JVC AV28H20EUS Service Manual page 8

AV32H20EUS
AV28H20EUS
AV28H20EUB
REMOVING THE CRT
∗ Replacement of the CRT should be performed by 2 or more
pers ons.
• After removing the c over, chassis etc.,
1. Putting the CRT c hange table on soft cloth, the CRT change table
should also be c overed with s uch soft cloth (shown in Fig.3).
2. While keeping the s urfac e of CRT down, mount the TV s et on the
CRT change table balanced will as shown in Fig.4.
3. Remove 4 sc rews marked by arrows with a box type screw driver
as s hown in Fig.4.
• Sinc e the cabinet will drop when screws have been removed, be
sure to support the cabinet with hands.
4. After 4 screws have been removed, put the cabinet slowly on
cloth (At this time, be carefully so as not to damage the front
surfac e of the c abinet) shown in Fig.5.
• The CRT should be ass embled according to the opposite
sequence of its dismounting steps.
∗ The CRT change table should preferably be smaller that the CRT
surfac e, and its height be about 35c m.
8
CRT CHANGE TABLE
CLOTH
CRT
CHANGE
TABLE
CABINET
No. 51945
APPROX.
35cm
Fig. 3
CRT
BOX
TYPE
SCREW
DRIVER
Fig. 4
CRT
CRT
CHANGE TABLE
Fig. 5
