will sound, indicating the cleaning phase is complete a. Remove and discard water filter if applicable by rotating 1⁄4 turn counterclockwise. b. Use the remaining cleaning solution to wipe the manifold and surrounding area.
For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase. All service provided by U-Line under the above warranty must be performed by a U-Line factory authorized servicer, unless otherwise specified by U-Line.
